- Page 1 All manuals and user guides at all-guides.com XM1240S AT Commands Reference Manual ISDN Modem XM1240S AT Commands Reference Manual Version 106 Released 31. December 2007 No. XM1240S-A00-106 xmodus swiss GmbH 1 / 46...
- Page 2 No license is granted by implication or otherwise under any patent rights of xmodus swiss other than for circuitry embodied in xmodus products. Xmodus swiss reserves the right to change circuitry at any time without notice.
-
Page 3: Table Of Contents
Message formats....................35 CALLING NUMBER REPORT (CLIP) ..............36 ISDN ERROR CAUSE REPORT................36 X.31 CALL SETUP....................37 Setup outgoing X.31 call..................37 Reporting of X.25 causes and diagnostic codes ........... 39 No. XM1240S-A00-106 xmodus swiss GmbH 3 / 46... - Page 4 Table of the implemented standard profile............42 FIRMWARE UPDATE....................43 AUDIO MODES ......................44 AT Command Specifications: ................44 APPENDIX A ......................46 TABLE OF ISDN CAUSES (ETSI CAUSE VALUES) ..........46 No. XM1240S-A00-106 xmodus swiss GmbH 4 / 46...
-
Page 5: Introduction
GSM Socket Modems allows upgrading and production configurability without hardware changes. As a data modem, the AL5068S Socket Modem can send and receive data at speeds up to 64kbps and 128kbps in the 2-channel version. B-Channel protocols such as V.110, V.120, PPP, transparent and X.75 are supported. -
Page 6: Syntax And Procedures
The modem can accept at least 80 characters in the body. The termination character may not be selected by the user, the default is CR. Example: AT&FE0Q1S0=1S96=1<CR> No. XM1240S-A00-106 xmodus swiss GmbH 6 / 46... - Page 7 DTE and sending of the OK result code to the DTE is controlled by the S12 register (default 1 sec.). The escape characters will be transmitted transparent to the remote side. Example: [1s pause] <+><+><+> [1s pause] No. XM1240S-A00-106 xmodus swiss GmbH 7 / 46...
-
Page 8: At Command Set
AT&D2 DTR not ignored AT&D4 DTR only for disconnect AT&F Load factory defaults AT&K0 Flow control off AT&K3 RTS/CTS Flow control AT&K5 RTS/CTS Flow control AT&V Display configuration AT&W Store active configuration No. XM1240S-A00-106 xmodus swiss GmbH 8 / 46... -
Page 9: At Commands Help Screens
Ring indicator (125) [0: normal, 1: DCD, 2: ON, 4: OFF] ATS96=n B ch prot [1,3,20,21] (3: PPP) ATS97=n TEI for X.31 case B D-channel [n: 1..62] (5) ATS98=n Command echo [0: no, 1: yes] (1) No. XM1240S-A00-106 xmodus swiss GmbH 9 / 46... - Page 10 Result format [0: number, 1: text] (1) ATWn Extended result code [0..3] (0) ATXn Extended result code [0..4] (4) AT%Vn CONNECT message format [0..2] (1) AT%Wn Message compatability [0: AL5500, 1: AL5064, 2: Modem] (1) No. XM1240S-A00-106 xmodus swiss GmbH 10 / 46...
-
Page 11: Standard At Commands
Must be the last command in an AT command line. Any character input while the modem is dialing will cancel the dialing procedure. No. XM1240S-A00-106 xmodus swiss GmbH 11 / 46... - Page 12 ATI2 Reports “OK“ ATI3 Reports the Firmware Version string: "V.XX" ATI4 Reports the name of the manufacturers: "xmodus swiss GmbH" ATI5 Reports the ISDN protocol type: "0 - DSS1" ATI6 Reports the copyright string: "(c) Copyright xmodus swiss GmbH” ATI8...
- Page 13 This command enables or disables the sending of result codes to the DTE according to the parameter supplied. The parameter value, if valid, is written to S-Register S32. ATQ0 = Enables result codes to the DTE (default). ATQ1 = Disables result codes to the DTE. No. XM1240S-A00-106 xmodus swiss GmbH 13 / 46...
- Page 14 = ISDN error cause [text format] (see also section 5.2) <nr> = calling party number (see also section 5.2) ATW3 same as ATW2 but <nr> at CONNECT message is replaced with <datetime> element of L3 frame. No. XM1240S-A00-106 xmodus swiss GmbH 14 / 46...
- Page 15 CONNECT XXXX, Enables reporting of busy tones; send all messages. 3.3.16 ATZ Load stored settings The isdn-modem performs a soft reset and restores (recalls) the configuration profile. Must be the last command in an AT command line. Result codes: No. XM1240S-A00-106 xmodus swiss GmbH 15 / 46...
-
Page 16: At& Commands
S39 bits 0, 1, and 2. AT&K0 Disables flow control. AT&K3 Enables RTS/CTS flow control. Default for data modem modes. (default). AT&K5 Enables RTS/CTS flow control in data mode and command mode. No. XM1240S-A00-106 xmodus swiss GmbH 16 / 46... - Page 17 The current configuration is comprised of a list of storable parameters illustrated in the &V command. These settings are restored to the active configuration upon receiving an ATZ command or at power up. AT&W Store the current configuration profile. Result codes: No. XM1240S-A00-106 xmodus swiss GmbH 17 / 46...
-
Page 18: Special Configuration Commands
AT%B9 Fixed DTE baudrate = 230400 bit/s 3.5.2 AT%Wn Message compatibility modes. Sets the compatibilty of the result messages (see chapter 5) AT%W0 AL5068S Message Mode. AT%W1 AL5064S Message Mode (default). AT%W2 Modem Message Mode. 3.5.3 AT%Vn CONNECT message formats. -
Page 19: Isdn Services Commands
Defines the msn nn (multiple subscriber number) for the data port. If the number is set to “*“ (default), all incoming calls are acceptable. The msn can be displayed by command AT&V. AT$Z=nn set parameter "msni" and "msno" to nn No. XM1240S-A00-106 xmodus swiss GmbH 19 / 46... -
Page 20: Isdn Configuration Commands
The value of 1 is chosen for compatibility with other products. A value of 2 – 7 should be chosen for best performance (default = 7). AT**K=n n = 1 – 7 , default = 7 No. XM1240S-A00-106 xmodus swiss GmbH 20 / 46... -
Page 21: S-Registers
(stored by AT&W) is subsequently loaded, and may change some of the factory default values. The defaults shown are those used by xmodus as the factory profile. The default values shown in Table 4-1 may vary by modem firmware configuration. Consult the MCU firmware release notes for exact configuration. -
Page 22: S-Register Summary
1/10s Autobaud Options (AT%B) 0 – 9 X.75 / V.120 Window Size (AT**K) 1 – 7 B-Channel Protocol Options (ATB) 0 – 41 TEI Value 1 – 62 Command Echo Options (ATE) No. XM1240S-A00-106 xmodus swiss GmbH 22 / 46... -
Page 23: S-Register Definitions
S5 - Backspace Character S5 holds the decimal value of the ASCII character used as the backspace character. The default value corresponds to an 08h. Range: 0 – 255 , ASCII decimal Default: No. XM1240S-A00-106 xmodus swiss GmbH 23 / 46... - Page 24 S32 - Bit Mapped Options (ATQn Command) S32 sets the options of ATQn command. Range: 0,1 (Bit Mapped) Default: S32=0 Enables result codes to the DTE. S320 Disables result codes to the DTE. No. XM1240S-A00-106 xmodus swiss GmbH 24 / 46...
- Page 25 S-Register bit 0,1 and 2. See ATVn Command for configuration. Range: 0,1 (Bit Mapped) Default: Enables short-form (terse) result codes. Line feed is not issued before a S42=0 short-form result code. S42=1 Enables long-form (verbose) result codes. No. XM1240S-A00-106 xmodus swiss GmbH 25 / 46...
- Page 26 S45=0 ATW0 (see description of AT command ATWn) S45=1 ATW1 (see description of AT command ATWn) S45=2 ATW2 (see description of AT command ATWn) S45=3 ATW3 (see description of AT command ATWn) No. XM1240S-A00-106 xmodus swiss GmbH 26 / 46...
- Page 27 S49=0 RI functions as ring indicator (indicates incoming calls). S49=1 RI follows the state of the DCD signal. S49=2 RI remains ON at all times. S49=4 RI remains OFF at all times. No. XM1240S-A00-106 xmodus swiss GmbH 27 / 46...
- Page 28 Local baudrate set to 19200 bit/s S94=6 Local baudrate set to 38400 bit/s S94=7 Local baudrate set to 57600 bit/s S94=7 Local baudrate set to 115200 bit/s S94=9 Local baudrate set to 230400 bit/s No. XM1240S-A00-106 xmodus swiss GmbH 28 / 46...
- Page 29 B-Channel routed to IOM-2 (3.1kHz Audio) S96=50 B-Channel routed to IOM-2 / 2-channel mode (speech) S96=51 B-Channel routed to IOM-2 / 2-channel mode (data) S96=52 B-Channel routed to IOM-2 / 2-channel mode (3.1kHz Audio) No. XM1240S-A00-106 xmodus swiss GmbH 29 / 46...
- Page 30 The isdn-modem enables or disables the echo of characters to the DTE according to the parameter supplied. This Register is used in conjunction with AT Command ATEn. Range: 0,1 (Bit Mapped) Default: S98=0 Disables command echo. S98=1 Enables command echo. No. XM1240S-A00-106 xmodus swiss GmbH 30 / 46...
-
Page 31: Messages
5.1.4 AT%Wn Message compatibility modes Sets the compatibility of result messages (see section 5.2) AT%W0 AL5500S Mode. S40 = 0 AT%W1 AL5064S Mode. S40 = 1 (default) AT%W2 Modem Mode. S40 = 2 No. XM1240S-A00-106 xmodus swiss GmbH 31 / 46... - Page 32 = Transparent IOM-2 Bus on B1-Channel IOM-B2 = Transparent IOM-2 Bus on B2-Channel B-Channel protocols are displayed in brackets. LINE SPEED : 64000 = for all protocols except V.110 1200 = V.110 br 38400 Example: CONNECTED (V.120) No. XM1240S-A00-106 xmodus swiss GmbH 32 / 46...
-
Page 33: Message Formats
= ISDN error cause (displayed if ATW1 is set) Case 4 Alerting ATX ATV0 Modem Mode AL5064 Mode AL5500 Mode 0 – 2 ALERTING RINGING RINGING ALERTING RINGING <nr> Comments: <nr> = Calling Party Number (displayed if ATW1 is set) No. XM1240S-A00-106 xmodus swiss GmbH 33 / 46... -
Page 34: Message Formats
CONNECT <nr> CONNECT <opt> CONNECTED <opt> CONNECT <opt> <nr> Comments: <nr> = call number of remote side in brackets (displayed if ATW1 is set) <opt> = CONNECT message format selected by command AT%Vn. No. XM1240S-A00-106 xmodus swiss GmbH 34 / 46... -
Page 35: Message Formats
RING <nr> Comments: <nr> = call number of remote side in brackets (displayed if ATW1 is set) Case 11 OK Result ATX ATV0 Modem Mode AL5064 Mode AL5500 Mode 0 – 4 No. XM1240S-A00-106 xmodus swiss GmbH 35 / 46... -
Page 36: Calling Number Report (Clip)
send to modem ATD0449121234 received from modem RELEASED 17 Example 2: send to modem ATW2 received from modem send to modem ATD0449121234 received from modem RELEASED USER BUSY No. XM1240S-A00-106 xmodus swiss GmbH 36 / 46... -
Page 37: Call Setup
In case of X.31 D-Channel calls, the configured own X.25 address will be compared to the X.25 address of the local X.25 access point. If they are different, the X.25 packet handler will use its own configured X.25 number. No. XM1240S-A00-106 xmodus swiss GmbH 37 / 46... - Page 38 - using outgoing call from closed user group “05”, - using the NUI selection string "nuitest" - using the X.25 number 50005432 - and additionally X.25 user data “xxxxxxxx” with protocol-ID will be sent. No. XM1240S-A00-106 xmodus swiss GmbH 38 / 46...
-
Page 39: Reporting Of X.25 Causes And Diagnostic Codes
“RELEASED” message. For a more detailed description of the X.25 causes refer to the Appendix A.2. The X.25 causes are displayed in the following format. RELEASED (X.25: xx/yy) xx = X.25 causes yy = X.25 diagnostic codes No. XM1240S-A00-106 xmodus swiss GmbH 39 / 46... -
Page 40: Integrated Pad (X.3)
XM1240S AT Commands Reference Manual INTEGRATED PAD (X.3) If you connect an asynchronous DTE to the X.31-service, you can use the integrated PAD of the AL5068S Modem. Command Mode of X.3 PAD The command mode on X.31 connections uses the normal modem command set with the AT commands descriped in chapter 3. - Page 41 No line feed insertion AT$P13=1 Insert LF after transmission of CR to DTE AT$P13=2 Insert LF after each CR in the data stream from DTE AT$P13=4 Insert LF after echo of CR to DTE No. XM1240S-A00-106 xmodus swiss GmbH 41 / 46...
-
Page 42: Table Of The Implemented Standard Profile
No echo of control characters and <DEL> 7.4 Table of the implemented standard profile. Parameter Prof 0 (10) (11) (14) (15) (16) (17) (18) (19) (21) (22) Note: Parameter in Brackets are not implemented. No. XM1240S-A00-106 xmodus swiss GmbH 42 / 46... -
Page 43: Firmware Update
This transfer is done via the 1K X-Modem protocol. Put the new modem firmware file (i.e. AL5068S V1.13.txt) in an appropriate directory on the computer’s hard disk. Configure the communications application program (HyperTerminal) for a DTE rate of 115200, 8N1 and RTS/CTS flow control. -
Page 44: Audio Modes
ATA1B Answer call no 1 and direct to Codec B ATA2A Answer call no 2 and direct to Codec A ATA2B Answer call no 2 and direct to Codec B No. XM1240S-A00-106 xmodus swiss GmbH 44 / 46... - Page 45 Y = Calling Party number Z = Called Party number i.e. [1] RING 4556688 7108890 ATA1A<CR> [1] CONNECTED (IOM-B1) ATB52DB4664433 [2] ALERTING [2] CONNECTED (IOM-B2) 9.1.7 S-Register S0 In 2-channel mode S-Register S0 have no function. No. XM1240S-A00-106 xmodus swiss GmbH 45 / 46...
-
Page 46: Table Of Isdn Causes (Etsi Cause Values)
Message not compatible with call state 102 / 0xE6 Recovery on timer expiry 103 / 0xE7 Parameter non-existent or not implemented, passed on 111 / 0xEF Protocol error, unspecified 127 / 0xFF Network interworking error, unspecified No. AL5068S-A00-106 xmodus swiss GmbH 46 / 46...
