- Page 1 ® ClearClick Portable Photo & Document Scanner Quick Start Guide & User’s Manual Full 1-Year Warranty & Free USA-Based Tech Support support@clearclick.tech www.ClearClick.tech...
- Page 2 QUICK START GUIDE #1: How To Use The Scanner Without A Computer (Recommended) 1. Load three (3) AA batteries into the device. (Not included.) We highly recommend “Energizer Ultimate Lithium” batteries. These batteries will allow you to make hundreds of scans per set of batteries.
- Page 3 memory card are facing up. The scanner accepts any microSD memory card that is 32 GB or less. We recommend “SanDisk” brand. 3. Turn on the scanner by pressing and holding the power (center) button. 4. Set the scanning resolution and file type.
- Page 4 5. Start scanning! Adjust the size of the paper tray. Then, feed a photo or document into the scanner (face up), and the device will automatically pull it through the scanner and save the image onto the memory card. (Not included.) 6.
- Page 5 a. Ensure that the scanner is turned on. b. Connect the scanner to your PC or Mac using the included USB cable. c. The scanner will show up as a new drive on your computer. d. Browse the folders on your PC or Mac and navigate to the new drive.
- Page 6 transfer them to your computer by dragging them into any folder on your computer.
- Page 7 QUICK START GUIDE #2: How To Scan Images Directly To A PC (PC/Windows Users Only; Mac Users, Please Use Quick Start Guide #1) 1. Download and install the included OCR software from: www.photo2usb.com/OCR.zip 2. Connect the scanner to your computer using the included USB cable.
- Page 8 4. Wait a minute for your computer to install the scanner automatically. 5. Open the DirectScan Pro software on your computer. 6. Adjust the size of the paper tray on the scanner with the slider. 7. To scan a photo or to scan a document as an image: a.
- Page 9 c. Important! After your document or photo scans, it will be placed on your computer’s clipboard, not saved as a file. To save your image as a file, simply open a software program such as Microsoft Word or Paint, and click “Paste”...
- Page 10 up). c. Important! After your document scans, the text will be placed on your computer’s clipboard, not saved as a file. To save your text, simply open a software program such as Microsoft Word or your email software, and click “Paste” to paste in your scanned text.
-
Page 11: Need Some Help
DirectScan Software” section. Need Some Help? Open a support ticket with us at: www.clearclicksoftware.com/help/ Or email us at support@clearclick.tech with a detailed description of your issue. Please include your order number. We’ll get back to you within 24-48 hours during normal business hours... - Page 12 Register Your Product & Extend Your Warranty for FREE Register your product and extend your warranty by 1 year for free! It takes just 30 seconds at: www.clearclicksoftware.com/Register/...
-
Page 13: Troubleshooting & Faqs
Use a can of compressed air to clear the scanning area. If this does not fix it, please contact us at support@clearclick.tech. Black bars or stripes usually indicate a malfunction with one of the scanner’s internal components. - Page 14 warranty. 2. What type of batteries work best with the scanner? We highly recommend Energizer Ultimate Lithium batteries. You will get hundreds of scans out of each set of batteries. 3. I’m trying to scan images or text with the software. After I scan an image, I don’t see where the software scans my image.
- Page 15 scanning, open Microsoft Word or Paint, and paste in your image/text. Then save the scan as an image from there. 4. The software isn’t working with my Mac. The included software is PC only. If you are running a Mac, you must use the scanner as a standalone device.
- Page 16 5. The DirectScan OCR software is not recognizing my text correctly. Please make sure you are scanning your document upright (so that you can read it as you are putting it in the scanner). The software will not be able to read the document if it is inserted sideways or upside down.
- Page 17 Scanner Diagram Button What Does It Do? Preview the scanning Enter image In scanning mode, chooses Up / the resolution Resolution In menu mode, goes “up” Pressing 2 seconds turns on or off the scanner Power/Scan In menu mode, works as an “OK”...
- Page 18 SD Card The place to insert the Slot Micro SD memory card In scanning mode, chooses the scanned image file Down / File format Format In menu mode, goes “down” Open or close the options Menu menu The place to plug in the USB cable.
- Page 19 LCD Screen Diagram Name What It Shows Time Shows the current time Shows how many images Images on are currently saved on the Card memory card Encrypting scanned Encryption images Status Not encrypting scanned images...
- Page 20 Shows if a memory Memory card is currently inserted Card Status Shows if the memory card is full Displays the chosen Resolution resolution in DPI Shows what file format Format the scanned images are Select being saved in Shows if the scans are Color or being saved in color or B&W...
- Page 21 How Many Images Can I Store On The Scanner? The number of images you can store on the scanner depends on how large of a memory (MicroSD) card you are using and the quality/resolution that you are scanning images at. Refer to the table below.
- Page 22 How To Open The Options Menu Turn on the scanner and press the menu (right) button. Scroll through the menu options to find the one you desire. To open a setting, select it and press the middle (power) button. Choose the desired setting and press the middle (power) button again.
- Page 23 option and press the OK (middle) button. How To Set The Scanning Resolution With the scanner at the main screen, press the “DPI” (up/top) button, until the desired screen resolution shows in the right corner of the screen How To Set The File Format With the scanner at the main screen, press the “JPG/PDF”...
- Page 24 How To Turn On/Off File Encryption Open the options menu and select the “Encryption” menu ( ). Press the middle (OK/power) button to open the Encryption menu. Choose the desired option and press the OK (middle) button. When in encryption mode, the scanner will encrypt the images when it saves them.
- Page 25 (OK/power) button to open the Format menu. Choose the yes/checkmark option and press the OK (middle) button. This will erase the images on the memory card. Note: after formatting, all the data on the memory card will be deleted. Please make sure you want to do this before continuing! How To Set The Time &...
- Page 26 How To Preview & Delete Scanned Images While the scanner is on, hold down the “Play” (left) button. The scanner will open a preview of the last scanned image. You can scroll through these images to preview them. You can also delete individual images by pressing the Trash (right) button.
- Page 27 Click “Next” until the installation completes. Note: the DirectScan Pro software is only compatible with Windows. If you use a Mac computer, please use Quick Start Guide #1 instead. Using The DirectScan Pro Software After the software has installed, double-click on the DirectScan Pro icon on your desktop.
- Page 28 Button 1: “Picture Direct” This program allows you to scan a photo or a document (as an image). To use the program, click the button, and then insert a photo or document into the scanner. The scanned image will be placed on your computer’s clipboard.
- Page 29 computer’s clipboard. To access the text, open a program like Microsoft Word or your email client and click “Paste.” The text will be inserted into your document or email. Button 3: BCR Direct This program will allow you to scan and organize business cards.
-
Page 30: Technical Specifications
text. Click the “Scan and OCR” button to open this program. Technical Specifications Scanning Resolution: 300DPI (default), 600DPI , 1200DPI Maximum Scanning Size: 8.5” wide and 47” long Scanning Format: JPG, PDF, or computer’s clipboard Storage: MicroSD Card (not included) or Power Source: 3x AA batteries (not included) or USB Computer Requirements: No computer... -
Page 31: Important Safety Instructions
direct to computer scanning, a Windows Vista/7/8/10 or higher PC is required. Important Safety Instructions Please read these safety instructions before use and follow them: 1. Do not disassemble the unit. 2. Do not operate the unit in very hot weather. - Page 32 7. Follow all copyright laws in your country. This product should not be disposed with other household wastes. To prevent possible harm to the environment or human health from uncontrolled wash disposal, recycle it responsibly to promote the sustainable reuse of material resources.
- Page 33 B FCC limits. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: this device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation...
- Page 34 Email: support@clearclick.tech Web: www.ClearClick.tech...
