SERVICE
SUHD TV
UN78JS8600F
SUHD TV
Chassis : UWJ50
Model
: UN78JS8600F
Manual
1. Precautions
2. Product specifications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
Contents

Advertisement

Table of Contents
loading

Related Manuals for Samsung UN78JS8600F

Summary of Contents for Samsung UN78JS8600F

  • Page 1 SUHD TV Chassis : UWJ50 Model : UN78JS8600F SERVICE Manual SUHD TV Contents 1. Precautions 2. Product specifications 3. Disassembly and Reassembly 4. Troubleshooting 5. Wiring Diagram UN78JS8600F...

  • Page 2: Table Of Contents

    2-2-2. Detailed Specifications ..................2-3 2-3. Accessories ........................2-7 2-4. Viewing the Functions ..................... 2-8 2-4-1. The Samsung Smart Control................2-8 2-4-2. Learning motion control basics ................2-12 2-4-3. Viewing the Panel ....................2-13 2-4-4. Using the web browser ..................2-18 2-4-5.
  • Page 3 4-3. Factory Mode Adjustments ..................... 4-9 4-3-1. Detail Factory Option ................... 4-9 4-3-2. Entering Factory Mode ..................4-10 4-3-3. Factory Data ...................... 4-11 4-4. White Balance ......................4-20 4-4-1. Calibration ......................4-20 4-4-2. Service Adjustment .................... 4-20 4-4-3. Adjustment ......................4-22 4-5.
  • Page 4 This Service Manual is a property of Samsung Electronics Co.,Ltd. © 2015 Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under applicable All rights reserved. International and/or domestic law. Printed in Korea...

  • Page 5: Precautions

    1. Precautions 1. Precautions 1-1. Safety Precautions Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as electrical shock. 1-1-1. Warnings For continued safety, do not attempt to modify the circuit board. Disconnect the AC power and DC power jack before servicing.

  • Page 6: Product Safety Notices

    1. Precautions 1-1-4. Product Safety Notices Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage, wattage, etc.

  • Page 7: Servicing Precautions

    1. Precautions 1-2. Servicing Precautions An electrolytic capacitor installed with the wrong polarity might explode. WARNING Before servicing units covered by this service manual, read and follow the Safety Precautions section of this manual. CAUTION If unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions, always follow the safety precautions.

  • Page 8: Static Electricity Precautions

    1. Precautions 1-3. Static Electricity Precautions Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some field-effect transistors. The following techniques will reduce the incidence of component damage caused by static electricity. Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your body by touching a known earth ground.

  • Page 9: Installation Precautions

    1. Precautions 1-4. Installation Precautions For safety reasons, more than a people are required for carrying the product. Keep the power cord away from any heat emitting devices, as a melted covering may cause fire or electric shock. Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature may cause fire.

  • Page 10: Product Specifications

    2. Product specifications 2. Product Specifications 2-1. Product information Model UN78JS8600F Front View * W : Width H : High D : Depth Detail View Front Color Silver Body 1770.2 X 1010.7 X 38.3 mm Dimensions 78" (W x H x D) With stand 1770.2 X 1072.8 X 325.0 mm...

  • Page 11: Product Specification

    • CMR 1440 • Dolby Digital Plus MS11, DTS Premium Sound 5.1, DTS Studio Sound • One Connect Mini Specifications „ Model UN78JS8600F Item Description Screen Size (Diagonal) 78 inches LCD Panel UHD 120Hz Display Colors 1.07B color (10bit) Display Resolution...

  • Page 12: Detailed Specifications

    DTS Premium Sound 5.1 3D Sound Sound Customizer Sound Output (RMS) 50W(L:10W, R:10W, Woofer: 15W*2) Speaker Type 2.2CH (Front Firing) Woofer Yes (Dual Woofer) HD Audio Wallmount Sound Mode Multiroom Link Smart TV Samsung SMART TV Apps Game Multi-Link Screen...
  • Page 13 Face recognition Ready Motion control Ready Convergence TV to Mobile - Mirroring Mobile to TV - Mirroring Wired (US Only) Samsung SMART View Wireless TV On - WOL Notification - BLE Briefing On TV WiDi WiFi Direct Tuner/Broadcasting Digital Broadcasting...
  • Page 14 Bezel Type Slim Type Ultra-Thin Slim Front Color Silver Light Effect (Deco) Stand Type Slim T Stand Swivel (Left/Right) Additional Feature Samsung 3D 3D Converter Instant On Camera Built-in Wireless Copy Processor Quad-Core PX Ready 21:9 Immersive Picture Mode SCSA Support...
  • Page 15 Eco Sensor Accessory 3D Active Glasses (Included) Remote Controller Model Smart Control Batteries (for Remote Control) Samsung Smart Touch Control (Included) PX (Included) Ultra Slim Wall Mount Supported Mini Wall Mount Supported Vesa Wall Mount Supported Floor Stand Support TV Camera (Included)

  • Page 16: Accessories

    2. Product specifications 2-3. Accessories NOTE • The items’ colors and shapes may vary depending on the model. • Cables not included in the package contents can be purchased separately. • The part code for some accessories may differ depending on your region. Product Code.

  • Page 17: Viewing The Functions

    : Changes the channel. POINTER: Place a finger on the POINTER button and move the Samsung Smart Control. The pointer on the screen moves in the direction you moved the Samsung Smart Control. Press the POINTER button to select or run a focused item.
  • Page 18 - System - Smart Control Settings - Motion Sensitivity. • To use the POINTER button and the movement of the Samsung Smart Control to operate your TV, Voice Guide must be set to Off. • To view a tutorial that shows how to use the...
  • Page 19 2. Product specifications Displaying and using the On-Screen Remote „ Button Description Menu Displays the menu on the screen. Voice Recognition Runs the Voice Recognition function. Picture Size Changes the picture size. Caption Turns captions on or off. Network Settings Displays screens that allow you to change your network settings.
  • Page 20 2. Product specifications Button Description Use these colored buttons to access additional options specific to the feature in use. • These buttons are only available in the U.S.A. and Canada. Move Number Pad to the Moves the number pad to the left or right. Right / Move Number Pad to the Left NOTE...

  • Page 21: Learning Motion Control Basics

    " " 2. Product specifications 2-4-2. Learning motion control basics The following actions are available. Image Description Moving the pointer Move your hand to move the pointer accordingly. Selecting an item Fold down and raise your index finger to select items. You can select a TV menu or run a function.

  • Page 22: Viewing The Panel

    2. Product specifications 2-4-3. Viewing the Panel Smart Hub „ NOTE • The image may differ with the specific model and area. You can surf the web and download apps with Smart Hub. In addition, you can enjoy photo, video, and music files stored on external storage devices.
  • Page 23 This function is not available on certain models in specific geographical areas. You can download, play, and manage games or games purchased with your Samsung account. Select a game displayed on the screen or select a genre category such as Spotlight, Most Popular, What's New, or Top Grossing from the top of the screen, and then select a game in the genre you selected.
  • Page 24 2. Product specifications APPS „ NOTE • Screen images may differ by model. • To use this feature, the TV must be connected to the Internet. • When Smart Hub is launched for the first time, the default apps are automatically installed. The default apps may differ by region.
  • Page 25 You cannot play media content if the content or the storage device is not supported by the TV. For more information, refer to "Read Before Playing Photo, Video, or Music Files." • Backup important files before connecting a USB device. Samsung is not responsible for damaged or lost files. 2-16...
  • Page 26 2. Product specifications NewsON „ NOTE • Screen images may differ by model. • Before you use the NewsON Service, check if the TV is connected to the Internet. • The image may differ with the model. • This service or some of functions is not available on all countries or region.. You can find daily information on a wide variety of topics in a smart and convenient way, updated in real time.

  • Page 27: Using The Web Browser

    2. Product specifications 2-4-4. Using the web browser You can surf the Internet on the TV in the same manner as you would using a PC - even while watching a TV programme using PIP. Select Help to view the information of the Internet web browser. NOTE •...

  • Page 28: Playing Multiple Screens

    Custom to turn on or off the sound from the selected screen. If you connect a Bluetooth headphone, you can only select Bluetooth Headphones. NOTE On the Samsung Smart Control, press the MENU/123 button, and then select Speaker List to set the speaker of each screen. 2-19...

  • Page 29: Enabling The Tv To Boot Faster

    NOTE • When Samsung Instant On is set to On, the use history of the apps that you used on the TV may be stored in the • The Samsung Instant On function works when you turn on the TV while its power cable is still connected after you set Samsung Instant On to On.

  • Page 30: Hdmi Uhd Color

    2. Product specifications 2-4-7. HDMI UHD Color Allows you to set the HDMI UHD Color mode to On or Off for each HDMI connector on the TV. When set to On, the TV optimizes processing of UHD 50P/60P signals. To configure the HDMI UHD Color mode for each HDMI connector, turn off the external devices. You can leave the HDMI cables connected to the TV.

  • Page 31: Supported Formats

    2. Product specifications 2-4-8. Supported Formats Supported external subtitles „ Name Format MPEG-4 Timed text .ttxt SAMI .smi SubRip .srt SubViewer .sub Micro DVD .sub or .txt SubStation Alpha .ssa Advanced SubStation Alpha .ass Powerdivx .psb SMPTE-TT Text .xml Supported internal subtitles „...
  • Page 32 2. Product specifications Supported Image resolution „ File Extension Type Resolution *.jpg JPEG 15360x8640 *.jpeg *.png 4096x4096 *.bmp 4096x4096 *.mpo 15360x8640 Supported Music File Formats „ File Extension Type Codec Comments *.mp3 MPEG MPEG1 Audio Layer 3 *.m4a *.mpa MPEG4 *.aac *.flac FLAC...
  • Page 33 2. Product specifications Supported Video Code „ File Frame rate Bit rate Container Video Codecs Resolution Audio Codec Formats (fps) (Mbps) 4096x2160: 24 H.264 BP/MP/HP 3840x2160: 30 HEVC (H.265 - 4096x2160 Main, Main10, Main4:2:2 10) Motion JPEG *.avi *.mkv *.asf *.wmv Dolby Digital *.mp4...
  • Page 34 2. Product specifications Other Restrictions „ • Codecs may not function properly if there is a problem with the content. • Video content does not play or does not play correctly if there is an error in the content or container. •...

  • Page 35: Features & Operation

    2. Product specifications 2-4-9. Features & Operation Nano-Crystal Tech & Direct type & Back light peaking control „ Achievement of Wide color gamut • DCI coverage 74% (White LED) 93% (Nano Crystal) • Enables vivid color display (Better Red and Green color) •...

  • Page 36: Disassembly And Reassembly

    3. Disassembly and Reassemble 3. Disassembly and Reassembly This section of the service manual describes the disassembly and reassembly procedures for the LED TV. This LED TV contains electrostatically sensitive devices. Use caution when handling these components. WARNING 3-1. Disassembly and Reassembly Disconnect the LED TV from the power source before disassembly.
  • Page 37 3. Disassembly and Reassemble Description Picture Description Screws Remove the Electric tapes shown on the image. • EMI Point : After removing release paper from the LVDS Cable bottom, attach the LVDS Cable to the C/ Chassis and rub the attatched surface.
  • Page 38 3. Disassembly and Reassemble Description Picture Description Screws Remove the screws of ASSY PCB MAIN Torque : and DC VSS-LED TV PD BD. 7~ 8Kgf.cm. • ASSY PCB MAIN : 4 EA • DC VSS-LED TV PD BD : 6 EA •...
  • Page 39 3. Disassembly and Reassemble Description Picture Description Screws Remove the IR unit. • Remove the IR unit by moving it from up to down. IR Assy Remove the JOG unit. • Remove the JOG unit by moving it from top to bottom top. Remove screws of BRKT STAND LINK Torque : and remove the BRKT from Panel.

  • Page 40: One Connect Mini

    3. Disassembly and Reassemble 3-1-2. One Connect MINI Description Picture Description Screws Remove 4 Screws from the bottom of Torque : the One Connect MINI. 7~ 8Kgf.cm. 6003-000282 Lift off the Bottom Cover. NOTE Reassembly procedures are in the reverse order of disassembly procedures.

  • Page 41: Troubleshooting

    4. Troubleshooting 4. Troubleshooting 4-1. Troubleshooting 4-1-1. Previous Check Check the various cable connections first. Check to see if there is a burnt or damaged cable. Check to see if there is a disconnected or loose cable connection. Check to see if the cables are connected according to the connection diagram. Check the power input to the Main Board.

  • Page 42: How To Check Fault Symptom

    4. Troubleshooting 4-2. How to Check Fault Symptom 4-2-1. Video Customer Picture Test „ Main Board Pre FRC Post FRC Problem Pass Pass Pass Check Signal Source and other inputs Fail Pass Pass Main Board or LVDS Cable Fail Fail Pass FRC (Main Board in TV) Fail...
  • Page 43 4. Troubleshooting Troubleshooting Video Test Power TV ON. Verify initial Start Up Screens with Power On. Press Mute 147 Mute to view Test Pattern from the MAIN Board. Press Mute 369 Mute to view Test Pattern from T-CON Board. (NOT Available on This Model) Start Up Screens Mute 147 Mute Mute 369 Mute...

  • Page 44: Bluetooth / Wifi Module

    4. Troubleshooting 4-2-2. Bluetooth / WIFI Module Bluetooth Module „ Troubleshooting Check Bluetooth Address at Contact Samsung. BT Address Check BT Version at Factory Mode screen. Might require upgrade. Check GSPN. T-HKMAKUC-XXXX.XX T-HKMAKUS-XXXX BT Version BT Version : BLUETOOTH-VER-XXXX E-MANUAL : HMUATSCJ-X.XXX...
  • Page 45 4. Troubleshooting WIFI Module „ Troubleshooting Check Wired MAC Address and Wireless MAC Address at Contact Samsung. Wired MAC Address Wireless MAC Address Check Wired MAC and Wireless MAC at Factory Mode screen. (Success/Failure) Wired MAC errors : Main Board is defective.

  • Page 46: One Connect Mini

    4. Troubleshooting 4-2-3. One Connect Mini SYMPTOM : When One Connect Mini is connected or disconnected, Re boot will „ be 10 sec later. When One Connect Mini is connected or disconnected, The Following Message appear on the TV. And Re boot will be 10 sec later.

  • Page 47: Jog Function Control

    4. Troubleshooting 4-2-4. Jog Function Control Jog Function Control „ Press Left Right Down Center Vol+ Vol- Jog Function Control Test „ Check Jog Shuttle STBY Voltages (All at 1.8VDC except LED) Check Jog Shuttle 5 SW Operation Key1 & Key 2 for each command change. (See Chart) Check LED active during STBY (1.8VDC ) Signal DC Voltage...

  • Page 48: T-Con Board

    4. Troubleshooting 4-2-5. T-CON Board T-CON Operation and Testing Check voltage of SMPS connectors to TV Board/Hawk UFP(CNM803) and TCON(CNT803) Test for 13VDC at both sides of both fuses on the TCON Board. If either one of the fuses is open, replace the T-CON Board. If 13VDC are missing on fuses, check power feed from SMPS (CON_12V, pins 1-7).

  • Page 49: Factory Mode Adjustments

    4. Troubleshooting 4-3. Factory Mode Adjustments 4-3-1. Detail Factory Option NOTE If you replace the main board with new one, please change the factory option as well. The options you must change are "Type". UN**JS8600FXZA „ Inches 78" Vendor PANEL Code BN95-02393A Spec.

  • Page 50: Entering Factory Mode

    4. Troubleshooting 4-3-2. Entering Factory Mode To enter ‘Service Mode’ Press the remote -control keys in this sequence : • If you do not have Factory remote control Power OFF MUTE Power On • If you have Factory remote control INFO Factory •...

  • Page 51: Factory Data

    4. Troubleshooting 4-3-3. Factory Data Option „ Factory Menu Name Data Range Factory Reset Type 78A1UU8QJ Local Set SW Model UJS8600 BOM Model 8600 TUNER S_TDA18275A Ch Table NONE MRT Option Engineer Option Control „ Factory Menu Name Data Range EDID EDID ON/OFF EDID WRITE ALL...
  • Page 52 4. Troubleshooting Factory Menu Name Data Range OPTION_SWU RF Remocon Support CDD mode … DPMS Support T-CON Device Status OK LMN 1ST THRESHOLD LMN 2ND THRESHOLD LMN 3RD THRESHOLD EOS Click BP PMS Reset FAnet Thread User InstantOn Default Value CI CPLD Version ACM_MC HotkeyList...
  • Page 53 4. Troubleshooting Factory Menu Name Data Range Asia Option Unbalance AF Level adjust TX Power Level Mono Last Memory H Shaking SOUND High Devi Carrier_Mute *If the broadcast signal is not good, TV will complement the characteristics of the signal (most use when weak signal comes from the growing area countries) Pilot Level High Thld...
  • Page 54 4. Troubleshooting Factory Menu Name Data Range Speaker Delay Normal NTV CU Delay Lipsync Inx Lipsync CheckSum 0x6431 Lipsync USB Test Ready Lipsync BT CheckSum 0x0000 TP Volume 0xc9h TP Scale 0x64h TP EQ CheckSum NONE Debug „ Factory Menu Name Data Range Spread Spectrum...
  • Page 55 4. Troubleshooting Factory Menu Name Data Range Error Popup On/Off Deadlock KILL CES Mode ON/Off NONE CES Option CES Convergence Option TCON Demura Bypass BT DUT Reproduce Module 21_9 „ Factory Menu Name Data Range Self Test(for HW) Info Upgrade T-CON Usb Download * UpgradeT-CON eeprom T-CON CheckSum...
  • Page 56 4. Troubleshooting Factory Menu Name Data Range NTV CU Update Failure UD LDC PROFILE UPGRADE Failure Pic Data USB Update P:066/M:002 Audio Data USB Update Eco Data USB Update E:071/M:002 CI CPLD Upgrade Failure TCON DEMURA FW UPGRADE Reset OPTION_HDMI DVI/HDMI SOUND Auto HDMI HOT PLUG...
  • Page 57 4. Troubleshooting Factory Menu Name Data Range HdmiRx EQ DVB CI European specifications Test Pattern * the Output of test pattern from each IC Other setting SVC Panel ORIGINAL Tizen ADC/WB „ Factory Menu Name Data Range AV Calibaration Comp Calibration PC Calibration HDMI Calibration ADC Result...
  • Page 58 4. Troubleshooting Factory Menu Name Data Range WB_W2_R_Gain WB_W2_B_Gain WB_N_R_Offset WB_N_B_Offset WB_N_R_Gain WB_N_B_Gain MGA On/Off R1_Gain G1_Gain B1_Gain R2_Gain G2_Gain B2_Gain R3_Gain G3_Gain B3_Gain R4_Gain G4_Gain B4_Gain R5_Gain G5_Gain B5_Gain R6_Gain G6_Gain B6_Gain R7_Gain G7_Gain B7_Gain R8_Gain G8_Gain B8_Gain R9_Gain G9_Gain B9_Gain R10_Gain...
  • Page 59 4. Troubleshooting Factory Menu Name Data Range B10_Gain SPI White Balance SPI MGA WB Data to SPI Advanced „ 4-19...

  • Page 60: White Balance

    4. Troubleshooting 4-4. White Balance 4-4-1. Calibration Into the Factory Mode. Select ADC/WB menu. Select menu. AV Calibration Option Comp Calibration Control PC Calibration Debug HDMI Calibration ADC/WB Advanced 4-4-2. Service Adjustment You must perform Calibration in the Lattice Pattern before adjusting the White Balance. Color Calibration „...
  • Page 61 4. Troubleshooting Method of Color Calibration (AV) Apply the NTSC Lattice (N0. 3) pattern signal to the AV IN 1 port. Press the Source key to switch to “AV1” mode. Enter Service mode. Select the “ADC” menu. Select the “AV Calibration” menu. In “AV Calibration Off”...

  • Page 62: Adjustment

    4. Troubleshooting 4-4-3. Adjustment Into the Factory Mode. ADC/WB Select menu. Select White Balance menu. Option Control Debug (Low Light) (Hight Light) Sub Brightness Sub Contrast White Balance ADC/WB R offset R gain Advanced G offset G gain B offset B gain 4-22...

  • Page 63: Rs-232C

    4. Troubleshooting 4-5. RS-232C • RS232C Control Port : COM#(Serial) Baud rate : 9600 Data Bit : 8 bit Parity : None Stop Bits : 1 Flow Control : None • Description of RS232C Pin# Name Full Name Pin# Name Full Name Pin# Name Full Name...

  • Page 64: Av Control Tabe

    4. Troubleshooting 4-6. AV Control Tabe Control Item Cmd1 Cmd2 Cmd3 Value General Power Power 0x00 0x00 0x00 0x00 0x01 0x02 Volume Direct 0x01 0x00 0x00 (0~100) 0x01 0x00 Down 0x02 0x00 Mute 0x02 0x00 0x00 0x00 Direct 0x04 Continuous 0x01 0x00 0x03...
  • Page 65 4. Troubleshooting Control Item Cmd1 Cmd2 Cmd3 Value PICTURE Mode Natural 0x03 CAL-NIGHT 0x04 CAL-DAY 0x05 BD Wise 0x06 Relax New function of 12" 0x07 (only PDP TV) BackLight 0~20 0x01 0x00 (0~20) (CellLight) Contrast 0~100 0x02 0x00 (0~100) Brightness 0~100 0x03 0x00...
  • Page 66 4. Troubleshooting Control Item Cmd1 Cmd2 Cmd3 Value PICTURE Advanced Edge Enhancement 0x0f 0x00 Settings 0x01 xvYCC 0x10 0x00 0x01 Motion Lighting 0x11 0x00 0x01 Color Space Custom 0x12 0x00 Color Green 0x01 Blue 0x02 Only for active Color Space Custom Yellow 0x03 Cyan...
  • Page 67 4. Troubleshooting Control Item Cmd1 Cmd2 Cmd3 Value PICTURE Picture HDMI Black Level Normal 0x04 0x00 Option 0x01 Film Mode 0x05 0x00 Auto1 0x01 Auto2 0x02 Cinema New function of 12" 0x03 Smooth (only PDP TV) Auto Motion Plus 0x06 0x00 Clear 0x01...
  • Page 68 4. Troubleshooting Control Item Cmd1 Cmd2 Cmd3 Value PICTURE 3D View Point 0x02 (-5~5) Depth 0x03 (1~10) 3D Auto View 0x05 0x00 Message 0x01 Notice 0x02 Control Item Cmd1 Cmd2 Cmd3 Value Sound Sound Mode Standard 0x0c 0x00 0x00 0x00 Music 0x01 Movie...
  • Page 69 4. Troubleshooting Control Item Cmd1 Cmd2 Cmd3 Value Sound Auto Volume Night 0x02 Speaker TV Speaker 0x07 0x00 0x00 Select External Speaker 0x01 Sound Main 0x08 0x00 0x00 Select 0x01 Sound Sound Reset 0x09 0x00 0x00 Reset 3D Audio 0x0a 0x00 0x00 0x01...

  • Page 70: Updating The Tv's Software

    4. Troubleshooting 4-7. Updating the TV’s Software • MENU/123 > MENU > Support > Software Update You can view your TV’s software version and update it if necessary. Updating the TV’s software to the latest version „ • MENU/123 > MENU >...

  • Page 71: Wiring Diagram

    5. Wiring Diagram 5. Wiring Diagram 5-1. Wiring Diagram 78" „ One Connect Mini CN901 LD Board BL LED BL LED CNL802B CNL803A CN803 CNL802A CNL803B CN900B CN9003 SMPS CN1301 CN201 CNM803 CN803 TV Board CN400 CNT804 CN2301 CN801 CN800 CN2201 CN1302 CN501_7.5K...

  • Page 72: Connector

    5. Wiring Diagram 5-2. Connector Main Board „ CN1502_RS 12 CN1301(BT/WIFI) CN1901(USB) 11 CN201(POWER Connector) CN2201(OCM) 10 CN2301(LVDS) CN1201(LAN) CN602(COMPONENT) CN603(AV) CN1501 9 CN502_7K(AUDIO)/ CN501_7.5K(AUDIO) 8 CN1302(IR&FUNCTION) Main Board Pin Map „ CN1502_RS CN1901(USB) DGND A5V_USB1_PW USB1RX+_USB30 EXLINK_TX USB-_USB30 EXLINK_RX DGNG USB+_USB30 USB1TX-_USB30...
  • Page 73 5. Wiring Diagram CN2201(OCM) CN602(COMPONENT) HDMI1_RX2+_ TEST_PB SW_POWER HDMI COMP_Y_CVBS TEST_PR IDENT_OCM A5V_PW COMP_PB COMP_PR USB1+_USB IDENT_COMP HDMI1_SDA_DDC_ USB1-_USB CN603(AV) HDMI1_SCL_DDC_ TEST_SR A3.3V_PW AV1_CVBS_IN TEST_SL USB2+_USB COMP_AV2_SR_IN COMP_AV2_SL_IN USB2-_USB IDENT_VIDEO HDMI1_RX_CLK-_ HDMI CN1501 HDMI1_RX_CLK+_ TEST_SR OCM_SCL_I2C HDMI MAX_IN IDENT_HP OCM_SDA_I2C MAX_OUT HDMI1_RX0-_HDMI TEST_SL...
  • Page 74 5. Wiring Diagram CN2301(LVDS) CN201(POWER Connector) DGND M_C_RX-_VBY1 ANA_DIMMING SDA_FRC_I2C VBY1_GND AGING_ENABLE M_B_RX+_VBY1 A13V_PW OVD_LEVEL SCL_FRC_I2C M_B_RX-_VBY1 A13V_PW BT_SYNC/PWM_ A13V_PW VBY1_GND SW_POWER_OUT A13VS_PW SDA_TCON_I2C M_A_RX+_VBY1 A13V_PW TCON_I2C_EN M_A_RX-_VBY1 B5V_PW A13VS_PW SCL_TCON_I2C VBY1_GND A13V_PW DGND LOCKN_TX_VBY1 OVD_ON_OFF A13VS_PW VBY1_GND SMPS_FET_FAIL_ M_H_RX+_VBY1 VBY1_GND DETECT M_H_RX-_VBY1...
  • Page 75 5. Wiring Diagram SMPS Board „ CN803 CNM803 CNT804 AC Power Connector...
  • Page 76 5. Wiring Diagram SMPS Board Pin Map „ CN803 CNT804 B13V B13V B13V B13V Vdrv B13V Vdrv B13V B13V CNM803 B13V A5.3V A5.3V B13V Power On/Off B13V B13V FAIL COUNT B13V Vamp B13V B13V Vamp B13V Vamp...
  • Page 77 5. Wiring Diagram LD Board „ 6 CNL803A 1 CNL802B 2 CNL802A 5 CNL803B 4 CN900B 3 CN9003 LD Board Pin Map „ CNL802B CN9003 T11+ PWM4 T21+ T13+ OD_On/Off PWM12 T11- T23+ BLU_On/Off PWM3 T21- T13- ANA_DIM T12+ T23- OD_Level T22+ T14+...
  • Page 78 5. Wiring Diagram CN900B CNL803A Vdrv T41- Vdrv T31- T43- Vdrv T41+ T33- T31+ T43+ Vdrv T42- T33+ Vdrv T32- T44- Vdrv T42+ T34- Vdrv B13V T32+ T44+ Vdrv T34+ Vdrv Vdrv CNL803B B13+ B22- B24- B12- B14- B22+ B24+ B12+ B14+ B21-...
  • Page 79 5. Wiring Diagram UFT Board (T-CON) „ 1 U2 2 U1 3 CON_12V UFT Board (T-CON) Pin Map „ U2 (41PIN) VB1_11_TX+ VB1_15_TX- SDC_USE VB1_8_TX- VB1_15_TX+ SDC_USE VB1_8_TX+ VB1_12_TX- SDC_USE VB1_12_TX+ VB1_9_TX- Pattern check VB1_9_TX+ VB1_13_TX- Panel ratio VB1_13_TX+ SDC_USE TEMP_SEL0 VB1_10_TX- SDC_USE...
  • Page 80 5. Wiring Diagram CON_12V 12V_PW 12V_PW 12V_PW 12V_PW 12V_PW 12V_PW 12V_PW 5-10...
  • Page 81 5. Wiring Diagram One Connect Board „ CN601(USB1) CN602(USB2) CN301(HDMI1_STB) CN303(HDMI3_MHL3.0) CN412(SPDIF) CN701(OCM) CN302(HDMI2_DVI) CN304(HDMI4_ARC) One Connect Board Pin Map „ CN601(USB1) CN302(HDMI2_DVI) USB1_VCC_5V_PW JACK1_D+_USB HDMI2_RX2+_ HDMI JACK1_D-_USB HDMI2_RX_CLK-_ CN602(USB2) HDMI USB2_VCC_5V_PW JACK2_D+_USB HDMI2_RX2-_HDMI JACK2_D-_USB HDMI2_RX1+_ HDMI CN301(HDMI1_STB) HDMI2_SCL_DDC HDMI1_RX2+_ HDMI2_RX1-_HDMI HDMI2_SDA_DDC HDMI...
  • Page 82 5. Wiring Diagram CN303(HDMI3_MHL3.0) CN412(SPDIF) HDMI3_RX2+_ BOSTON_SPDIF_ DGND HDMI HDMI3_RX_CLK-_ B5V_PW HDMI CN701(OCM) HDMI3_RX2-_HDMI SW_POWER_OUT HDMI1_TX2+_HDMI HDMI3_RX1+_ HDMI DGND (OCM JACK CEC_A5V_PW HDMI3_SCL_DDC HUB1_D+_USB HDMI3_RX1-_HDMI HDMI3_SDA_DDC HDMI1_TX_SDA_ HDMI3_RX0+_ HUB1_D-_USB HDMI HDMI1_TX_SCL_ HDMI3_5V_PW HDMI3_RX0-_HDMI HDMI3_HOT_PLUG HUB2_D+_USB HDMI3_RX_CLK+_ HUB2_D-_USB HDMI HDMI_TX_CLK-_ CN304(HDMI4_ARC) HDMI HDMI4_RX2+_ HDMI_TX_CLK+_...

  • Page 83: Annex. Exploded View & Part List [Un78Js8600Fxza-Th01]

    ANNEX. Exploded View & Part List ANNEX. Exploded View & Part List [UN78JS8600FXZA-TH01] 1-1. Exploded View ANNEX-1...

  • Page 84: Parts List

    ANNEX. Exploded View & Part List 1-1-1. Parts List Code No. Description & Specification Q’ty SA/SNA Remark BN95-02393A PRODUCT LCD-SDC; CY-QJ078FLLV1V/H,JS8600, BN96-38389A ASSY COVER P-FRAME TOP; JS8600 78,AI,Cr P BN96-38387A ASSY COVER P-FRAME BOTTOM; JS8600 78,PC+A BN96-38321A ASSY SPEAKER P; 6ohm,8pin,15W,JS8600 78" BN44-00857A DC VSS-LED TV PD BD;...

  • Page 85: Electrical Parts List

    ANNEX. Exploded View & Part List 2-1. Electrical Parts List Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE) Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark UN78JS8600FXZA (TH01) BN90-06495S ASSY W/I;J5000 BN81-08159Z PART SET-ELEC W/I;UF**,UH**,UG**,ELEC BN81-12183B A/S PART SET-MECH W/I;UJ8X,U78JX* BN90-07737A ASSY COVER REAR-REAR;JS8600 78...
  • Page 86 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 BN63-14446A COVER-STAND FRONT;JS8600 78",ABS+PC,V0,B BN96-38203A ASSY STAND P-BASE SEMI;JU7000,75",W/W ...4 SCREW 6003-001001 SCREW-TAPTYPE;FH,+,-,B,M3,L8,ZPC(BLK),SW ...4 SCREW 6003-001321 SCREW-TAPTYPE;BH,+,B,M4,L8,ZPC(BLK),SWRC ...4 SCREW 6003-001374 SCREW-TAPTYPE;FH,+,B,M4,L12,NI PLT,SWRCH ...4 BN60-00162A SPACER-FOAM;FOAM,50000L,BLK,0.35T,20W...
  • Page 87 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..5 BN60-00162C SPACER-FOAM;FOAM,50000mm,DARK GRAY,0.5T, ..5 BN60-00972A SPACER-FRAME;Y14 SNB,U8.5K,PC,21.4,WHITE ..5 BN60-01127E SPACER-RUBBER-LGP;78JS8600,RUBBER,9,GRAY ..5 BN61-10711A HOLDER-RIVET;Y14 VDTV H8000 U9000 55 65, ..5 BN61-10712A HOLDER-WALL RIVET;Y14 VDTV H8000 U9000,S ..5 BN61-12234A HANGER-QD;JQ9000 78",PC,PC GF10...
  • Page 88 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 BN63-10029B SHEET-COVER;JN9000,PET,0.052,W22mm,100M, ...4 BN64-02130J BADGE-BRAND;JS9000,Ni,0.05,30.0,DARK SIL ...4 BN64-03143A BADGE-UHD;JS9000,NI,0.09,19.99,Dark Silv ...4 AC157 BN64-03213A CHASSIS-TOP;JS8600 78",STS,T0.6,Silver,F BN96-38196A ASSY COVER P-SOURCE PCB R;JS8500 78,EGI- ...4 BN62-00650X INSULATION-SOURCE_COVER R;PET,0.1,30,870...
  • Page 89 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 1203-007694 IC-DC/DC CONVERTER;SN1106041DDAR,DDA,8Z3 ...4 1203-008023 IC-POSI.ADJUST REG.;AOZ2003PI,SO-8,8P,4..4 1203-008082 IC-DC/DC CONVERTER;TPS54627DDAR,SOP 8P,8 ...4 1203-008104 IC-POSI.FIXED REG.;S-13A1D18-E800,HSOP,8 ...4 1203-008183 IC-DC/DC CONVERTER;AOZ3015PI-1,EPAD SO-8 ...4 1203-008392 IC-VOL.
  • Page 90 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 2007-008137 R-CHIP;24Kohm,1%,1/16W,TP,1005 ...4 2007-008298 R-CHIP;49.9ohm,1%,1/16W,TP,1005 ...4 2007-008485 R-CHIP;22ohm,1%,1/16W,TP,1005 ...4 2007-008779 R-CHIP;0ohm,1%,1/16W,TP,1005 ...4 2007-009117 R-CHIP;49.9Kohm,1%,1/16W,TP,1005 ...4 2007-009777 R-CHIP;4.99Kohm,1%,1/16W,TP,1005 ...4 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 ...4 2011-001587 R-NETWORK;100ohm,5%,1/16W,L,CHIP-V,4P,TP ...4 AD480...
  • Page 91 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 2801-004477 CRYSTAL-SMD;24.576MHz,20ppm,SMD,18pF,20o ...4 3301-001364 BEAD-SMD;1000ohm,1608,TP,1085ohm/108MHz, ...4 3601-001374 FUSE-SURFACE MOUNT;32V,5A,FAST-ACTING,PL ...4 3710-004015 CONNECTOR-SOCKET;33P,1R,0.5mm,SMD-A,AU,B ...4 EH01 3711-008422 HEADER-BOARD TO CABLE;BOX,9P,1R,1.25mm,S ...4 EH01 3711-008454 HEADER-BOARD TO CABLE;BOX,22P,2R,2mm,ANG ...4 EH01 3711-008659...
  • Page 92 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 ...4 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 ...4 2007-000239 R-CHIP;1.5Kohm,1%,1/10W,TP,1608 ...4 2007-000614 R-CHIP;24Kohm,1%,1/10W,TP,1608 ...4 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 ...4 2007-007132 R-CHIP;15Kohm,1%,1/16W,TP,1005 ...4 2007-007135 R-CHIP;18Kohm,1%,1/16W,TP,1005 ...4 2007-007136 R-CHIP;4.7Kohm,1%,1/16W,TP,1005 ...4 2007-007138...
  • Page 93 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 3708-003073 CONNECTOR-FPC/FFC/PIC;51P,0.5mm,SMD,AU,N ...4 3708-003183 CONNECTOR-FPC/FFC/PIC;41P,0.5mm,SMD-A,AU ...4 EH01 3711-008098 HEADER-BOARD TO CABLE;BOX,20P,1R,1.25mm, ...4 6302-001290 GASKET;SMR-TS-4-4.5-3,4.0mm,Ni+Au+SUS+Mg ...4 BN41-02319A PCB MAIN;hawk_ufp(4k),FR-4,4,1.2T,123*16 ...4 BN68-04746A LABEL-SMD;all model,POLY*,25.4mm x 9.53m ...4 BN97-09538A ASSY MICOM-SPI;FRC_SPI_9K,JS9000,W25Q32F...
  • Page 94 BATTERY-ALKALINE;1.5V,1650mAH,LR6,14.5x5 EC08 BN39-01154C CBF SIGNAL;Chelsea Slim, STEREO Plug to EC07 BN39-01154H CBF SIGNAL;UE40B7000WWXXC,3P RCA,30AWG,1 REMOCON-15SMART REMOCON BN59-01220A CONTROL;TM1560,18,70mA,3 BN68-04972E LEAFLET-04,REGULATORY GUIDE;ALL,SAMSUNG, BN68-05723A LABEL-ACCESSORY;ALL MODELS,YUPO,0.2,20,7 BN68-07154F MANUAL USERS;JS8600,United States,W/P* BN68-07429B LEAFLET-RMH GUIDE;Common,ZA,W/P* BN69-08751A WRAP VINYL-SHRINK;STAND,PLASTIC OTHERS,P BOX ACCESSORY;H8000_ACCESSORY,CB,SERP BN69-10158A BN69-10161A PAD-TYPE;H8000_ACCESSORY,CB,SERP Recycle PAD ACCESSARY;JQ8500 ACCESSORY-BOX-...
  • Page 95 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark BN92-19140E ASSY BOX;J8000 BH68-00697A LABEL BOX-00;ALL MODEL,ART PAPER 90G,60, BN69-12581B BOX UNIT-01,OUT;78JS8600-TS,CB,C3,DW4,YE BN69-12582A BOX UNIT-IN;78JS8500-TS,CB,C1,DW1,YEL,W2 ANNEX-13...
