Stoane Lighting Mole Installation And Maintenance Instructions

IMPORTANT: All wiring connections must be made before switching on mains power.

MSL Star Oslon Square 2.9V

IP66 Dust tight and protected against powerful jets of water.

Please retain these instructions for future reference

This product should not be disposed of in your general waste

STOANE LIGHTING

Installation and maintenance

instructions

2W @ 700mA

410 381 1497 inter-lux.com answers@inter-lux.com

Inter-lux reserves the right to make technical changes without notice.

Mole

Class III - Extra-low voltage

Suitable for Exterior Use

European Conformity

Table of Contents

Need help?

Do you have a question about the Mole and is the answer not in the manual?

Page 1 Mole Installation and maintenance instructions IMPORTANT: All wiring connections must be made before switching on mains power. Class III - Extra-low voltage MSL Star Oslon Square 2.9V 2W @ 700mA IP66 Dust tight and protected against powerful jets of water.
Page 2 Dimming control circuit source must be of SELV insulation class. Ensure supply driver and connectors are housed indoors OR in a suitable IP rated enclosure STOANE LIGHTING 410 381 1497 inter-lux.com answers@inter-lux.com Inter-lux reserves the right to make technical changes without notice.
Page 3 Retaining Fin IP66 Silicone Connector 33mm To driver Install in well drained ground. Surface gradient must run away from the fitting. STOANE LIGHTING 410 381 1497 inter-lux.com answers@inter-lux.com Inter-lux reserves the right to make technical changes without notice.
Page 4 Step 4 Replace black optic holder in fitting, placing the four legs of the optic holder into the corresponding holes in the fitting, and fully tighten bezel Replacement Optic Old Optic STOANE LIGHTING 410 381 1497 inter-lux.com answers@inter-lux.com Inter-lux reserves the right to make technical changes without notice.
