9.5

Electrical connection

An omnipolar disconnector switch must be
installed upstream of the cabinet. This must
have:
• Minimum distance of the contacts of 3
mm.
• Adequate breaking power
The disconnector switch must be placed in a
position that makes it easy to operate in
emergency situations (maximum distance of 3
m).
Before connecting the cabinet, ensure that the
supply voltage corresponds to the rating plate
data of the cabinet. To guarantee smooth
operation, the maximum voltage variation must
be between +/- 6% of the nominal value.
9.6

Technical features

The identification plate shows the characteristic
technical data of the cabinet. Its position and
the type of data are shown in "Technical
features" ("Fig. 29").
Wiring diagrams, control instrument calibration
lists, installation instructions and copy of the
Declaration of Conformity are available on the
website https://documents.eptarefrigeration.
com.
The sound pressure level generated by the
operation of the cabinet is lower than 70 dB(A).
The cabinet does not cause harmful vibrations.
9.7

Loading the product

Energise the cabinet to start its cooling cycle,
by acting on the general disconnector switch
mounted on the wall. After about 2 hours it is
possible to load the cabinet.
The cabinet is suitable to maintain the
temperature of the goods and not lower it; the
foods, therefore, must be introduced inside it
only if already cooled to the respective
temperatures of preservation. Products which
have been heated must never be introduced
into the cabinet.
N°DOC. UM000331 REV. "C" - 21/01/22
SHAPE INTEGRAL
Epta Spa - Via Mecenate, 86 - 20138 Milano (MI) ITALIA
Tel. 02/55403211 Telefax 02/55401023
In the presence of glass fronts on the cabinet, it
is recommended to load the goods when there
is no customer in the sales area.
In loading the goods, ensure that:
• The load is homogeneous in terms of
dimension and quality of the products
• The goods do not obstruct the correct flow
of refrigerated air ("Fig. 30").
• The goods do not exceed the load line
("Fig. 33").
Uniformly distributed maximum permissible
load:
• On the bottom level: 90 kg/m
9.8

Use of cabinet

Lighting
Cabinet lighting is controlled by a switch on the
rear of the cabinet.
Thermometer
The thermometer located on the air inlet
displays the temperature inside the display
case.
Telethermostat
The telethermostat on the rear displays control
and operation temperature.
Anti-fog heating element (optional)
The cabinet avails of an anti-condensation
ventilation system of the front glass. In case of
excessive humidity of the environment with
fogging of the glass, an indicator light mounted
on the rear control panel of the cabinet allows to
insert an anti-fog heating element.
The heating element turns off automatically
after one hour of operation (indicator light off).
If the need to use it persists, press the button
again.
For changes to the operating time of the heating
element, contact your nearest service centre.
