- Page 1 Manual iMSO-204 iMSO-204L Revised April 21, 2014...
- Page 2 Manual Table of Contents Section 1 – Getting Started – SAFETY 1.10 Quickstart Guide 1.20 SAFETY 1.30 Compatibility 1.31 Hardware 1.32 Software 1.40 Tool Tips Section 2 – How it works 2.10 Menus 2.20 Analog Channels 2.21 Analog Channels On / Off 2.22 Analog Channels 1x / 10x Probe 2.23 Analog DC / AC Coupling 2.24 Channel Labeling...
-
Page 3: Section 1 - Getting Started
Section 1 – Getting Started 1.10 Quickstart Guide This product can be purchased either with a 30-pin connector (iMSO-204) or a lightning connec- tor (iMSO-204L). Both products function exactly the same. The only difference is the connector. iMSO-204 has the 30-pin connector and iMSO-204L has the lightning connector. - Page 4 3) Connect Analog Probe and Logic Probe to the appropriate ports on the scope. W A R N I N G W A R N I N G 4) For more information, please visit the Oscium DO NOT APPLY DO NOT APPLY MORE website at www.oscium.com MORE THAN +/-40V THAN -0.5/+7V TO THE...
- Page 5 The maximum voltage limit for the analog probe in 1x mode is -8v / +13v, and the maximum voltage limit in 10x mode is -40V / +40V. The maximum voltage limit for the digital channels is -.0.5v to +7v. Oscium is not held liable for usage outside of these limits. 1.30 Compatibility 1.31 Hardware...
-
Page 6: Tool Tips
& iMSO-204L Manual 1.40 Tool Tips Although having a manual is nice (and if you’re reading this, you probably agree), it is even better when there’s help built into the app itself. Here is a screenshot of some of the tool tips we’ve built into the app (this picture is found on iOS 7 software and newer):... -
Page 7: Section 2 - How It Works
When hardware is connected on an iPhone or iPod touch, changes to . The demo mode icon disappears on the iPad when hardware is in use. In addition, Oscium has a single shot mode that is enabled by pressing and holding . Upon holding one of those icons, it will change to 2.20 Analog Channels... -
Page 8: Channel Labeling
& iMSO-204L Manual iPad | iPad mini | iPhone | iPod touch 2.22 Analog Channel 1x / 10x Probe The analog probe has a sliding red lever that allows the user to move between 1x and 10x modes. Once a mode is selected on the analog probe, chose the matching state by selecting either . -
Page 9: Digital Channels On / Off
iPad | iPad Mini iPhone | iPod touch move the channel position either up or down. 2.31 Digital Channels On / Off Touch on the menu bar. The following menu will appear: Each channel can be turned either on or off by touching either 2.40 Cursors 2.41 Cursors On / Off Touch... -
Page 10: Vertical Cursors
& iMSO-204L Manual iPad | iPad mini | iPhone | iPod touch 2.45 Vertical Cursors Touch the icon from the menu bar. Tap to activate cursors. Touch from the cursors menu. On the main screen, touch and swipe the desired cursor in the horizontal direction and place where desired. - Page 11 iPad | iPad mini | iPhone | iPod touch Up to six measurements can be selected for either CH A or CH B or a combination of both. Once selected, measurements appear on the top right of the interface. 2.60 Trigger 2.61 Analog Triggering The trigger level is controlled with the bubble located on the far right of the screen.
-
Page 12: Digital Triggering
& iMSO-204L Manual iPad | iPad mini | iPhone | iPod touch To reactivate the analog trigger, touch . If the analog triggering is grayed out, it is disabled. Then touch any of the options on the picture below and it will no longer be grayed out. -
Page 13: Auto Vs Normal
iPad | iPad mini | iPhone | iPod touch Then, the option that is touched will activate. From the menu, select the desired triggering function from these options: single channel only , simultaneous events on two channels , a single event on one of two channels , or concurrent events on two channels 2. -
Page 14: Analog Vs Digital
& iMSO-204L Manual iPad | iPad mini | iPhone | iPod touch 2.66 Analog vs Digital Touch . Then touch . Touch the desired mode, either ANALOG or DIGITAL. For example, if activating ANALOG mode touch ANALOG and it will change to . -
Page 15: Demo Amplitude
iPad | iPad mini | iPhone | iPod touch 2.82 Demo Amplitude Touch from the menu bar on the right. To change the of the signal touch located to the right of . Enter the desired voltage using the pick wheel. To activate the setting tap away from the menu. - Page 16 2.95 Compensation The iMSO-204 and iMSO-204L is shipped fully calibrated and fully compensated. If, for any reason, the analog input ever needs to be re-compensated, iMSO-204L (and iMSO-204) both have built-in 3.3 V, 1 kHz reference signals. Regardless of whether the function generator we provide is used or if an external input is used, the electrically isolated flathead screwdriver will help trim the signal.
-
Page 17: Manage Data Log
iPad | iPad mini | iPhone | iPod touch Remove the connector attachment from the analog probe. Then connect the SMD grabber for D1 (or the purple wire) to the tip of the analog probe. 2.96 Screenshot Two options exist. First, a screenshot can be captured by simultaneously pressing both the home button and the power button on your Apple device. -
Page 18: Configuration Settings
& iMSO-204L Manual iPad | iPad mini | iPhone | iPod touch When viewing the .csv data file: Each column (excluding the first) is the data point in time that is shown on the screen. When the time scale is set to less than 100ms, each row is a single screen capture. -
Page 19: Section 3 - Product Warranty & Accessories
& iMSO-204L hardware both come with a full one year manufacturer’s warranty. No warranty exists on probes and accessories. 3.20 Accessories iMSO-204 and iMSO-204L come with the following accessories: 1x / 10x analog probe, logic harness, five SMD grabbers, and one screwdriver. 3.21 1x / 10x Analog Probes The analog probe is capable of measuring signals up to 100 MHz (although our fastest scope is currently limited to 50 MSPS). -
Page 20: Section 4 - Performance Specifications
& iMSO-204L Manual Section 4 – Performance Specifications iMSO-204 & iMSO-204L 9.7” (iPad 4th gen, 3rd gen, iPad 2, iPad) 7.9” iPad Mini Display 3.5” (iPod touch 5th gen, 4th gen, iPhone 5S, iPhone 5C, iPhone 5 iPhone 4s, iPhone 4, iPhone 3GS) -
Page 21: Performance Optimization
Section 5 – How to Contact Us Thank you for your interest in Oscium’s newest products, iMSO-204 & iMSO-204L! Please feel free to contact us if you have any questions, comments or feedback. The best way to reach us www.oscium.com.
