  • Page 2 The copyright of this manual belongs to Shenzhen JEHE Technology Development Co., Ltd. (Giada, JEHE’s global brand) and all rights are reserved. The company reserves the right to change this manual at any time without notification. Specifications here are for reference only, please take the real product as standard.

  • Page 3: Table Of Contents

    Table of Contents 1. Product Introduction..................... - 3 - 2. Interface Description and Hardware Specifications.......... - 3 - 2.1 Interface Description..................- 3 - 2.2 Hardware Specifications.................. - 4 - 3. Accessories Installation Steps................- 5 - 3.1 CPU Installation....................- 6 - 3.2 Memory Installation..................- 7 - 3.3 WIFI (M.2) Installation..................- 8 - 3.4 2.5”...
  • Page 4 4.2.7 System Devices Configuration............. - 24 - 4.3 Security......................- 26 - 4.4 Boot........................ - 27 - 4.5 Save & Exit....................- 29 - 5. JAHC Introduction....................- 30 - 5.1 How to set up Auto power on function............- 30 - 5.2 JAHC Software....................

  • Page 5: Product Introduction

    1. Product Introduction Based on Rocket Lake platform, Giada BQ611 is a high-performance desktop model supports Intel LGA1200 Socket 10th/11th Gen. processors (TDP ≤65W), equipped with H510/B560 chipset; maximum 32GB dual-channel SO-DIMM DDR4-3200MHz memory and rich I/O ports to serve different desktop terminal application scenarios.

  • Page 6: Hardware Specifications

    Left I/O Port 2.2 Hardware Specifications BQ611 Intel ® LGA1200 Socket 10 Gen. Processors (TDP≤65W) Processor BIOS AMI Source Code Chipset H510 / B560 Type DDR4-3200MHz Socket SO-DIMM Memory Channel Max Capacity 32 GB Intel ® Gen. UHD Graphics DirectX 12, OpenGL 4.5, OpenCL 2.2...

  • Page 7: Accessories Installation Steps

    Infineon TPM2.0 (Optional) Socket 1 1 x M-key M.2 (2242/2280) for SSD Storage Socket 2 1 x 2.5” SATA (7+15Pin) WatchDog Timer 0-255 Second Time Out Support Auto Power On Power Activated Automatically Start JAHC Set Up Independently Every day Remote Control Wake on LAN Windows...

  • Page 8: Cpu Installation

    3.1 CPU Installation 1. Unscrew the 4 screws and remove the CPU cooler. 2. Remove the hook to open the closure. 3. Put the CPU on the board and paint the top side with heat conduction grease. 4. Remove the closure and put the hook back. 5.

  • Page 9: Memory Installation

    3.2 Memory Installation This product only supports DDR4 SO-DIMM memory modules. 1. On top side, unscrew the two screws and remove the fan. Locate the SO-DIMM slot on the board. 2. Gently insert the module into the slot in a 45-degree angle. 3.

  • Page 10: Wifi (M.2) Installation

    3.3 WIFI (M.2) Installation 1.Plug the WIFI module into the appropriate slot. 2.Secure the module to the carrier by tightening up the screw. 3.Connect the two black cables to Main and AUX. Install antennas. - 8 -...

  • Page 11: Sata Hdd/Ssd Installation

    3.4 2.5” SATA HDD/SSD Installation 1. Fix the two standoffs on motherboard; 2. Fix the 2.5” hard drive on HDD bracket and place silicone rubber pad on bracket; 3. Fix the bracket by tightening up the screw to standoffs. - 9 -...

  • Page 12: Ssd (M.2) Installation

    The descriptions relating to BIOS setup in this Manual is for reference only since the BIOS version of the product might be upgraded. Giada provides no guarantee that all the contents in this Manual are consistent with the information you acquired.
  • Page 13 can run stably and work in optimized state will hinge on how to properly set the parameters in BIOS. Therefore, the correct setup of BIOS plays a key role in stably running the system and optimizing its performance. The CMOS Setup will save the set parameters in the built-in CMOS SRAM on the motherboard. When the power is shut off, the lithium battery on the motherboard will provide continuously power to CMOS SRAM.
  • Page 14 C. Auxiliary information Main interface When the system enters the main interface of Setup, the major selected contents will be displayed at the lower part of the interface with the change of the options. When you set the value for each column, you can view the preset value of the column and the values that can be set if you press F2, for example, the BIOS default values or CMOS Setup values.

  • Page 15: Main (Standard Cmos Setup)

    3) Security (set the administrator/user password) 4) Boot (startup configuration characteristics) 5) Save & Exit (option of exit) This item includes load optimal defaults / load failsafe defaults value / discard changes / discard changes and exit. 4.1 Main (Standard CMOS Setup) 1) System time (hh:mm:ss) Use this item to set the time for the computer, with the format as “HH / MM / SS”.

  • Page 16: Advanced (Advanced Bios Setup)

    4.2 Advanced (Advanced BIOS Setup) 4.2.1 ACPI Setting ACPI Settings Menu Description ACPI Sleep state Enable/Disable Software Guard Extensions (SGX) State After G3 Enabled/disable CPU Flex Ratio Programming. Control Unit (MCU) and software (JAHC Technology Manager). JAHC Enable  Disabled: The JAHC is disable by default. ...

  • Page 17: Cpu Configuration

    4.2.2 CPU Configuration - 15 -...
  • Page 18 CPU Configuration Menu Description  Max Non-Turbo Performance: the best performance. Boot performance mode  Max Battery. Turbo performance.  Intel (VMX) Virtualization Intel Virtualization Technology is enabled by default. User can Technology enable and disable the Intel Virtualization Technology function. Intel （...

  • Page 19: Wake Configuration

    4.2.3 Wake Configuration CSM Options Description Wake Configuration Wake On LAN Function. Wake Up On LAN  Disabled: The WOL is disabled by default.  Enabled. Enabled or Disabled Wake Up by USB KB/MOUSE from S3 Status. Wakeup By USB KB/MS ...

  • Page 20: Trusted Computing

    4.2.4 Trusted Computing - 18 -...
  • Page 21 Trusted Computing Description TPM20 Device Found  TPM2.0 device information. Enables or Disables BIOS support for security device. OS will  Security Device Support not show security device. TCG EFI protocol and INT1A interface will not be available. SHA-1 PCR Bank ...

  • Page 22: It8625 Super Io Configuration

    4.2.5 IT8625 Super IO Configuration - 20 -...
  • Page 23 Super IO Configuration Description This item can be used to set the Serial Port 1 after entering the Serial Port 1 Configuration Serial Port 1 Configuration. It can be set according to user's needs. Serial Port 1 Configuration The serial port is enabled by default. Serial Port ...

  • Page 24: Hm Monitor & Smart Fan

    Super IO Configuration Description User can set the serial port by change settings option.  Auto IO=3E8H ； IRQ=4 ；  IO=3F8H ； IRQ=3 ， 4 ， 5 ， 6 ， 7 ， 9 ， 10 ， 11 ， 12 ； ...
  • Page 25 Menu Description Pc Hardware Monitor Status It includes Full on mode Smart Fan manual mode " ", " " " ". Full on mode.  CPU Smart Fan Mode  Smart Fan: Smart Fan is enabled by default.  Manual Mode. FAN will stop work If temperature is lower than the Fan off Fan off temperature limit temperature limit value.

  • Page 26: System Devices Configuration

    CPU Fan Setting  Current FAN Setting 4.2.7 System Devices Configuration - 24 -...
  • Page 27 System Devices Configuration Description SATA Configuration SATA Controller(s) Enable/Disable SATA Controller(s) SATA Mode Selection Determines how SATE controller (s) operate.  Control Detection of the HD-Audio device. HD Audio Disabled. HDA will be unconditionally disabled   Enabled. HDA will be unconditionally enabled. Network Stack This item can enable and disable UEFI network stack.

  • Page 28: Security

    The user can enable or disable IPV4 PXE Boot support. If disabled IPV6 PXE boot option will not be created. Ipv6 PXE Support  Enabled.  Disabled.IPV6 PXE support is disabled by default. The user can enable and disable IPV4 PXE Boot support. If disabled IPV6 HTTP boot option will not be created.

  • Page 29: Boot

    If this function is selected, the following information will appear: Enter New Password hhhhhh Then enter a password which is no more than eight characters and press <Enter>. BIOS will require to enter the password again. Once you enter it again, BIOS will save the set password. Once the password item is enabled, you will be required to enter the password every time before the system entering to the setup program of BIOS.
  • Page 30 Boot Menu Description Boot Configuration  This item is use to set the wait time of entering the operation system. During the BIOS post, if user Setup Prompt Timeout doesn't press the keyboard, it won't respond unless you reboot the BIOS. The Setup Prompt Timeout is 3s by default.

  • Page 31: Save & Exit

    4.5 Save & Exit Save Exit Item Description Save Options  Save all changes and exit Save Changes and Reset  Give up the settings and exit. Discard Changes and Exit  Recover it to default. Restore Defaults  Whole Boot devices Boot Override - 29 -...

  • Page 32: Jahc Introduction

    5. JAHC Introduction JEHE Active Hardware Control (JAHC) management system includes both hardware Micro Control Unit (MCU) and software (JAHC Technology Manager). It can support following functions: 1. Automatically boot up when power on. It is controlled by the Micro Control Unit (MCU) chip. 2.
  • Page 33 b. Select Advanced- > ACPI Setting - > JAHC Enable- > Enabled. c. Press ‘F10’ to save change & exit after select “JAHC enabled” option. - 31 -...

  • Page 34: Jahc Software

    Supported operation system: Windows 10 64bit, Linux 64bit. How to install JAHC software: Please download the JAHC.EXE from Giada website: www.giadatech.com, then follow up below steps: a. Double-click the JAHC.EXE file, the setup wizard will pop up, select destination location and click [Next] button to continue the installation.
  • Page 35 b. Click [Next] button to continue the installation. c. Select [Create a desktop shortcut] and click [Next] button. - 33 -...
  • Page 36 d. Click [Install] button to continue the installation. - 34 -...
  • Page 37 e. Click [Finish] button to finish the installation. You can select [Launch JAHC] to run the software automatically after finishing the installation. Notice: The JAHC will be added into boot item when it is installed. It will start up when system boot - 35 -...

  • Page 38: Startup & Shutdown Time Setup

    5.2.3 Startup & shutdown time setup After install the JAHC software, double click the JAHC icon on taskbar and the setup menu will pop One week as a circle, maximum 3 schedules per day. Select each schedule to set up the resume time and shutdown time.
  • Page 39 Click [Cancel] button to restore the time settings and cancel the shutdown status. Click [X] button to hide the menu. You can find it on taskbar. Right click the JAHC icon on taskbar and select [exit] to exit the software. Shutdown caution: the shutdown caution will pop up before the system shutdown.

  • Page 40: Watchdog Api And Instruction

    5.3 Watchdog API and Instruction Please contact Giada FAE (email:support@giadatech.com) for watchdog API software and instruction. - 38 -...
  • Page 41 - 39 -...
