Summary of Contents for Lucent Technologies CIB 2863
- Page 1 CIB 2863 2-Line Adapter CIB 2863 Comcode 103-974-572 Issue 2...
- Page 2 CIB 2863 2-Line Adapter The (267C) 2-Line Adapter is used to connect two (D2R-29) line cords to an (RJ14C) single network interface where two outside telephone lines enter the premises. If you do not know whether you have two outside telephone lines entering at a single network interface, contact your local telephone exchange service company.
- Page 3 Locking Tab Release Jacks Locking Tab Network Interface (RJ14C) Plug To Local Telephone Exchange Service Company Lines To the Control Unit 267C D2R-29 Adapter FIGURE 1 (267C) 2-Line Adapter iss 2, cib2863-2...
- Page 4 The two jacks on the adapter now provide connecting points for two individual (D2R-29) modular line cords. Removal Push down the locking tab release and pull the adapter out of the network interface jack. iss 2, cib2863-3...
