AXIS T8310 SERIES VIDEO SURVEILLANCE
CONTROL BOARD INTEGRATION
COMPLETEVIEW 20/20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AXIS T8310 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Salient AXIS T8310 Series

Summary of Contents for Salient AXIS T8310 Series

  • Page 1 AXIS T8310 SERIES VIDEO SURVEILLANCE CONTROL BOARD INTEGRATION COMPLETEVIEW 20/20...

  • Page 2: Table Of Contents

    Table of Contents Introduction Installation Plug and Play Device Management AXIS T8311 Joystick AXIS T8311 Joystick Functions AXIS T8312 Keypad AXIS T8312 Keypad Functions A Word About the Function Keys Mouse Mode AXIS T8313 Jog Dial AXIS T8313 Jog Dial Functions Troubleshooting Additional Resources...

  • Page 3: Introduction

    NTRODUCTION The AXIS T8310 Video Surveillance Control Board consists of three units that can be installed separately or together as one unit. The AXIS T8311 gives responsive and accurate control of the pan, tilt, and zoom functionality of the camera(s) on the network, while the AXIS T8312 is used to navigate quickly between cameras, views, and PTZ presets.

  • Page 4: Installation

    NSTALLATION The AXIS T8310 Video Surveillance Control Board adheres to traditional Windows hardware installation paradigms. Plug and Play Installation of the AXIS T8310 Video Surveillance Control Board driver is Plug and Play. The AXIS T8311 Video Surveillance Joystick, AXIS T8312 Video Surveillance Keypad, and AXIS T8313 Video Surveillance Jog Dial can be connected separately or together as one unit using the AXIS T8312 Video Surveillance Keypad as a USB hub.
  • Page 5 In addition, the joystick will also appear as a game controller. Select Start > Control Panel > Game Controllers or Start > Settings > Devices depending on operating system to view it.

  • Page 6: Axis T8311 Joystick

    AXIS T8311 J OYSTICK The AXIS T8311 joystick is a USB device that can be used to pan, tilt, and zoom in the camera view. It can also be used as a mouse. AXIS T8311 Joystick Functions The diagram below provides an overview of the functions of the joystick specific to . Consult the table below for more detail.
  • Page 7 Control Description Joystick X-Axis Pan Right/Pan Left and Mouse Control Joystick Y-Axis Pan Up/Pan Down and Mouse Control Joystick Z-Axis Zoom In/Out...

  • Page 8: Axis T8312 Keypad

    AXIS T8312 K EYPAD The AXIS T8312 Video Surveillance Keypad is a USB device used to quickly navigate between workspaces, cameras, views, and PTZ presets. AXIS T8312 Keypad Functions The diagram below provides an overview of the functions of the keypad specific to Com- pleteView 20/20.
  • Page 9 Control Description Navigates to Playback Review Video. Populates the video for the selected camera tile in Live View and automatically fills in the time for the 24 hour scale. Navigates to Playback List Search. Populates the search for the selected camera tile in Live View. Navigates to Playback Thumbnail Search.

  • Page 10: Mouse Mode

    Control Description Review window with the entered playback time in minutes. For example, entering 2 will open Quick Review automatically with 2 minutes of playback. Entering 0 and then pressing the Quick Review button will stop Quick Review for the selected camera tile.

  • Page 11: Axis T8313 Jog Dial

    AXIS T8313 J The AXIS T8313 Video Surveillance Jog Dial is a USB device used to jog and shuttle through recorded video. AXIS T8313 Jog Dial Functions The diagram below provides an overview of the functions of the jog dial specific to Com- pleteView 20/20.
  • Page 12 ALARM VIEW: Takes a snapshot of the Live View tile of the cur- rently selected Event. Note: Snapshots are automatically saved to the Documents folder of the current Windows user. (e.g. C:\User- s\<user>\Documents\Salient Security Platform\CompleteView 2020\Desktop Client) ALARM VIEW: Exports the Playback video clip of the currently selected Event.

  • Page 13: Troubleshooting

    ROUBLESHOOTING Note that the control boards are not designed to work with multiple open instances of the Desktop Client. In addition, the hardware must be plugged in before the Desktop Client is launched. If the AXIS T8310 Video Surveillance Control Board is or becomes unresponsive, begin troubleshooting by restarting the CompleteView 20/20 Desktop Client.

  • Page 14: Additional Resources

    Salient Systems 4616 W. Howard Ln. Building 1, Suite 100 Austin, TX 78728 512.617.4800 512.617.4801 Fax www.salientsys.com ©2020 Salient Systems Corporation. Company and product names mentioned are registered trademarks of their respective owners.

This manual is also suitable for:

Axis t8311Axis t8312Axis t8313
