1x Serial port for debug, 3-pin connector
Serial
3x UART, 4-pin connectors
1x RS485, 3-pin connector
HDMI 2.0, 4Kp60
MIPI DSI/LVDS, 1080p60 (40-pin header)
Video
EDP 1.3, 2560x1600@60Hz (30-pin header)
RGB, up to 1920x1080@60Hz (40-pin FPC connector)
3.5mm audio I/O jack
8-channel audio via HDMI
Audio
SPDIF out
Speaker (2-pin connector)
MIC
Camera(optional) 2x MIPI Cameras, 24-pin FPC connector.
Keys
Recover, Reset, Power
RTC with battery connector; GPIO&I2C; CAN; Key connector(PWM3_IR/Reset /
Other features
Recover /Power)
Dimension
Based board - 135mm x 100mm; CPU module - 45mm x 60mm

2 Compiler Environment

2.1 Vmware10.0+ubuntu18.04

Install Vmware10.0 in windows OS, and then install ubuntu18.04 in VMware to compile.
official website
http://www.ubuntu.com/
Note: Debian should be complied by ubuntu 64bit OS.

2.2 Install Tools

PC OS: ubuntu system
Network: online
Permission: root
$ sudo apt-get install build-essential zlib1g-dev flex libx11-dev gperf libncurses5-dev bison lsb-core
lib32z1-dev g++-multilib lib32ncurses5-dev uboot-mkimage g++-4.4-multilib repo git ssh make gcc
libssl-dev liblz4-tool expect g++ patchelf chrpath gawk texinfo chrpath diffstat binfmt-support
qemu-user-static live-build bison flex fakeroot cmake gcc-multilib g++-multilibdevice-tree-compiler
python-pip ncurses-dev pyelftools unzip
Customize the embedded system based on
to
download and install ubuntu operating system.
5
Your Idea
