ClearClick
Virtuoso
2.0
Film & Slide Scanner
22MP
Quick Start Guide & User's Manual
2-Year Warranty &
Free USA-Based Tech Support
This product comes with a 2-year warranty & free USA-
®
based tech support from ClearClick
. As a small business,
we're here to serve you! If you have any issues with our
product, please contact us at support@clearclick.tech.
www.ClearClick.tech
Advertisement
Related Manuals for ClearClick Virtuoso 2.0
Summary of Contents for ClearClick Virtuoso 2.0
- Page 1 This product comes with a 2-year warranty & free USA- ® based tech support from ClearClick . As a small business, we’re here to serve you! If you have any issues with our product, please contact us at support@clearclick.tech. www.ClearClick.tech...
-
Page 2: Safety Precautions
Extend Your Warranty for FREE! Extend your warranty by one year for free simply by registering your product at: www.ClearClick.tech Browse All Our Products… If you’re looking for fun, unique, and easy-to- use technology, we’ve got it! Please visit our website to browse all of our products: www.ClearClick.tech... - Page 3 Thank You ® Thank you for your purchase of the ClearClick ® Virtuoso 2.0 Film & Slide Scanner! We are a small business and appreciate your order. ® At ClearClick , we try to make our technology as clear to understand and use as possible. But if you get stuck at any point, you qualify for FREE USA- ®...
-
Page 4: What's In The Box
• USB Cable & Power Adapter • Cleaning Brush • User’s Manual BUNDLE EDITION ONLY: • SD Card & Photo Editing Software Not Included: • Mini HDMI Cable (Optional – for TV Output) Missing any parts? Need help? Please contact us at: support@clearclick.tech... - Page 5 ® Virtuoso 2.0 Quick Start Guide 1. Insert an SD card into your scanner. First, insert an SD memory card (not included) into the slot in the back of the scanner. The card must be 32 GB or less and “Class 10” or higher.
- Page 6 4. Select the first menu option (“Scan/Settings”) and press OK. Using the arrow buttons and OK button, select the first option in the main menu (Scan/Film Settings). You will then be able to choose what you would like to scan – Slides, Color Negatives, or Black &...
- Page 7 5. Prepare & insert your slides/negatives. To scan slides: open the main holder (shown below). Insert one slide and close the holder. Then insert the holder into the right side of the scanner as shown on the next page. To scan negatives: open the main holder. Select the appropriate adapter (135/35mm, 126, or 110) and place it inside the main holder.
- Page 8 Inserting the main holder into the device. 6. Set the scanning resolution, brightness, and RGB color. (Optional) If you want, you can adjust the scanning resolution, brightness, and RGB color before scanning. To adjust the scanning resolution, press the button. The set value (14 or 22 Megapixels) is shown on the lower right hand side of the preview screen.
- Page 9 7. Start scanning your images! To scan an image, just press the button. The scanner will scan the image shown on the LCD screen. The image will be saved on your SD memory card as it appears on the screen. 8.
- Page 10 c. Use the Left () and Right () buttons to navigate through the main menu to select “USB” , then press the “OK” button. d. When the scanner establishes communications with the computer, the screen will display the following: e. The memory card will now appear on your computer as a removable external drive.
- Page 11 g. Press the “Home / P” button to exit uploading mode and return the scanner to the Main Menu. 9. For other options and details of using ® the Virtuoso 2.0 scanner, please refer to the subsequent sections of this manual.
- Page 12 How To View or Delete Scanned Images On The Device To view images you’ve already scanned on the device’s screen, first press the Main Menu (Home) button: At the main menu, use the arrow buttons to select the Photo Gallery option, and press the OK button.
- Page 13 How To Connect The Scanner To A TV Using a Mini-HDMI-to-HDMI cable (not included), connect the scanner to your TV. Turn on the scanner and set your TV to the correct input, and you will see the display of the scanner on the TV. How To Change The Scanner’s Date/Time From the scanner’s main menu (press the “Home”...
- Page 14 Icon Details Icons Functions and Indication Scanning films Connect SD Card to Computer Reviewing scanned photos in the SD card Setting date and time For transparent film and 50X50mm slides For color negative film For black and white film For 135 film, 24X36mm picture size film For 110 film, 13X17mm picture size film For 126 film, 28X28mm picture size film Selected film type shown on preview :Transparent film...
- Page 15 SD card malfunction: Not loaded, locked, or not compatible Reviewing picture from card: single picture Reviewing pictures from card: Slide show Brightness(EV) adjustment scale RGB color adjustment scale RGB color adjustment recover to default setting RGB color selection and reset Single image delete selection All scanned images delete selection Indicate SD card and computer successfully connected...
- Page 16 Technical Specifications Image Sensor 1/2.33” 14 Mega CMOS Sensor, 5” all angle Color LCD Preview and Review Display Lens Specification F/No. 3.5, 5 elements lens Color Balance Automatic Exposure Control Automatic & Manual adjustment Film Size 135 Negative & Slide (3:2) Auto Cropping 110 Negative &...
- Page 17 Focusing Fixed Focus EV adjustment Yes, + - 2.0 EV RGB Color adjustment PC Interface USB 2.0 Image Format 135 Negative 3:2 Ratio 110 Negative 4:3 Ratio 126 Negative, 1:1 Ratio Light Source White LED Panel Power Source From computer USB port, 5V/1A Power adaptor / Power Bank USB Connector...
-
Page 18: Need Help
Need help? Open a support ticket and we’ll get back to you within 24-48 hours! Just visit: http://Support.ClearClickSoftware.com or email us at: support@clearclick.tech... - Page 20 © 2020 ClearClick Software LLC. All rights reserved.
