Eneo ENX-900P Installation Manual

Package Contents

Before you start to install this switch, please verify your
package that contains the following items:
• 2 Port PoE Extender (1x)
• Quick Installation Guide (1x)
• Sets of screws for wall mounting (2x)

Key Features

• 2 Port PoE Extender: 1 Port 10/100M PoE In (Data +
Power in) and 1 Port 10/100M PoE Out (Data + Pow-
er out) which is compliant with IEEE 802 10BaseT,
IEEE 802.3u 100BaseTX and IEEE 802.3af PoE.
• 1 Port (Data + Power in) is IEEE 802.3af Powered
Device (PD) getting power source from other PSE
• 1 Port (Data + Power out) is IEEE 802.3af Power
Souring Equipment (PSE) providing power source
to other PD
• Dedicated full-duplex 200Mbps bandwidth
• Smart plug & play
• A DIP switch for turning ON/OFF PoE function

Front Panel (LEDs)

LED Indicator of 2 Port PoE Extender
LED Status Description
On PoE function ON
PoE
Off PoE function OFF or no connection
On Port is connected
Data Off No connection
Flashing Data is transmitting or receiving

Connections

PSE/PD to 2 Port PoE Extender
This PoE extender provides automatic crossover de-
tection functionality. Via a twisted pair cable straight
through, this PoE extender can be connected to other
PSE/PD.

Power and Extend Distance

Power is supplied through Cat. 5e/6 cable from other
PSE and extend a distance to another 100M through this
device. Please see the table below for your reference.
Number of Distance PD voltage PD max
PoE Source
PSD-311 (m) (V) power (W)
1 200 47 16.45
2 300 43.8 14.41
802.3af
PoE switch
3 400 40.9 12.27
4 500 38 10.64

Technical Specifications

IEEE 802.3af
IEEE 802.3 10BaseT
Standards
IEEE 802.3u 100BaseTX
IEEE 802.3x Flow control
Number of Ports:
1 x PoE In (Data + Power in)
Features +1 x PoE Out
(Data + Power out)
Method: Store and Forward
100Mbps port – 148,800pps
Filtering/Forwarding Rates
10Mbps – 14,880pps
Transmission Media Cat. 5e/6 UTP/STP
LED Indicators Per Port : Link/Act, PoE
Dimensions 123 x 32 x 20 mm
Weight 98g
Operating Temperature 0 to 40℃
Storage Temperature -20 to 90℃
Humidity 10 to 90% RH (non-condensing)
Certifications FCC Class A, CE
