- Page 1 041_03 11/2005 Installation, operating and maintenance instructions GAS FRYERS AGB 519/WP · AGB 520/WP AGB 432/WP · AGB 436/WP AGB 434/WP · AGB 438/WP AGB 440/WP · AGB 442/WP AGB 444/WP · AGB 446/WP...
- Page 2 INDEX Models and dimensions Note for the installer page page Running the appliance on other types Data of appliances of gas Replacing the main burner nozzle Technical data Replacing the pilot burner nozzle Maintenance Operating instructions Replacing parts Construction, equipment installed Gas valve and safety devices Safety thermostat...
- Page 3 Dimensions 13.5 13.5 52.5 52.5 52.5 52.5 AGB 519/WP AGB 520/WP 1/2” gas connector Safety thermostat Technical data Oil drain 041 - 03 - Gas fryers...
- Page 4 Dimensions AGB 432/WP AGB 436/WP AGB 434/WP AGB 438/WP 3/4” gas connector Safety thermostat Technical data Oil drain 041 - 03 - Gas fryers...
- Page 5 Dimensions AGB 440/WP AGB 444/WP AGB 442/WP AGB 446/WP 3/4” gas connector Safety thermostat Technical data Oil drain 041 - 03 - Gas fryers...
-
Page 6: Characteristics Of The Appliances
Model Description Dimensions Basins Nr. Gas connector (LxPxH+H1) - mm. Capacity (Lt.) AGB 519/WP Gas deep fat fryer - 1 tank 400 x 700 x 875 (1085) 1/2" ISO R228 51BQ2905 AGB 520/WP Gas deep fat fryer - 2 tanks... - Page 7 TABLE 1 AGB 519/WP AGB 520/WP AGB 434/WP AGB 438/WP Model AGB 432/WP AGB 436/WP AGB 442/WP AGB 446/WP AGB 440/WP AGB 444/WP II2H3+ Category Construction type Air necessary for combustion 18.0 12.0 24.0 Nominal thermal power Minimum thermal power...
-
Page 8: Installation
ASSEMBLY Gas connection Location The R 1/2” gas off-take for models AGB 519/WP - AGB 520/WP and R 3/4” for models AGB 432/WP - The appliance should be installed in a well ventilated AGB 436/WP - AGB 434/WP - AGB 438/WP - AGB 440/WP room, and if possible under a range hood. -
Page 9: Commissioning The Appliance
- Place part (A) on the appliance and fix with the relative screws; - Insert extension (B) onto the collector; - Place part (C) on part (A) and fix with self-tapping screws; - Fit back element (D) onto part (A) and fix. - connect the outlet (E) to the fume exhaust pipe. - Page 10 Note for the installer - Explain and demonstrate to the user how the machine works according to the instructions and hand him this manual. - Remind the user that any structural alterations to the room housing the appliance may affect the combu- stion air supply.
-
Page 11: Replacing Parts
REPLACING PARTS Burner (Fig. 1) Unscrew nozzle (28) and nut (29). Loosen the screws (26) fixing the burner to the chamber. Replace the burner. All parts must be replaced by authorised technicians Thermocouple (38 - Fig. 1) only! To replace the following parts, remove the control panel Unscrew the nipple fixing the thermocouple to the valve, (after unscrewing its fixing screws). -
Page 12: Using The Appliance
USING THE APPLIANCE Warning! Lighting the pilot burner - Beware of inexpert handling! Press the button (14) and as the same time the piezoelec- - Old and dirty oil or frying fat can represent a real fire tric lighter (12) to light the pilot flame, which can be seen hazard;... -
