Summary of Contents for H3C S7500 Series
- Page 1 H3C S7500 Series Ethernet Switches Memory Upgrade Kit Hangzhou H3C Technologies Co., Ltd. http://www.h3c.com Manual Version: T2-080718-20070521-C-1.01...
- Page 2 Copyright © 2006-2007, Hangzhou H3C Technologies Co., Ltd. All Rights Reserved No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of Hangzhou H3C Technologies Co., Ltd. Trademarks H3C,...
- Page 3 Environmental Protection This product has been designed to comply with the requirements on environmental protection. For the proper storage, use and disposal of this product, national laws and regulations must be observed.
- Page 4 H3C S7500 Series Ethernet Switches Memory Upgrade Kit Table of Contents Chapter 1 Memory Upgrade Kit for H3C S7500 Series Ethernet Switches ..................1-1 1.1 Memory Specifications ............1-1 1.2 About Memory Upgrade.............1-2 1.3 Installing and Removing a Memory Module.......1-2 1.4 Precautions ................1-4...
- Page 5 H3C S7500 Series Ethernet Switches Memory Upgrade Kit Chapter 1 Memory Upgrade Kit for H3C S7500 Series Ethernet Switches 1.1 Memory Specifications Table 1-1 lists the general memory specifications for H3C S7500 series Ethernet switches. Table 1-1 Memory specifications Item...
- Page 6 H3C S7500 Series Ethernet Switches Memory Upgrade Kit Figure 1-1 Appearance of a memory module 1.2 About Memory Upgrade A memory module is a card component in a switch. You can upgrade or replace a memory module as required.. Generally, you...
- Page 7 H3C S7500 Series Ethernet Switches Memory Upgrade Kit Figure 1-2 Remove memory module from the slot Follow the steps below to install a memory module: Step 1: Place the card horizontally. Align the contact fingers of the memory module with the memory slot on the card and align the module with the keyed plastic bridge in the slot.
- Page 8 Hold the memory module by its edge and avoid touching any component on its surface. An improper operation might result in damage. Caution: Use a memory module provided by Hangzhou H3C Technologies only. Otherwise, anomalies might occur to the device.
