  • Page 1 Lenovo V17 Gen 3 Hardware Maintenance Manual...
  • Page 2 First Edition (April 2022) © Copyright Lenovo 2022.

  • Page 3: Table Of Contents

    Remove the 3-cell battery pack(for models without storage drive)... Trademarks ....lxiii © Copyright Lenovo 2022...
  • Page 4 Lenovo V17 Gen 3 Hardware Maintenance Manual...

  • Page 5: About This Manual

    Important: • This manual is intended only for trained service technicians who are familiar with Lenovo products. • Before servicing a Lenovo product, be sure to read all the information under Chapter 1 “Safety information” on page 1. © Copyright Lenovo 2022...
  • Page 6 Lenovo V17 Gen 3 Hardware Maintenance Manual...

  • Page 7: Chapter 1. Safety Information

    • Do not work alone under hazardous conditions or near equipment that has hazardous voltages. • Disconnect all power before: – Performing a mechanical inspection – Working near power supplies © Copyright Lenovo 2022...

  • Page 8: Safety Inspection Guide

    This guide addresses only those items. You should use good judgment to identify potential safety hazards due to attachment of non-Lenovo features or options not covered by this inspection guide.

  • Page 9: Handling Devices That Are Sensitive To Electrostatic Discharge

    4. Check for cracked or bulging batteries. 5. Remove the cover. 6. Check for any obvious non-Lenovo alterations. Use good judgment as to the safety of any non-Lenovo alterations. 7. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.

  • Page 10: Grounding Requirements

    The safety notices in this section are provided in the following languages: • English • Arabic • Brazilian Portuguese • French • German • Hebrew • Japanese • Korean • Spanish • Traditional Chinese DANGER DANGER DANGER Lenovo V17 Gen 3 Hardware Maintenance Manual...
  • Page 11 DANGER DANGER DANGER DANGER DANGER Chapter 1 Safety information...
  • Page 12 Lenovo V17 Gen 3 Hardware Maintenance Manual...
  • Page 13 PERIGO PERIGO PERIGO Chapter 1 Safety information...
  • Page 14 PERIGO PERIGO PERIGO PERIGO PERIGO Lenovo V17 Gen 3 Hardware Maintenance Manual...
  • Page 15 DANGER DANGER DANGER DANGER Chapter 1 Safety information...
  • Page 16 DANGER DANGER DANGER DANGER VORSICHT Lenovo V17 Gen 3 Hardware Maintenance Manual...
  • Page 17 VORSICHT VORSICHT VORSICHT VORSICHT Chapter 1 Safety information...
  • Page 18 VORSICHT VORSICHT VORSICHT Lenovo V17 Gen 3 Hardware Maintenance Manual...
  • Page 19 Chapter 1 Safety information...
  • Page 20 Lenovo V17 Gen 3 Hardware Maintenance Manual...
  • Page 21 Chapter 1 Safety information...
  • Page 22 Lenovo V17 Gen 3 Hardware Maintenance Manual...
  • Page 23 Chapter 1 Safety information...
  • Page 24 Lenovo V17 Gen 3 Hardware Maintenance Manual...
  • Page 25 Chapter 1 Safety information...
  • Page 26 Lenovo V17 Gen 3 Hardware Maintenance Manual...

  • Page 27: Chapter 2. General Checkout

    • Scratched (cosmetic) parts • Distortion, deformation, or discoloration of the cosmetic parts • Plastic parts, latches, pins, or connectors that have been cracked or broken by excessive force • Damage caused by liquid spilled into the system © Copyright Lenovo 2022...

  • Page 28: Cru List

    • Check for obvious damage to a hard disk drive. If the spindle of a hard disk drive becomes noisy, the hard disk drive might have been dropped or subject to excessive force. CRU list Table 1. Model: Lenovo V17 G3 IAP (Machine type: 82U1) Type ac power adapter...

  • Page 29: Chapter 3. Identifying Frus (Crus)

    Chapter 3. Identifying FRUs (CRUs) Locate FRUs and CRUs The exploded illustrations help Lenovo service technicians identify FRUs or CRUs that they may need to replace when servicing a customer’s computer. Figure 1. Exploded view © Copyright Lenovo 2022...
  • Page 30 2280 solid-state drive thermal pad* 2242 solid-state drive* 2242 solid-state drive thermal pad* 2242 solid-state drive bracket* Wi-Fi card Touch pad cable System board Screw kit Power cord ac power adapter * for selected models Lenovo V17 Gen 3 Hardware Maintenance Manual...
  • Page 31 Figure 2. LCD unit exploded view Table 3. FRU (CRU) categories for LCD unit FRU (CRU) category LCD bezel Microphone rubbers Camera board Stripe covers LCD cover EDP cable LCD panel with hinges Chapter 3 Identifying FRUs (CRUs)
  • Page 32 Lenovo V17 Gen 3 Hardware Maintenance Manual...

  • Page 33: Chapter 4. Removing A Fru Or Cru

    Chapter 4. Removing a FRU or CRU Service tools The following table lists tools for servicing Lenovo computers. Tools with a cross mark are needed for serving the product models as described by this publication. Prepare them before you service the product.

  • Page 34: Remove The Lower Case

    Make sure the computer has been shut down before servicing the computer. Step 1. Place the computer upside down on a flat surface. Step 2. Remove 10 screws. Step 3. Remove the lower case. Figure 3. Remove 10 screws Lenovo V17 Gen 3 Hardware Maintenance Manual...

  • Page 35: Remove The Memory Module And Shielding

    Screw specifications Number of screws M2 x L6 M2 x L4 Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: Lower case Remove the memory module and shielding Make sure the following FRUs (or CRUs) have been removed.
  • Page 36 Figure 5. Remove the memory module shielding Step 3. Peel off the memory absorber from the memory module. Figure 6. Peel off the memory absorber Step 4. Open the latches and remove the memory module from the system board. Lenovo V17 Gen 3 Hardware Maintenance Manual...

  • Page 37: Remove The Storage Drive, Cable And Bracket (For Selected Models)

    Figure 7. Remove the memory module Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: Memory module shielding Memory absorber Memory module Remove the storage drive, cable and bracket (for selected models) Make sure the following FRUs (or CRUs) have been removed.
  • Page 38 Figure 9. Disconnect cable and remove the storage drive Screw specifications Number of screws M2 x L3.5 Step 3. Remove the storage drive cable. Remove four screws. Then, remove the storage drive. Lenovo V17 Gen 3 Hardware Maintenance Manual...

  • Page 39: Remove The Battery Pack

    Figure 10. Remove the storage drive cable and bracket Screw specifications Number of screws M3 x L3 Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: Storage drive Storage drive cable Storage drive bracket...

  • Page 40: Remove The 3-Cell Battery Pack(For Models Without Storage Drive)

    Figure 11. Remove the battery pack Screw specifications Number of screws M2 x L3.5 Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: Battery pack Remove the 3-cell battery pack(for models without storage drive) Make sure the following FRUs (or CRUs) have been removed.

  • Page 41: Remove The Solid-State Drive And Thermal Pad

    Figure 12. Remove the battery pack Screw specifications Number of screws M2 x L3.5 Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: Battery pack Remove the solid-state drive and thermal pad Remove the 2242 solid-state drive, bracket and thermal pad (for selected models) Make sure the following FRUs (or CRUs) have been removed.
  • Page 42 Remove one screw. Remove the 2242 solid-state drive with the bracket. Then, remove the thermal pad. Figure 14. Remove the 2242 solid-state drive with bracket and remove the thermal pad Screw specifications Number of screws M2 x L2.8 Step 3. Remove the 2242 solid-state drive. Lenovo V17 Gen 3 Hardware Maintenance Manual...

  • Page 43: Remove The 2280 Solid-State Drive And Thermal Pad (For Selected Models)

    Figure 15. Remove the 2242 solid-state drive Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: 2242 solid-state drive 2242 solid-state drive bracket 2242 solid-state drive thermal pad Remove the 2280 solid-state drive and thermal pad (for selected models) Make sure the following FRUs (or CRUs) have been removed.
  • Page 44 Remove one screw and then remove the 2280 solid-state drive by pulling it away from the slot. Figure 17. Remove the 2280 solid-state drive Screw specifications Number of screws M2 x L2.8 Step 3. Remove the 2280 solid-state drive thermal pad. Lenovo V17 Gen 3 Hardware Maintenance Manual...

  • Page 45: Remove The Heat Sink

    Figure 18. Remove the 2280 solid-state drive thermal pad Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: 2280 solid-state drive 2280 solid-state drive thermal pad Remove the heat sink Remove the heat sink (for DIS models) Make sure the following FRUs (or CRUs) have been removed.

  • Page 46: Remove The Heat Sink (For Uma Models)

    Step 2. Loosen six screws and then remove the heat sink. Figure 20. Loosen six screws and remove the heat sink Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: Heat sink Remove the heat sink (for UMA models) Make sure the following FRUs (or CRUs) have been removed.
  • Page 47 Loosen four screws and then remove the heat sink. Figure 22. Loosen four screws and remove the heat sink Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following replacement part: Heat sink Chapter 4 Removing a FRU or CRU...

  • Page 48: Remove The System Fan

    Figure 23. Disconnect the battery pack cable Step 2. Disconnect the antenna cable connectors from the Wi-Fi card. Disconnect the fan cable from the system board. Then, release all cables from fan hooks. Lenovo V17 Gen 3 Hardware Maintenance Manual...

  • Page 49: Remove The System Fan (For Uma Models)

    Figure 25. Remove four screws and the system fan Screw specifications Number of screws M2 x L3.5 Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: System fan Remove the system fan (for UMA models) Make sure the following FRUs (or CRUs) have been removed.
  • Page 50 Disconnect the antennas from the Wi-Fi card. Disconnect the system fan cable from the system board. Then, remove all the cables from the fan hooks. Figure 27. Disconnect and remove the cables Step 3. Remove three screws and then remove the system fan. Lenovo V17 Gen 3 Hardware Maintenance Manual...

  • Page 51: Remove The Wi-Fi Card

    Figure 28. Remove three screws and the system fan Screw specifications Number of screws M2 x L3.5 Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: System fan Remove the Wi-Fi card Make sure the following FRUs (or CRUs) have been removed.
  • Page 52 Figure 30. Disconnect antenna cable connectors, remove one screw and the Wi-Fi card Number of screws Screw specifications M2 x L2.8 Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: Wi-Fi card Lenovo V17 Gen 3 Hardware Maintenance Manual...

  • Page 53: Remove The Usb Board And Cable

    Remove the USB board and cable Make sure the following FRUs (or CRUs) have been removed. “Remove the lower case” on page 28 Step 1. Disconnect the battery pack cable from the system board. Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable. Figure 31.

  • Page 54: Remove The Coin-Cell Battery

    Screw specifications Number of screws M2 x L2.8 Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following replacement parts: USB board USB board cable Remove the coin-cell battery Make sure the following FRUs (or CRUs) have been removed.

  • Page 55: Remove The Fingerprint Reader And Cable (For Selected Models)

    Figure 34. Remove the coin-cell battery Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: Coin-cell battery Remove the fingerprint reader and cable (for selected models) Make sure the following FRUs (CRUs) have been removed.

  • Page 56: Remove The System Board

    Step 2. Remove the fingerprint reader. Figure 36. Remove the fingerprint reader Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: Fingerprint reader Fingerprint reader cable Remove the system board Make sure the following FRUs (or CRUs) have been removed.
  • Page 57 Figure 37. Disconnect cables and remove two screws Screw specifications Number of screws M2.5 x L5 Step 2. Open the right hinge. Figure 38. Open the right hinge Step 3. Remove six screws. Then, turn the system board over carefully. Chapter 4 Removing a FRU or CRU...
  • Page 58 Disconnect the touch pad cable and remove the system board. Figure 40. Disconnect the touch pad cable and remove the system board Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following replacement part: System board Lenovo V17 Gen 3 Hardware Maintenance Manual...

  • Page 59: Use A Golden Key U1 Tool To Flash-Write Key Id Information

    The Golden Key U1 tool is prepared by running the U1 Update software on a FAT32-formatted USB thumb drive. Go to for detailed instructions on how to create http://support.lenovo.com/us/en/solutions/HT506954 and use a Goldern Key U1 tool. Remove the touch pad cable Make sure the following FRUs (or CRUs) have been removed.

  • Page 60: Remove The Lcd Unit

    Figure 42. Disconnect and remove the touch pad cable Refer to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: Touch pad cable Remove the LCD unit Make sure the following FRUs (CRUs) have been removed.
  • Page 61 Figure 44. Disconnect cables and remove four screws Screw specifications Number of screws M2.5 x L5 Step 3. Open the hinges. Figure 45. Open the hinges Step 4. Remove the LCD unit. Attention: When disassembling the LCD unit, handle the LCD unit and upper case with care. Chapter 4 Removing a FRU or CRU...

  • Page 62: Remove The Upper Case Assembly

    Figure 46. Remove the LCD unit Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: LCD unit Remove the upper case assembly Make sure the following FRUs (or CRUs) have been removed. “Remove the lower case” on page 28 “Remove the memory module and shielding”...

  • Page 63: Disassemble The Lcd Unit

    Attention: Do not pull the LCD bezel from the outer sides of the LCD bezel, otherwise the hooks may be damaged. The lower side of the LCD bezel is fixed to the LCD panel with adhesive tape. Detach with care. Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: LCD bezel Remove the stripe covers Make sure the following FRUs (CRUs) have been removed.

  • Page 64: Remove The Lcd Panel With Hinges

    Figure 48. Remove the stripe covers Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: Stripe covers Remove the LCD panel with hinges Make sure the following FRUs (CRUs) have been removed. “Remove the LCD unit” on page 54 “Remove the LCD bezel”...

  • Page 65: Remove The Microphone Rubbers

    Disconnect the EDP cable. Then, remove the LCD panel with hinges. Figure 50. Disconnect the EDP cable and remove the LCD panel with hinges Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: LCD panel with hinges Remove the microphone rubbers Make sure the following FRUs (CRUs) have been removed.

  • Page 66: Remove The Camera Board

    Figure 51. Remove the microphone rubbers Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: Microphone rubbers Remove the camera board Make sure the following FRUs (CRUs) have been removed. “Remove the LCD unit” on page 54 “Remove the LCD bezel”...

  • Page 67: Remove The Edp Cable

    Figure 52. Remove the camera board Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: Camera board Remove the EDP cable Make sure the following FRUs (CRUs) have been removed. “Remove the LCD unit” on page 54 “Remove the LCD bezel”...

  • Page 68: Remove The Lcd Cover

    Figure 53. Remove the EDP cable Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: EDP cable Remove the LCD cover Make sure the following FRUs (CRUs) have been removed. “Remove the lower case” on page 28 “Remove the LCD unit”...

  • Page 69: Trademarks

    Trademarks LENOVO and the LENOVO logo are trademarks of Lenovo. All other trademarks are the property of their respective owners. © 2022 Lenovo.
