Kudux PIXEL ZOOM 285 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PIXEL ZOOM 285
WASH LED
User manual
!
Please read the manual before installing and using this lighting
Keep it for future reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PIXEL ZOOM 285 and is the answer not in the manual?

Questions and answers

Related Manuals for Kudux PIXEL ZOOM 285

Summary of Contents for Kudux PIXEL ZOOM 285

  • Page 1 PIXEL ZOOM 285 WASH LED User manual Please read the manual before installing and using this lighting Keep it for future reference...
  • Page 2 If you have any remarks or comments, please share them with us. We will be grateful for any suggestions that will help us make products that are even better and devices that satisfy your needs. R&D Team WWW.KUDUX.COM...

  • Page 3: Table Of Contents

    WWW.KUDUX.COM...

  • Page 4: Safety Information

    Prohibit the use of a lightning storm or wet environment. 1.5. To prevent burning or fire • The fixture can't be mounted directly on the surface of ordinary combustible material. • The equipment must be installed away from inflammable and explosive materials. WWW.KUDUX.COM...

  • Page 5: Package

    The equipment cannot have an obstacle at least in the range of 0.5 meters. • Do not replace the non-original parts. Package 2.1. Attachment PIXEL ZOOM 285 packed with fly-case of one in one, two in one, or carton box, attach follow accessory: CONTENT QUANTITY USER MANUL...
  • Page 6 3. Product parts 01 —body 02 —arm 03 —lens 04 —handle 05 —base bottom 4. Dimensions: WWW.KUDUX.COM...
  • Page 7 3-phase motor for Pan/Tilt fast moving speed & noiseless; IP Rate: IP20; Flight case : 740x400x490 mm; carton : 460x305x420 mm; Net weight : 12 KG; Can make the clear spot when beam angel in7.9-degree, wash effect when in big angle 5.2. Luminous diagram WWW.KUDUX.COM...

  • Page 8: Install Standard

    Install standard 6.1. Install lock PIXEL ZOOM 285 can be placed on the stage, or mounted in an arbitrary direction of the truss. Two fast locks system could fix the item easily. 6.2. Equipment fixed • Before installation must verify the fast lock is keep in good state, and can withstand at least 10 times the weight of product.

  • Page 9: Power Supply

    Aoto inactive 14CH 14CH Channel 25CH 25CH Mode: 90CH 90CH FEATURES Pan Scan Normal SETTING Pan Reverse: Pan Scan Reverse Tilt Scan Normal Tilt Reverse: Tilt Scan Reverse Pan/Tilt optical sensor testing Opto Check: Pan/Tilt optical sensor testing WWW.KUDUX.COM...
  • Page 10 DefConfig exit from the current interface UseManage save factory configuration ,exit SAVE from current interface export factory configuration FacConfig EPRT exit from current interface exit from current interface back to last interface Verify1: UNLOCK 0-255 unlocking code Verify2: WWW.KUDUX.COM...
  • Page 11 Colour Grad: SMULATE Gobo: Shape Selection: Shape Speed: Shape Fade: Shape R: Shape G: Shape B: Shape W: Shape Dim: Background Dim: Reserved: > current value + 1 < current value - 1 back to last interface WWW.KUDUX.COM...
  • Page 12 3 minutes close menu to return DISPLAY automatically SETTING 1Min The menu returns in 1 minute Menu Back: The menu returns after 2 2Min minute The menu returns after 3 3Min minute Light Flash: Closing backlight flashing WWW.KUDUX.COM...

  • Page 13: Dmx Channels

    65 -69 Strobe ON 70 -84 Slow input Strobe Fast-Slow 85 -89 Strobe ON Strobe 90 -104 Slow output Strobe Fast-Slow 105-109 Strobe ON 110-124 Random Strobe Fast-Slow 125-129 Strobe ON 130-144 Random Slow input Strobe Fast-Slow 145-149 Strobe ON WWW.KUDUX.COM...
  • Page 14 Congo Blue temperature or 45 -49 Tokyo Blue color 50 -54 Deep Blue 55 -59 Just Blue 60 -64 Medium Blue 65 -69 Double CT Blue 70 -74 State Blue 75 -79 Full CT Blue 80 -84 Half CT Blue WWW.KUDUX.COM...
  • Page 15 40 -71 Yellow to Green 72 -103 Green to Cyan Color slow 104-135 Cyan to Blue change 136-167 Blue to Magenta 168-199 Magenta to Red 200-231 Red to White 232-255 Color change slow - fast LED gobo 0 -4 -F91 WWW.KUDUX.COM...
  • Page 16 0 -255 White Dimmer Dark-Bright Effect 0 -255 Dimmer Dark-Bright Dimmer Effect 0 -255 Dimmer Dark-Bright backlight Reserve 0 -255 R1Dimmer 0 -255 R1Dimmer Dark-Bright G1Dimmer 0 -255 G1Dimmer Dark-Bright B1Dimmer 0 -255 B1Dimmer Dark-Bright W1Dimmer 0 -255 W1Dimmer Dark-Bright WWW.KUDUX.COM...

  • Page 17: Clear And Maintenance

    1. Cut off the power supply, cool down the lamp and open the covers. 2. Using vacuum or pressure blows gently blow any dust and floating structures. 12. Contact: website Please check who is our dealer in your country at our www.kudux.com or write direct to us by email: office@kudux.com WWW.KUDUX.COM...
