Install the new AC PEM all the way into the power bay to ensure a secure
Step 3
connection to the backplane, and then tighten the captive screws (Figure 6).
Figure 6
Captive
screws
78-10832-01
Installing an AC PEM
PO W ER
FA U LT
Cisco 10000 ESR AC Power Entry Module Installation
Adding or Replacing an AC PEM
