PCIeCANFD-400U User Manual
User
Industrial PCI-E Interface CAN (FD) Card
Manual
Category
Keywords
Abstract
PCIeCANFD-400U is a PCI Express x1 4-way CAN (FD) interface card. Backward compatibility with CAN
2.0 A/B standard enables PC/industrial computer to be connected to CAN/CAN(FD) network through the
PCI-E interface, which constitutes a data acquisition and data processing system in CAN/CAN(FD)
network applications such as laboratories, industrial control, and smart communities.
Contents
PCI Express, CAN(FD) interface card
©2022 Guangzhou ZLG Electronics Co., Ltd.
UM01010101 1.2 Date:
2022/5/20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCIeCANFD-400U and is the answer not in the manual?

Questions and answers

Related Manuals for ZLG PCIeCANFD-400U

Summary of Contents for ZLG PCIeCANFD-400U

  • Page 1 PCI Express, CAN(FD) interface card Abstract PCIeCANFD-400U is a PCI Express x1 4-way CAN (FD) interface card. Backward compatibility with CAN 2.0 A/B standard enables PC/industrial computer to be connected to CAN/CAN(FD) network through the PCI-E interface, which constitutes a data acquisition and data processing system in CAN/CAN(FD) network applications such as laboratories, industrial control, and smart communities.
  • Page 2 PCIeCANFD-400U PCIe Interface CAN (FD) Card User Manual Revision History Version Date Description V1.0 March 18, 2021 Created 2022 © Guangzhou ZLG Electronics Co., Ltd.

  • Page 3: Table Of Contents

    3.1 Installing the Driver under Windows ........................13 4. Packing List ..............................15 5. Quick Guide ..............................16 5.1 Introduction to ZCANPRO Software .......................... 16 5.2 Using PCIeCANFD on ZCANPRO ..........................16 6. Disclaimer ..............................17 。 2022 © Guangzhou ZLG Electronics Co., Ltd.

  • Page 4: Functions

    5 Mbps, which enables flexible and convenient applications. To improve system reliability, the PCIeCANFD-400U interface card adopts 2,500 V DC electrically isolated CAN (FD) transceiver module, which protects the computer from the influence of ground circulation and enhances the system reliability in harsh environments.

  • Page 5: Functions

    PCIeCANFD-400U PCIe Interface CAN (FD) Card User Manual Figure 1.1 PCIeCANFD-400U appearance 1.2 Functions ⚫ PC interface: high-speed PCIe interface, PCI Express x1 specification, compatible with x8, x16 and other PCI Express slots; ⚫ Comply with CAN FD ISO 11898-1:2015 specification (compatible with CAN 2.0A/B standard);...

  • Page 6: Specifications

    -40℃~+85℃. Using the interface card in too low or too high ambient temperature will make it work abnormally and shorten its service life. 1.4 Typical Applications ⚫ CAN(FD)-Bus network diagnosis and test ⚫ Electric power communication network ⚫ Industrial control equipment ⚫ Vehicle network debugging 2022 © Guangzhou ZLG Electronics Co., Ltd.

  • Page 7: Hardware Interfaces

    DB9 interface is connected to the actual CAN-bus network. Figure 2.1 DB37 connector converted into a 4-channel DB9 interface through a communication cable Figure 2.2 DB37 to 4xDB9 cable channel identification 2022 © Guangzhou ZLG Electronics Co., Ltd.

  • Page 8: Connector Definition

    Table 2.2 Pin definition of the OPEN5 socket Signal Description Interface Diagram Network power supply negative CAN_L CAN_L signal cable CAN_SHIELD Shielded cable CAN_H CAN_H signal cable Network power supply positive 2.3 DB-37 Connector Figure 2.3 DB-37 connector 2022 © Guangzhou ZLG Electronics Co., Ltd.
  • Page 9 Shielded cable CAN_GND Reference ground CAN_H CAN_H signal cable —— —— —— CAN_L CAN_L signal cable CAN_GND Reference ground —— CAN2 CAN_SHIELD Shielded cable CAN_GND Reference ground CAN_H CAN_H signal cable —— —— 2022 © Guangzhou ZLG Electronics Co., Ltd.

  • Page 10: Terminal Resistance

    —— 2.4 Terminal Resistance As shown in Figure 2.3, the CAN channel of the PCIeCANFD-400U interface card has a built-in 120Ω terminal resistance.The interface card uses the DIP switches S1_1, S1_2, S1_3, and S1_4 to select whether the terminal resistance of the corresponding CAN0, CAN1, CAN2, and CAN3 channels is connected to the bus network. As shown in Figure 2.4, set whether the CAN channel uses the 120 ohm terminal resistance.

  • Page 11: System Indicators

    Light off CAN channel not started After the PCIeCANFD-400U interface card is powered on, the system status indicator FPGA_RUN is green, indicating that the device is powered on, and the system is operating properly; if the system status indicator FPGA_RUN is off, the system power supply fails or a critical fault occurs in the system.

  • Page 12: Board Installation

    PCI-E slot before you install the driver. The installation procedure is as follows: Power off the computer and open the computer case cover; Insert the PCIeCANFD-400U series interface card into a free PCI-E slot, x1, x4, x8, or x16 slot; Tighten the screws to fix the board;...

  • Page 13: System Connections

    120 ohm terminal resistors. For branch connections, the length should not exceed 3 meters. Figure 2.2 shows the CAN-bus connection. Figure 2.8 Linear topology of CAN-bus network 2022 © Guangzhou ZLG Electronics Co., Ltd.
  • Page 14 Figure 2.9 Two-core single-layer shielded cable connection Figure 2.10 Double-core double-shielded cable connection Figure 2.11 Three-core single-layer shielded cable connection 2022 © Guangzhou ZLG Electronics Co., Ltd.

  • Page 15: Driver Installation

    Figure 3.1. Figure 3.1 Driver software As shown in Figure 3.2, click [Install] in the dialog box, and wait until the driver is installed. Figure 3.2 Installing the driver 2022 © Guangzhou ZLG Electronics Co., Ltd.
  • Page 16 CAN (FD) messages. It is recommended to use the ZCANPRO software provided by ZLG Electronics as the host computer software. Users can also develop their own host computer software by using the provided secondary development function library.

  • Page 17: Packing List

    PCIeCANFD-400U PCIe Interface CAN (FD) Card User Manual 4. Packing List Table 5.1 PCIeCANFD-400U Packing List V1.00 Name Quantity Unit Remarks PCIeCANFD-400U interface card Piece DB-37 to 4xDB-9 cable After-sales Service Guide Certificate of Conformity Piece 2022 © Guangzhou ZLG Electronics Co., Ltd.

  • Page 18: Quick Guide

    5. Quick Guide 5.1 Introduction to ZCANPRO Software ZCANPRO is the supporting software for CAN/CANFD series products produced by Guangzhou ZLG Electronics Co., Ltd., which can perform operations such as raw data transmission and reception, data playback, and high-level protocol analysis. The software is easy to operate and powerful, and it is a good helper for CAN bus testing, monitoring, diagnosis, and development.

  • Page 19: Disclaimer

    ZLG Electronics shall reserve the right to update this manual without prior notice. To get the latest version, please visit the official website of ZLG Electronics regularly or contact ZLG Electronics. Thank you! Right to modify the document Guangzhou ZLG Electronics Co., Ltd.
  • Page 20 Dreams come true with professionalism and dedication. Guangzhou ZLG For more details, please visit Welcome to call the national service hotline www.zlg.cn 400-888-4005 Electronics Co., Ltd.
