- Page 1 Tecal 140H Calibrators Operator's Manual Issue 6 Date of issue: 3rd May 2005 Techne is a trademark © Techne, 2003...
-
Page 3: Table Of Contents
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L CONTENTS Hi-Spec Dri-Block Calibrator Operator’s Manual ® page SAFETY AND INSTALLATION English Français Deutsch Español THE CALIBRATOR Applications Warning... - Page 4 T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L PAGE 2...
- Page 5 T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L NOTES PAGE 3...
-
Page 6: English
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L Introduction After use Please read all the information in this booklet before using When you have finished heating samples, remember that the unit. -
Page 7: Français
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L Introduction Les symboles ci-dessous situés à côté des témoins lumineux sur la face avant de l’appareil ont la Veuillez lire attentivement toutes les instructions de ce signification suivante : document avant d’utiliser l’appareil. -
Page 8: Deutsch
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L Einleitung Nach dem Gebrauch Bitte lesen Sie diese Bedienungsanleitung komplett bevor Vergessen Sie nicht, daß Teile des Gerätes (die Gefäße, Sie dieses Gerät benutzen. -
Page 9: Español
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L Introducción 5. Los símbolos, que pueden aparecer junto a las luces indicadoras en el panel frontal del equipo, tienen los Le rogamos lea cuidadosamente la información contenida siguientes significados: en este folleto antes de manipular el aparato. -
Page 10: The Calibrator
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L INTRODUCTION Before using the Tecal Calibrator, make sure you have read this manual carefully. If you have any queries, contact your supplier. The Tecal Calibrator is designed to provide safe and convenient calibration of a wide range of thermal sensors. -
Page 11: Warning
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L Programs that are created and saved on th calibrator can be modified and deleted from the calibrator or from a PC. Data that is saved on the calibrator can be created only whilst running a program from the calibrator. -
Page 12: Specification
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L Specification The figures stated in the specification are as measured 0-50 mm from the base of the well of the insert, using an SPRT, at the time of calibration. Measuring zone 0 to 50 mm 0"... -
Page 13: The Front Panel
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L THE FRONT PANEL The control panel of the Tecal units consists of a membrane keypad, an alphanumeric LCD panel, an LED display and three LEDs. -
Page 14: Front Panel Controls
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L The Front Panel Controls The ESC key " ENTER ABCD EFGH IJKL ON/OFF PAUSE MNOP QRSTU VWXYZ (0-9) - Page 15 T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L The ON/OFF key " ENTER ABCD EFGH IJKL ON/OFF PAUSE MNOP QRSTU VWXYZ (0-9) The ON/OFF key allows the operator to start or stop the unit in Manual Mode or stop a program in Program Mode.
- Page 16 T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L Power Indicator The top indicator shows that there is power to the unit Power to the Block Indicator The next indicator shows when there is power to the block.
-
Page 17: When You Switch On
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L When you Switch On When you first switch on, the display will show a choice of options. MAIN MENU manual mode program mode... -
Page 18: Manual Mode
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L MANUAL MODE To go into the Manual Mode, use the # # # # # key to put the cursor on manual mode then press the ENTER key. -
Page 19: Program Mode
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L PROGRAM MODE To go into the Program Mode, use the # # # # # key to put the cursor on program mode then press the ENTER key. -
Page 20: New Program
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L New Program If you have chosen New Program the following screen will appear NEW PROGRAM name: _ _ _ _ _ _ _ _ Use the keys with letters beneath them to enter the name of the program... -
Page 21: Program Running Display
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L Program Running Display The Display will automatically go into the the program running display as described earlier. -
Page 22: Switch Test
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L Switch Test The switch test indicates the switch point temperature of a thermostat by detecting the making or breaking of the circuit made by the contacts of the thermostat. -
Page 23: Program Delete
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L Program Delete PROGRAM MODE run program new program delete program To go into the Program Delete Mode from the Program Mode screen, use the # # # # # key to put the cursor on delete program then press the ENTER key. -
Page 24: Water Cooling
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L Water Cooling An extended temperature range to -40°C can be achieved on the Tecal 140 unit with a 4°C chilled water supply. -
Page 25: Rs232 Serial Interface
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L RS232 SERIAL INTERFACE The calibrator may send data logging information to an IBM PC or compatible computer by connecting the unit and the PC via an RS232 cable, and installing the "Calsoft"... -
Page 26: Technical Information
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L TECHNICAL INFORMATION Brief fault finding notes and lists of replacement parts, accessories and inserts for the Tecal units are given in this section. NOTE THAT THIS EQUIPMENT SHOULD ONLY BE DISMANTLED BY PROPERLY TRAINED PERSONNEL. -
Page 27: Replacement Parts
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L Replacement parts Each unit is supplied with an extraction tool, a carrying case and a mains cable. -
Page 28: Inserts
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L Inserts Inserts are made from aluminium or aluminium-bronze and must be ordered separately from the calibrator. Each insert is stamped for identification. A blank insert is available which may be drilled to suit your application. -
Page 29: Glossary
T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L GLOSSARY Block temp. The current temperature of the heat transfer block. Cursor The flashing bar on the LCD screen which indicates where the next character is entered. - Page 30 T E C A L 1 4 0 H O P E R A T O R ’ S M A N U A L PAGE 28...
- Page 31 Thank you for reading this data sheet. For pricing or for further information, please contact us at our UK Office, using the details below. UK Office Keison Products, P.O. Box 2124, Chelmsford, Essex, CM1 3UP, England. Tel: +44 (0)330 088 0560 Fax: +44 (0)1245 808399 Email: sales@keison.co.uk...
