Summary of Contents for Oscium IMSO-204x
- Page 1 Manual iMSO-204x RevOrig_20170727...
-
Page 2: Table Of Contents
Manual Table of Contents Section 1 – Getting Started – SAFETY 1.10 Quickstart Guide 1.20 SAFETY 1.30 Compatibility 1.31 Hardware 1.32 Software 1.40 Tool Tips Section 2 – How it works 2.10 Menus 2.20 Analog Channels 2.21 Analog Channels On / Off 2.22 Analog Channels 1x / 10x Probe 2.23 Analog DC / AC Coupling 2.24 Channel Labeling... -
Page 3: Quickstart Guide
Section 1 – Getting Started 1.10 Quickstart Guide iMSO-204x has universal platform support. It works with iOS, Android, PC, Mac. The Quickstart Guide is available for reference below: RevOrig_20170727... -
Page 4: Safety
The maximum voltage limit for the analog probe in 1x mode is -8v / +13v, and the maximum voltage limit in 10x mode is -40V / +40V. The maximum voltage limit for the digital channels is -.0.5v to +7v. Oscium is not held liable for usage outside of these limits. 1.30 Compatibility 1.31 Hardware... -
Page 5: Tool Tips
1.40 Tool Tips Although having a manual is nice (and if you’re reading this, you probably agree), it is even better when there’s help built into the app itself. Here is a screenshot of some of the tool tips we’ve built into the app (this picture is found on iOS 7 software and newer): This tool tip is only available (1) when the demo app is first launched or (2) after hardware has been connected and is now disconnected. -
Page 6: Menus
When hardware is connected on an iPhone or iPod touch, changes to . The demo mode icon disappears on the iPad when hardware is in use. In addition, Oscium has a single shot mode that is enabled by pressing and holding . Upon holding one of those icons, it will change to 2.20 Analog Channels... -
Page 7: Analog Channels 1X / 10X Probe
iOS, Android, PC or Mac Oscilloscope 2.22 Analog Channel 1x / 10x Probe The analog probe has a sliding red lever that allows the user to move between 1x and 10x modes. Once a mode is selected on the analog probe, chose the matching state by selecting either . -
Page 8: Digital Channels On / Off
Manual iOS, Android, PC or Mac Oscilloscope move the channel position either up or down. 2.31 Digital Channels On / Off Touch on the menu bar. The following menu will appear: Each channel can be turned either on or off by touching either 2.40 Cursors... -
Page 9: Vertical Cursors
iOS, Android, PC or Mac Oscilloscope 2.45 Vertical Cursors Touch the icon from the menu bar. Tap to activate cursors. Touch from the cursors menu. On the main screen, touch and swipe the desired cursor in the horizontal direction and place where desired. The selected cursor will be displayed as a solid line and the un-selected cursor, a dashed line. -
Page 10: Trigger
Manual iOS, Android, PC or Mac Oscilloscope Up to six measurements can be selected for either CH A or CH B or a combination of both. Once selected, measurements appear on the top right of the interface. 2.60 Trigger 2.61 Analog Triggering... - Page 11 iOS, Android, PC or Mac Oscilloscope To reactivate the analog trigger, touch . If the analog triggering is grayed out, it is disabled. Then touch any of the options on the picture below and it will no longer be grayed out. Analog triggering is always available in demo mode;...
-
Page 12: Delay
Manual iOS, Android, PC or Mac Oscilloscope Then, the option that is touched will activate. From the menu, select the desired triggering function from these options: single channel only , simultaneous events on two channels , a single event on one of two channels , or concurrent events on two channels 2. -
Page 13: Single-Shot Waveform Capture
iOS, Android, PC or Mac Oscilloscope 2.66 Analog vs Digital Touch . Then touch . Touch the desired mode, either ANALOG or DIGITAL. For example, if activating ANALOG mode touch ANALOG and it will change to . Repeat the process for DIGITAL mode. -
Page 14: Demo Amplitude
Manual iOS, Android, PC or Mac Oscilloscope 2.82 Demo Amplitude Touch from the menu bar on the right. To change the of the signal touch located to the right of . Enter the desired voltage using the pick wheel. To activate the setting tap away from the menu. -
Page 15: Alerts
2.95 Compensation The iMSO-204x is shipped fully calibrated and fully compensated. If, for any reason, the analog input ever needs to be re-compensated, a built-in 3.3 V, 1 kHz reference signal exists. Regardless of whether the function generator we provide is used or if an external input is used, the electrically isolated flathead screwdriver will help trim the signal. -
Page 16: Screenshot
Manual iOS, Android, PC or Mac Oscilloscope Remove the connector attachment from the analog probe. Then connect the SMD grabber for D1 (or the purple wire) to the tip of the analog probe. 2.96 Screenshot Two options exist. First, a screenshot can be captured by simultaneously pressing both the home button and the power button on your Apple device. -
Page 17: Configuration Settings
iOS, Android, PC or Mac Oscilloscope When viewing the .csv data file: Each column (excluding the first) is the data point in time that is shown on the screen. When the time scale is set to less than 100ms, each row is a single screen capture. When the time scale is greater than or equal to 100ms, each row is a data point in time. -
Page 18: Product Warranty
No warranty exists on probes and accessories. 3.20 Accessories iMSO-204x come with the following accessories: 1x / 10x analog probe, logic harness, five SMD grabbers, and one screwdriver. 3.21 1x / 10x Analog Probes The analog probe is capable of measuring signals up to 100 MHz (although our fastest scope is currently limited to 50 MSPS). -
Page 19: Performance Optimization
Delay (always on) / Holdoff ~99.99s max FFT, Data Logging, Advanced Math 4.11 Performance Optimization Newer generations of Apple hardware will improve the Oscium customer experience. Animations will be faster and crisper. Multitasking can also affect performance. Turning off RevOrig_20170727... - Page 20 Section 5 – How to Contact Us Thank you for your interest in Oscium’s newest product: iMSO-204x! Please feel free to contact us if you have any questions, comments or feedback. The best way to reach us is by emailing www.oscium.com.
