Instruction Manual for Viewfinder Collar
Adaptor for 32211/2/3/4 to use with MIL
F
OREWORD
Thank you for your purchase of a NAUTICAM product.
At NAUTICAM, we pride ourselves in the ability to recognise the requirements
of professional as well as amateur underwater photographers and fulfill them
through the innovative designs of our products. We strive to achieve a high
level of user-friendliness by allowing stress-free installation and easy operation
of all important functions of the camera.
Each product is individually inspected and water pressure tested to ensure
optimum quality.
Please read this manual carefully before using the product, this will maximise
its performance as well as its lifetime.
W
ARRANTY
All NAUTICAM Products are warranted against any material and
manufacturing defects for two years from the date of purchase for consumer
use. This warranty only applies to products purchased from authorised
NAUTICAM dealers and does not extend beyond the original retail purchaser.
To return your product for service, please contact your regional authorized
service centre(s). Please note that this warranty only applies when the product
is purchased in the territory where the service centre is located.
NAUTICAM does not hold responsibility for damage, of any nature, to any
equipment used with and/or placed within our products.
NAUTICAM accepts no liability for any loss of captured images or the
inability to capture images even if it is due to the malfunctioning of our
products.
Unauthorised modifications and/or repairs of our products will automatically
invalidate the warranty.
I
DENTIFICATION OF
Sealing O-rings (2x)
Alignment Groove
Spare Sealing O-rings (2x)
Housings
P.N. 32215
P
ARTS
M3 Screws (4x)
Screw Caps (2x)
R
EMOVE THE
Unlock and remove the four S.S. screws from viewfinder body as shown.
Retainer O-ring
Guiding Pin
Points (2x)
Remove the two screw cap covers, and install one of the existing screws to
push and separate the collar from the viewfinder body.
Spare Retainer O-ring
O
C
32211/2/3/4
LD
OLLAR FROM
