- Page 1 Quick Installation Guide HD-TVI/AHD/HDCVI/CVBS with RS485 Fiber Optical Extender MAM-5MF1001MTA...
-
Page 2: Table Of Contents
Contents Panel View ........................5 HD-TVI/AHD/HDCVI/CVBS Fiber Optical Extender .............6 Features ....................................6 Installation View ................................6 LED Indication ..................................6 Cable & Transmission Distance .............................6 Specifications..................................7 Further information .................................7... - Page 3 Safety instructions General safety instructions • Before switching on and operating the system, first read this safety advice and the operating instructions. • Keep the operating instructions in a safe place for later use. • Installation, commissioning and maintenance of the system may only be carried out by authorised individuals and in accordance with the installation instructions - ensuring that all applicable standards and guidelines are followed.
- Page 4 WEEE (Waste Electronical & Electronic Equipment) Correct Disposal of This Product (Applicable in the European Union and other European countries with separate collection systems). This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
-
Page 5: Panel View
Panel View... -
Page 6: Hd-Tvi/Ahd/Hdcvi/Cvbs Fiber Optical Extender
HD-TVI/AHD/HDCVI/CVBS Fiber Optical Extender MAM-5MF1001MTA support HD-TVI/AHD/HD-CVI/HD-TVI/CVBS 4-in-1 Video signal over Fiber cable. Based on digital uncompressed HD composite video technologies which convert the AHD, HDCVI, HD-TVI or CVBS composite signals to optical signals to reach long distance up to 20 km. -
Page 7: Specifications
Half Duplex Power DC5V 1A DC5V 1A Power Consumption ≤5W ≤5W Humidity Operation: -40 to 75°C, Storage: -20 to 85°C, Humidity: up to 95% Weight 200 g Further information The manual is also available from the eneo web site at www.eneo-security.com. - Page 8 VIDEOR E. Hartig GmbH Exclusive distribution through specialised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
