  • Page 1 29FV6 34FV6 COLOR TV RECEIVER OWNER'S MANUAL Please READ this manual carefully before operating the unit, and keep it for future reference.
  • Page 2: Table Of Contents

    * For your enjoyment of this TV set, please read this manual carefully and keep it good for future reference. CONTENTS Before Operation Warning and cautions...1 Installation...2 Antenna connection...2 Preparation for the remote control ...2 Position of Button and Plug-ins...3 Front and side pannel...3...
  • Page 3: Warning And Cautions

    TV set. 6. If the TV set is not going to be used for a long time, or there is a severe thunder & Lighting storm, it is recommended that the TV set be disconnected from the AC power outlet and the aerial plug removed.
  • Page 4: Installation

    Installation Antenna connection General speaking, to enjoy a clearer picture, we recommend that you use a CATV system or an outdoor antenna .In different places, the suitable antenna type and position are different. 300 twin-lead cable Antenna adapter (additional purchase) 75 coaxial cable Plug (additional purchase)
  • Page 5: Position Of Button And Plug-Ins

    Position of Buttons and Plug-ins Front and Side panel 29FV6 , 34FV6 Model Channel position up/down Volume up/ down MENU Back panel 29FV6 Model VGA input terminal AV output terminals AV2 input terminals AV1 input terminals DVD component terminals S-video input terminal: Special video...
  • Page 6: Function Button Of The Remote Control

    Function buttons of the remote control Mute button To eliminate the sound of the programs DC standby and power button TV and AV exchange button A changeover between TV and other input signals like AV I/II select button Picture still button Screen call/help button...
  • Page 7: The Screen Display Menu

    Remind Prog. --- Note: When the TV set is powered on, there might be different from what have been illustrated above. Please do some adjustment as follows to meet your needs. 1. Press the MENU button to select the menu in the main menu: PICTURE, SOUND, TUNING and FUNCTION.
  • Page 8: Switch On/Off The Tv Set

    2. If the TV is in the state of standby, press the POWER button or the CH+/- buttons on the remote control. Note: 1.
  • Page 9: Watching Tv Programs

    Press the CH+/- buttons to move the indicator to " ", and Sound Sys. press the VOL+/- buttons to select the proper sound. (If the TV set you bought had multi-system, then M, B/G and I will appear alternately.) Picture...
  • Page 10: Program Swap And Auto Scan Functions

    Auto program scan 1. Press the SCAN button to scan through all the memorized TV channels. The TV set screen displays 12 pictures at the same time. Press the S.STD button to scan next page, and press the P.STD to scan last page.
  • Page 11: Tuning

    Tuning The TV set has three methods to set the channels, which are Auto search, Search and Fine tune. In this section, how to use the remote control to set the channel is explained. You can also use the buttons on the TV set to set channel.
  • Page 12: Search

    . Press the CH+/- buttons to move the indicator to "Search". 4. Press the VOL+ or VOL- buttons, the TV set will begin to search up or down, when the TV set has searched a program, the TV set will stop searching.
  • Page 13: Fine Tune

    4. Press the VOL+ button to enter the Fine Tune Menu, and then VOL- button to search downwards or the VOL+ button to search upwards until it has searched the TV signal you need. Picture Sound Tuning Prog NO. Skip Sound Sys.
  • Page 14: Skip Unnecessary Channel

    Tuning (Continued) Skip unnecessary channel VOL- MENU VOL+ TUNE VOL- MENU VOL+ Skip unnecessary channel The Program skip feature enables you to skip/hide programs that you do not wish to be displayed when using the CH+/- buttons. These channels will still be displayed by directly using the channel number buttons on the remote control.
  • Page 15: Exchange Programs

    MENU VOL+ Exchange Programs This feature enables TV programmes that may be on a wrong program number to be moved to another number. This feature is very useful when Automatic Search Tuning has been used because programmes are stored in the order they are found, which is usually not the desired order.
  • Page 16: Convenient Picture And Sound Controls

    Convenient Picture and Sound Controls Select the picture modes and set the picture quality P.STD PICTURE VOL- MENU VOL+ How to select the picture modes You can quickly select the desired picture mode from four preset modes and one customized mode. Press the P.STD button to select the desired picture quality.
  • Page 17: Select The Sound Modes And Set The Sound Quality

    Convenient Picture and Sound Controls (Continued) Select the sound modes and set the sound quality S.STD SOUND VOL- VOL+ MENU How to select the sound modes You can quickly select the desired sound mode from four preset modes and one customized mode.
  • Page 18: Set Sound Effect, Surround And Mute Functions

    . Press the VOL+ button to sub-menu. . Press the CH+/- buttons to select the desired option, then the sound effect of the TV set turn to the sound effect selected. Press MENU button to exit the sub-menu. Surround Function 1.
  • Page 19: Time Set Up Function

    If the VOL+/- buttons is pressed and released, the time will change in one minute. On/Off Time function The TV set can be powered on/off at a preset time and it can start with a program you have preset. Here take On Time function for example. The Off Time function is same with it.
  • Page 20: Sleep And Remind Prog. Function

    VOL-/+ buttons to adjust. . Press the VOL-/+ buttons to adjust. Remind Prog. Function With Remind Prog. function, the TV set can automatically change a preset program in a preset time . 1. Press the TIME button, the Time menu will appear on the screen.
  • Page 21: Set Up Function

    . Press the CH+/- buttons to move the indicator to " Language ", then press the VOL+ button to select the desired language, then the OSD language of the TV set turn to the OSD language selected. Picture Sound Tuning...
  • Page 22: Time Skip And Select Switch On Mode

    Set Up Function(continued) Time Skip function and Select Switch on mode FUNCTION VOL- MENU VOL+ FUNCTION VOL- MENU VOL+ Time Skip function In the FUNCTION menu yon can set the time of the Skip Time function (For example, 2 minutes. The screen displays 02:00).
  • Page 23: Hdmscan Function And Svm Function

    HDM Scan function The HDM scan includes 1920*1080/50Hz,1920*1080/60Hz, 1280*720 720P ,480P YPbPr , Pixes Plus,100Hz,60P, 50P, etc. The TV set will recover 100Hz after powering off. 1. Press the FUNCTION button, the Function menu will appear on the screen. . Press the CH+/- buttons to move the indicator to "...
  • Page 24: Dnr Function And Comb Filter Function

    Set Up Function(continued) DNR (Digital Noise Reduction) function and Comb Filter function FUNCTION VOL- MENU VOL+ FUNCTION VOL- MENU VOL+ DNR function 1. Press the FUNCTION button, the Function menu will appear on the screen. . Press the CH+/- buttons to move the indicator to "...
  • Page 25: Tilt Function And Digital Bass Function

    FUNCTION VOL- MENU VOL+ Tilt function When the TV set is affected by the geomagnetism so that the whole picture turn tilt, you can use the function. 1. Press the FUNCTION button, the Function menu will appear on the screen.
  • Page 26: Mark Six Function

    Set Up Function(continued) Mark Six function FUNCTION VOL- MENU VOL+ SOUND TUNE CAL./EXIT FUNCTION Mark Six display 1. Press the FUNCTION button, the Function menu will appear on the screen. . Press the CH+/- buttons to move the indicator to " Amusement ". .
  • Page 27: Chinese Jumper Function

    Set Up Function(continued) Chinese Jumper function FUNCTION VOL- MENU VOL+ FUNCTION SOUND TUNE CAL./EXIT Chinese Jumper display 1. Press the FUNCTION button, the Function menu will appear on the screen. . Press the CH+/- buttons to move the indicator to " Amusement ". .
  • Page 28: Paint Function

    Set Up Function(continued) Paint function FUNCTION VOL- MENU VOL+ FUNCTION SOUND TUNE CAL./EXIT Paint display 1. Press the FUNCTION button, the Function menu will appear on the screen. . Press the CH+/- buttons to move the indicator to " Amusement ". .
  • Page 29: Calendar And World Clock Function

    Set Up Function(continued) Calendar and World Clock function FUNCTION VOL- MENU VOL+ PICTURE SOUND FUNCTION VOL- VOL+ MENU PICTURE SOUND Calendar function Note: The calendar can not renew automatically. 1. Press the FUNCTION button, the Function menu will appear on the screen.
  • Page 30: Cslculator And Screen Display Function

    Set Up Function(continued) Calculator and Screen display function FUNCTION VOL- MENU VOL+ PICTURE SOUND TUNE CALL/HELP Calculator function 1. Press the FUNCTION button, the Function menu will appear on the screen. . Press the CH+/- buttons to move the indicator to " Amusement ". .
  • Page 31: Setting The Lock

    Setting the Lock This TV set provides you with the LOCK function, you can choose it due to your need to protect your TV set. Change your password H.LOCK VOL- MENU VOL+ Change your password This TV set can set a four digit password, the original one is 0000, if you want to reset it, please follow the instructions below.
  • Page 32: Setting The Lock

    AV has been locked. 4.When the CHILD LOCK is set ON, if the buttons on the TV are pressed, the screen will indicate that the TV set is in the status of Child Lock, and the buttons won't work.
  • Page 33: Others Functions

    Others Functions Shuttle and Favorite functions SHUTTLE FAVORITE VOL- MENU VOL+ FAVORITE Shuttle function After the shuttle function set, it is convenient to swap the desired program. It is set to video AV ( On AV status, only recall the memoried programs,not memory the AV contents.) When you are watching the program 3, you don not favorite some sections but others...
  • Page 34: Vga Input Adjustment

    5.Click the Advanced button and click the Monitor tab on the dialog-box. Set the vertical-frequency to 60Hz and then click the OK button. 6. Connect the PC to the TV set by the VGA terminal. VGA input adjustment 1. Press the HDM button to select the HDM 640X480 input mode .
  • Page 35: External Connections

    Video/Audio Output Connection, VGA Input Note: The 34FV6 model can be connected such as the order of dashed; the 29FV6 model can be connected such as the order of real line. To Audio/Video input VCR Etc.
  • Page 36: Video/Audio Input Connection

    To Audio/Video Input Note: 1.When the S-Video signal and the AV1 signal are connected to the TV set at the same time, the S-Video prior to the AV1 signal. 2.Don not use the Side AV2 IN terminal and rear AV2 IN at the same time.
  • Page 37: Trouble Shooting

    TV set, placing magnets near the TV screen or turning on/off house hold appliances such as vacuum cleaners near the TV set. Turn the TV off with the mains power switch for 15 minutes. When the power is turn on again Normal volume the TV set will automatically degauss the picture.
  • Page 38: Specifications

    Specifications Design and specifications are subject to change without notice. 29FV6 M o d e l Color system Sound system 74cm Pure flat Picture tube Sound output 8W+8W & 15W AC 160V-250V 50Hz/60Hz Power supply Power consumption 746 W x589 H x546 D...
