Stoane Lighting Module M Installation And Maintenance Instructions

Download this manual

Module M.pdf 1 16/04/2020 12:59:16

IMPORTANT: All wiring connections must be made before switching on mains power.

MSL Type M 8.7V

6W @ 700mA

This product should not be disposed of in your general waste

Please retain these instructions for future reference

Mike Stoane Lighting Ltd

20 Dryden Road Bilston Glen Ind Est.

Loanhead Midlothian EH20 9LZ UK

Module M

Installation and Maintenance

Instructions

Class III - Extra Low Voltage

IP66 Dust tight and protected against powerful jets of water.

European Conformity

T: +44 (0) 131 440 1313

F: +44 (0) 131 440 0049

sales@mikestoanelighting.com

www.mikestoanelighting.com

VAT No GB682885284

Limited Company 188910

Need help?

Do you have a question about the Module M and is the answer not in the manual?

Page 1 Module M.pdf 1 16/04/2020 12:59:16 Module M Installation and Maintenance Instructions IMPORTANT: All wiring connections must be made before switching on mains power. MSL Type M 8.7V 6W @ 700mA Class III - Extra Low Voltage IP66 Dust tight and protected against powerful jets of water.
Page 2 Module M.pdf 2 16/04/2020 12:59:16 Installation Electrical Supply Check that the mounting surface is suitable for the Installation must be carried out by a qualified electrician in installation of this fitting. accordance with BS 7671:2008 Wiring Regulations. 230/240V AC 50/60Hz mains supply to a suitable SELV Step 1 Make mains connections to SELV LED driver LED Driver.
Page 3 Module M.pdf 3 16/04/2020 12:59:16 2 x M6 thread at 30mm PCD To 700mA Max LED driver...
Page 4 Module M.pdf 4 16/04/2020 12:59:16 OPTIC CHANGE To change the lens fitted please follow these instructions: Step 1 Remove the heatsink by twisting the knurled end in an anti clockwise direction. Step 2 Remove bezel and carefully remove lens. Step 3 Attach new lens making sure to align the legs with the holes in the LED board.
