Page 3
-3 - CONTENTS SAFETY PRECAUTION ......................4 SPECIFICATION ........................5 APPEARANCE OF REMOTE CONTROL................10 EXPLODED VIEW AND PART NAME..................11 CIRCUIT DIAGRAM .........................14 REPLACEMENT PARTS ......................46 INSTALLATION GUIDE ......................59 TROUBLESHOOTING ......................63 Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 4
-4 - IMPORTANT SAFETY PRECAUTION Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 5
HDMI jack (Type A) DVI Audio (stereo audio-in jack L/R In) INPUT (applicable when using DVI to HDMI cable) VGA (RGB) Analog RGB (15 Pin D-Sub) Component 1,2 3 RCA (Y Pb Pr) 2 RCA Stereo (L/R) Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 6
Channel Add / Erase Channel Edit Channel Name Edit Image Setting (Video & Contrast / Brightness / Sharpness / Colour Graphic ) 4 Colour Tone Temperature Modes (Normal / Warm / Cool / User ) Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 7
Digital Noise Reduction of Image (SD Only) Disable all the buttons on TV set Stand-By < 3W Maximum Y/C IN Y:1.0±0.2VP-P C:0.7 VP-P SOURCE IN/OUT Consumption CVBS 1.0±0.2VP-P AUDIO IN 0.2 ~ 2V (Normal 0.5V) RGB IN RGB IN: ≤ 0.7VP-P Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 8
,the user is suggested to perform the Auto Setup is Windows "Full Screen"pattern. RESOLUTION V.FREQ.(Hz) H.FREQ.(KHz) BAND WIDTH(MHz) 640*350 37.86 31.5 640*400 37.86 31.5 640*480 31.469 25.175 640*480 37.86 31.5 640*480 37.5 31.5 800*600 35.156 800*600 37.88 800*600 800*600 46.875 49.5 1024*768 48.363 1024*768 56.476 Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 10
-10 - Appearance Remote Control Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 11
-11 - Exploded View and Part List Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 12
BRACKET SUPPORT FOR PCB 40302KCD42010 SWITCH 4200AC1020010 AC JACK 305T370102030 BRACKET FOR SWITCH AND AC JACK 7506DT3720020P POWER SUB-ASSEMBLY 6020BMW040060 MACHINE SCREW BM6 x 8 (WHITE) 7596T3702002A AV SUB-ASSEMBLY 7566T3001000M VGA SUB-ASSEMBLY 305T37010402A TERMINAL BRACKET (SIDE) Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 13
BASE GLASS 6020BMB050100 MACHINE SCREW BM5 x 10 305T370107020 CONNECTING BRACKET FOR BASE 305T370107010 MAIN BASE BRACKET 101T370102040 DECORATING COVER FOR BACK COVER 6020KMB050200 MACHINE SCREW BM5 x 20 305T370107030 SYRFACE BRACKET FOR BASE GLASS Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 38
Multistandard video decoder with adaptive SAA7117(A)H/V2 comb filter and component video input SAA7117(A)E/V2...
Page 39
Multistandard video decoder with adaptive SAA7117(A)H/V2 comb filter and component video input SAA7117(A)E/V2 Analog Frontend 3.2.1 Analog Frontend of SAA7117A 3.2.1.1 Overview The SAA7117A offers sixteen analog signal inputs, which are fed to four analog main channels with source switches, clamp circuits, analog amplifiers, and 10-bit CMOS ADCs with decimation filters.
Page 40
SAA7117(A)H/V2 Multistandard video decoder with adaptive SAA7117(A)E/V2 comb filter and component video input DNC6 DNC12 AI41 DNC11 AGND DNC8 V SSA4 DNC7 AI42 DNC2 AI4D DNC1 AI43 V DDD9 V DDA4 HPD0 V DDA4A HPD1 AI44 HPD2 AI31 HPD3 V SSA3 HPD4 AI32 V SSD8...
Page 41
SAA7117(A)H/V2 Multistandard video decoder with adaptive SAA7117(A)E/V2 comb filter and component video input ORDERING INFORMATION PACKAGE TYPE NUMBER NAME DESCRIPTION VERSION plastic ball grid array package; 156 balls; body 15 × 15 × 1.15 mm SAA7117E/V2 BGA156 SOT472-3 SAA7117E/V2/G BGA156 leadfree version of SAA7117E/V2 SOT472-3 plastic ball grid array package;...
Page 42
SAA7117(A)H/V2 Multistandard video decoder with adaptive SAA7117(A)E/V2 comb filter and component video input SYMBOL TYPE DESCRIPTION QFP160 BGA156 AI11 analog input 11 ground for analog inputs AI1x SSA1 AI12 analog input 12 AI1D differential input for ADC channel 1 (pins AI14 to AI11) AI13 analog input 13 analog supply voltage for analog inputs AI1x (3.3 V)
Page 43
SAA7117(A)H/V2 Multistandard video decoder with adaptive SAA7117(A)E/V2 comb filter and component video input SYMBOL TYPE DESCRIPTION QFP160 BGA156 serial clock input (I C-bus) digital ground 4 (core; connects to substrate) SSD4 I/O/od serial data input/output (I C-bus) RTS0 real-time status or sync information, controlled by subaddresses 11h and 12h RTS1 real-time status or sync information, controlled by subaddresses...
Page 44
SAA7117(A)H/V2 Multistandard video decoder with adaptive SAA7117(A)E/V2 comb filter and component video input SYMBOL TYPE DESCRIPTION QFP160 BGA156 IPD1 MSB6 of image port data 1 output digital supply voltage 7 (core, 1.8 V) DDD7 IPD0 LSB of image port data 1 output HPD7 MSB0 of host port data I/O, extended C input for expansion port,...
Page 45
SAA7117(A)H/V2 Multistandard video decoder with adaptive SAA7117(A)E/V2 comb filter and component video input SYMBOL TYPE DESCRIPTION QFP160 BGA156 XPD4 MSB3 of expansion port data digital supply voltage 10 (core, 1.8 V) DDD10 digital ground 10 (core) SSD10 XPD3 MSB4 of expansion port data XPD2 MSB5 of expansion port data digital supply voltage 11 (peripheral cells, 3.3 V)
Page 46
THERMAL RES. NTC 8D-15 5A 8R 412A0471D14A0 PIEZO RES. ENC471D-14A 4130471102M00 EL- CAPA. ENC471D-14A 4136151102M00 CERAMIC CAPA. Y DC1000V-151 4136471251M00 CERAMIC CAPA. Y CAPA.AC250V-471 M C3,4,38 4138104101M00 METAL MYLAR CAPA.. 100V-0.1uF-M 4138184101M01 METAL MYLAR CAPA.. 100V-0.18uF Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 47
PHOTO COUPLE IC PC817B U3,4 41700KA431AZ0 IC KA431AZ TO-92 4170F9222L000P IC F9222L-F219[ROHS] 4222500500041 FUSE T 5A 250V VDE/UL MTV-3201 HEAT SINK (1) 425T320100010 PCB BOARD WJETV3201#390100(AL) MTV-3201 HEAT SINK (2) 425T320100020 U2&D9 WJETV3201#390200(AL) 42902101KT800 INDUCTOR L2006-100Uh, T80-26 Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 58
CHIP INDUCTOR 0805, 120 OHM@100MHz 4290512106010 400-407 B300 301 302 303 B400 401 L408 409 CHIP INDUCTOR 22uH SM5845-220K(f) 4291022R00040P L100 101 102 103 [ROHS] 1.2A The data are subject to change without prior notice. Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 59
Improper installtion may render the unit unsafe in the event of an earthquake etc. 2. Two or more people are require to hand this TV on wall. 3. The unit must be fixed to a concrete wall. Refer to drawings below :- Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 60
-60 - FRONT BACK Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 61
-61 - Model No.: LCT-40KX1DSTP.doc Version: 1.0...
Page 62
-62 - ANTENNA Model No.: LCT-40KX1DSTP.doc Version: 1.0...
