- Page 1 CIB 2867 (502A) Headset Adapter (3164-HFA) CIB 2867 Comcode 103-980-009 Issue 3...
- Page 2 CIB 2867 (502A) Headset Adapter (3164-HFA) The Headset Adapter (Figure 1) allows a headset to be connected to 10-button and 34-button voice terminals. Modular cord FIGURE 1 Headset Adapter Installing the Headset Adapter Place the Headset Adapter near the voice terminal to which it will be connected.
- Page 3 FIGURE 2 Connecting a Headset With a Two-Prong Plug to the Headset Adapter If your headset cord has a modular plug, locate the smaller keyed jack with the blue modular plug in it on the back of the adapter. Remove the plug with a pair of small snub-nosed pliers by grasping the outside edge of the blue tab with one tip of the pliers and insert- ing the other tip into the blue modular plug’s center hole (Figure 3A).
- Page 4 5 Plug the other end of the modular cord into the jack labeled Other on the bottom of your voice terminal (Figure 4). Modular cord 10-button voice terminal (bottom view) Headset adapter Headset with a 2-prong plug FIGURE 4 Connecting the Headset Adapter to Your Voice Terminal Operating the Headset Adapter Follow the instructions listed below to operate the headset connected to your Headset Adapter:...
