Installation and Operation Manual
Condensing Units
Models
A4AC6036B1000A
A4AC6037B1000A
A4AC6042B1000A
A4AC6060B1000A
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating,
and air-conditioning equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or
altered equipment by an unqualified person could result in death or serious injury. When working on the equipment, observe all pre-
cautions in the literature and on the tags, stickers, and labels that are attached to the equipment.
May 2022
A4AC6018A1000A
A4AC6024A1000A
A4AC6030A1000B
A4AC6031A1000A
A4AC6036A1000A
A4AC6037A1000A
A4AC6042A1000A
A4AC6048A1000A
A4AC6060A1000A
88-A4AC6001-1F-EN
Note: "Graphics in this document are for representation only.
Actual model may differ in appearance."
SAFETY WARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A4AC6036B1000A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Trane A4AC6036B1000A

Summary of Contents for Trane A4AC6036B1000A

  • Page 1 Installation and Operation Manual Condensing Units Models A4AC6036B1000A A4AC6018A1000A A4AC6037B1000A A4AC6024A1000A A4AC6042B1000A A4AC6030A1000B A4AC6060B1000A A4AC6031A1000A A4AC6036A1000A A4AC6037A1000A A4AC6042A1000A A4AC6048A1000A A4AC6060A1000A Note: “Graphics in this document are for representation only. Actual model may differ in appearance.” SAFETY WARNING Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.

  • Page 2: Section 1. Safety

    Section 1. Safety IMPORTANT — This Document is customer property WARNING and is to remain with this unit. Please return to service Extreme caution should be exercised when opening information pack upon completion of work. the Liquid Line Service Valve. Turn counterclockwise WARNING until the valve stem just touches the rolled edge.

  • Page 3: Table Of Contents

    Table of Contents Section 1. Safety ................................2 Section 2. Unit Location Considerations ........................4 Section 3. Unit Preparation............................5 Section 4. Setting the Unit ............................6 Section 5. Refrigerant Line Considerations ........................ 6 Section 6. Refrigerant Line Routing ..........................8 Section 7.

  • Page 4: Section 2. Unit Location Considerations

    Section 2. Unit Location Considerations 2.1 Unit Dimensions and Weight Table 2.1 Unit Dimensions and Weight Models H x D x W (in) Weight* (lb) A4AC6036B 29 x 30 x 33 A4AC6037B 37 x 34 x 37 A4AC6042B 37 x 34 x 37 A4AC6060B 45 x 34 x 37 A4AC6018A...

  • Page 5: Section 3. Unit Preparation

    2.3 Suggested Locations for Best Reliability Ensure the top discharge area is unrestricted for at least five (5) feet above the unit. Avoid Install Near Bedrooms Three (3) feet clearance must be provided in front of the control box (access panels) and any Min 5’...

  • Page 6: Section 4. Setting The Unit

    Section 4. Setting the Unit 4.1 Pad Installation When installing the unit on a support pad, such as a concrete slab, consider the following: • The pad should be at least 1” larger than the unit on all sides. • The pad must be separate from any structure. •...
  • Page 7 5.3 Required Refrigerant Line Length Determine required line length and lift. You will need this later in STEP 2 of Section 14. Total Line Length = __________ Ft. Line Length Total Vertical Change (lift) = __________ Ft. 5.4 Refrigerant Line Insulation Important: The Vapor Line must always be Vapor Line insulated.

  • Page 8: Section 6. Refrigerant Line Routing

    Section 6. Refrigerant Line Routing 6.1 Precautions Important: Take precautions to prevent noise Comply with National, State, and Local Codes when within the building structure due to vibration isolating line sets from joists, rafters, walls, or other transmission from the refrigerant lines. structural elements.

  • Page 9: Section 7. Refrigerant Line Brazing

    Wall Sealant Ductwork Insulation Vapor Line Isolator Line Set Isolation Through Wall DO NOT hang line sets from ductwork Section 7. Refrigerant Line Brazing 7.1 Braze The Refrigerant Lines STEP 1 - Remove caps or plugs. Use a deburing tool to debur the pipe ends. Clean both internal and external surfaces of the tubing using an emery cloth.
  • Page 10 STEP 3 - Purge the refrigerant lines and indoor coil with dry nitrogen. STEP 4 - Wrap a wet rag around the valve body to avoid heat damage and continue the dry nitro- gen purge. Braze the refrigerant lines to the service valves. Continue the dry nitrogen purge.

  • Page 11: Section 8. Refrigerant Line Leak Check

    Section 8. Refrigerant Line Leak Check 8.1 Check For Leaks STEP 1 - Pressurize the refrigerant lines and 150 PSIG evaporator coil to 150 PSIG using dry nitrogen. STEP 2 - Check for leaks by using a soapy solu- tion or bubbles at each brazed location. Remove nitrogren pressure and repair any leaks before continuing.

  • Page 12: Section 10. Service Valves

    STEP 2 - Observe the micron gauge. Evacuation is complete if the micron gauge does not rise above 500 microns in one (1) minute. 1 MIN. Once evacuation is complete blank off the vacuum pump and micron gauge, and close the valves on the manifold gauge set.

  • Page 13: Section 11. Electrical - Low Voltage

    Section 11. Electrical - Low Voltage 11.1 Low Voltage Maximum Wire Length Table 11.1 defines the maximum total length of Table 11.1 low voltage wiring from the outdoor unit, to the 24 VOLTS indoor unit, and to the thermostat. WIRE SIZE MAX.
  • Page 14 With Furnace With Variable Speed Furnace Outdoor Outdoor Thermostat Furnace Thermostat Furnace Unit Unit 24 VAC HOT 24 VAC HOT 24 VAC 24 VAC Common Common COOL COOL HEATING HEATING • Units with pigtails require wirenuts for connections. Cap all unused wires. •...

  • Page 15: Section 12. Electrical - High Voltage

    Section 12. Electrical - High Voltage 12.1 High Voltage Power Supply WARNING LIVE ELECTRICAL COMPONENTS! During installation, testing, servicing, and troubleshooting of this product, it may be nec- essary to work with live electrical components. Failure to follow all electrical safety precautions when exposed to live electrical components could result in death or serious injury.

  • Page 16: Section 13. Start Up

    Section 13. Start Up 13.1 System Start Up STEP 1 - Ensure Sections 7 through 12 have been completed. STEP 2 - Set System Thermostat to OFF. DONE CANCEL STEP 3 - Turn on disconnect(s) to apply power to the indoor and outdoor units. STEP 4 - Wait one (1) hour before starting the unit if compressor crankcase heater acces- sory is used and the Outdoor Ambient is below...

  • Page 17: Section 14. System Charge Adjustment (Systems Can Be Rated With Txv, Eev Or Piston)

    Section 14. System Charge Adjustment (Systems can be rated with TXV, EEV or Piston) NOTE: For systems using a indoor piston metering device, refer to the Superheat charging method and chart. For systems using a TXV or EEV indoor metering device, refer to Subcool charging method and charts. 14.1 Temperature Measurements STEP 1 - Check the outdoor temperatures.
  • Page 18 STEP 2 - Determine the final subcooling value using total Line Length and Lift measured in STEP 1 and the charts below. 1 1/2 Ton 2 Ton SUBCOOL CHARGING CHART CORRECTIONS TABLE (FOR LINE LENGTH AND RISE) SUBCOOL CHARGING CHART CORRECTIONS TABLE (FOR LINE LENGTH AND RISE) Add 3°...
  • Page 19 STEP 4 - Measure the liquid line temperature and pressure at the outdoor unit’s service valve. Measured Liquid Line Temp = __________ º F Liquid Gage Pressure = __________ PSI Final Subcooling Value = __________ º F 107 °F STEP 5 - Use the final subcooling value, refriger- Table 14.2 ant temperature and pressure from STEP 4, to R-410A REFRIGERANT CHARGING CHART...
  • Page 20 STEP 6 - Adjust refrigerant level to attain proper gage pressure. Add refrigerant if the Liquid Gage Pressure is lower than the chart value. 1. Connect gages to refrigerant bottle and unit as illustrated. 2. Purge all hoses. 3. Open bottle. 107 °F 4.
  • Page 21 Fixed Orifice Superheat Charging Table Indoor Wet Bulb Temp (F) Outdoor Bulb Temp. Using a digital psychrometer, measure the return air wet-bulb temperature at the unit just before the coil. Also measure the outdoor dry-bulb tem- perature. Use these temperatures to locate the target superheat on the charging table. Do not attempt to charge the system if these conditions fall outside of this charging table.

  • Page 22: Section 15. Checkout Procedures

    STEP 9 - Record System Information for refer- ence. Record system pressures and temperatures after charging is complete. Measured Suction Line Temp = __________ º F Outdoor model number = _________________ Liquid Gage Pressure = __________ PSI Measured Outdoor Ambient = __________ º F Measured Indoor Ambient = __________ º...

  • Page 23: Section 16. Refrigerant Circuits

    Section 16. Refrigerant Circuits 1 1/2-Ton Units PRINTED FROM D158513P01 2 & 3-Ton Units PRINTED FROM D157394P01 88-A4AC6001-1F-EN...
  • Page 24 2 1/2-Ton Units Accumulator 3 1/2 & 4-Ton Units PRINTED FROM D158514P01 88-A4AC6001-1F-EN...
  • Page 25 5-Ton Units PRINTED FROM D158515P01 88-A4AC6001-1F-EN...

  • Page 26: Section 17. Wiring Diagrams

    Section 17. Wiring Diagrams 036B - 060B Models 018A - 048A Models 88-A4AC6001-1F-EN...
  • Page 27 036B - 060B Models 018A - 048A Models 88-A4AC6001-1F-EN...
  • Page 28 060A Models 88-A4AC6001-1F-EN...
  • Page 29 060A Models 88-A4AC6001-1F-EN...

  • Page 30: Section 18. Pressure Curves

    Section 18. Pressure Curves PRESSURE CURVES (Refer below table for models) INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM 71, 67, 63 AND 59 DEG F. Cooling OD Model @SCFM 1000 A4AC6036B1 OUTDOOR TEMPERATURE (Degree F) A4AC6037B1 A4AC6042B1 1250 INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM 71, 67, 63 AND 59 DEG F.
  • Page 31 PRESSURE CURVES (Refer below table for models) INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM 71, 67, 63 AND 59 DEG F. Cooling OD Model @SCFM OUTDOOR TEMPERATURE (Degree F) 1450 A4AC6060B1 INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM 71, 67, 63 AND 59 DEG F.
  • Page 32 PRESSURE CURVES (Refer below table for models) INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM 71, 67, 63 AND 59 DEG F. Cooling OD Model @SCFM OUTDOOR TEMPERATURE (Degree F) A4AC6018A1 INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM 71, 67, 63 AND 59 DEG F. OUTDOOR TEMPERATURE (Degree F) COOLING PERFORMANCE CAN BE CHECKED WHEN THE OUTDOOR TEMP IS ABOVE 65 DEG F.
  • Page 33 PRESSURE CURVES (Refer below table for models) INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM 71, 67, 63 AND 59 DEG F. Cooling OD Model @SCFM A4AC6024A1 OUTDOOR TEMPERATURE (Degree F) A4AC6030A1 INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM 71, 67, 63 AND 59 DEG F.
  • Page 34 PRESSURE CURVES (Refer below table for models) INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM 71, 67, 63 AND 59 DEG F. Cooling OD Model @SCFM A4AC6031A1 OUTDOOR TEMPERATURE (Degree F) 1000 A4AC6036A1 A4AC6037A1 INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM 71, 67, 63 AND 59 DEG F.
  • Page 35 PRESSURE CURVES (Refer below table for models) INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM 71, 67, 63 AND 59 DEG F. Cooling OD Model @SCFM OUTDOOR TEMPERATURE (Degree F) 1250 A4AC6042A1 A4AC6048A1 1400 INDOOR ENTERING WET BULB CURVES A4AC6060A1 1450 TOP TO BOTTOM 71, 67, 63 AND 59 DEG F.
  • Page 36 About Trane and American Standard Heating and Air Conditioning Trane and American Standard create comfortable, energy efficient indoor environments for residential applications. For more information, please visit www.trane.com or www.americanstandardair.com The AHRI Certified mark indicates company participation in the AHRI Certification program. For verification of individual certified products, go to ahridirectory.org.
