SERVICE MANUAL
1. Caution
2. specification
3. Alignment Procedure
4. Block Diagram
5. Scheme Diagram
6 PCB Layout
7. Specification of Main IC
8. Trouble Shooting
9. BOM List
10 Explode Diagram
This manual is the latest at the time of printing, and does not
include the modification which may be made after the printing, by
the constant improvement of product
TCL
14F1 NX56C-LA
2
6
14
29
35
38
40
6
64
7
