Summary of Contents for AEG HG654350
- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per AEG HG654350SM cerca il tuo prodotto tra le migliori offerte di Cucine e Piani cottura HG654350 User Manual USER MANUAL...
-
Page 2: Table Of Contents
10. ENERGY EFFICIENCY..................... 17 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it. - Page 3 ENGLISH usage. Always keep the instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety This appliance can be used by children aged 8 years • and above and by persons with reduced capabilities provided that they have been given instruction and/or supervision regarding the safe use of the appliance and understand the potential hazards involved.
-
Page 4: Safety Instructions
WARNING: Danger of fire: Do not store items on the • cooking surfaces. Metallic objects such as knives, forks, spoons and lids • should not be placed on the hob surface since they can get hot. Do not use a steam cleaner to clean the appliance. - Page 5 ENGLISH • Remove all the packaging. • Make sure that a shock protection is • Do not install or use a damaged installed. appliance. • Use the strain relief clamp on the • Follow the installation instruction cable. supplied with the appliance. •...
- Page 6 Make sure to connect • Do not keep hot cookware on the the appliance according to current control panel. installation regulations. Pay attention • Do not let cookware to boil dry. to requirements regarding adequate • Be careful not to let objects or ventilation.
-
Page 7: Product Description
ENGLISH • Do not use water spray and steam to • Contact your municipal authority for clean the appliance. information on how to discard the • Clean the appliance with a moist soft appliance correctly. cloth. Only use neutral detergents. Do •... - Page 8 4.1 Burner overview WARNING! Do not keep the control knob pushed for more than 15 seconds. If the burner does not light after 15 seconds, release the control knob, turn it into off position and try to light the burner again after minimum 1 minute.
-
Page 9: Hints And Tips
ENGLISH 5. HINTS AND TIPS 5.2 Diameters of cookware WARNING! Refer to Safety chapters. Use cookware with diameters applicable to the 5.1 Cookware size of burners. CAUTION! Burner Diameter of Do not use cast iron pans, cookware (mm) potstones, earthenware, grill or toaster plates. -
Page 10: Troubleshooting
• To remove burn food, fat and stubborn stains, let them soak for a few minutes in a small amount of mild detergent before cleaning. • Use cleaning products designed specifically for cleaning stainless steel in order to protect the steel surfaces. - Page 11 ENGLISH 7.1 What to do if... Problem Possible cause Remedy There is no spark when you The hob is not connected to Check if the hob is correctly try to activate the spark gen- an electrical supply or it is connected to the electrical erator.
-
Page 12: Installation
7.3 Labels supplied with the accessories bag Stick the adhesive labels as indicated below: MOD. MOD. MOD. TYPE PROD.NO. IP20 PROD.NO. PROD.NO. SER.NO. 0049 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY A. Stick it on Guarantee Card and send C. - Page 13 ENGLISH mobile parts or they are not squeezed. 3. With a socket spanner 7 remove the Also be careful when the hob is put injectors and replace them with the together with an oven. ones which are necessary for the type of gas you use (see table in Make sure that the gas "Technical Information"...
- Page 14 8.5 Electrical connection 8.7 Assembly • Make sure that the rated voltage and type of power on the rating plate agree with the voltage and the power of the local power supply. • This appliance is supplied with a mains cable.
- Page 15 ENGLISH If a furniture unit is installed at a distance of 400 mm above the hob, there must be a minimum safety distance of 50 mm to the left or right from the edge of the hob. A) supplied seal B) supplied brackets CAUTION! Install the appliance only on...
-
Page 16: Technical Data
Kitchen unit with door A. Removable panel B. Space for connections Kitchen unit with oven The electrical connection of the hob and the oven must be installed separately for safety reasons and to let easy remove oven from the unit. -
Page 17: Energy Efficiency
ENGLISH Appliance class: 9.4 Gas burners for NATURAL GAS G20 20 mbar BURNER NORMAL POWER kW MINIMUM POWER INJECTOR MARK Rapid 0,75 108x Semi-rapid 0,75 Auxiliary 0,45 9.5 Gas burners for LPG G30/G31 28-30/37 mbar BURNER NORMAL MINIMUM INJECTOR NOMINAL GAS FLOW g/h POWER kW POWER kW MARK... - Page 18 • If it is possible, always put the lids on the cookware. • When the liquid starts to boil, turn down the flame to barely simmer the liquid. • If it is possible, use a pressure cooker. Refer to its user manual.
- Page 19 ENGLISH...
- Page 20 www.aeg.com/shop...
