Cisco Memory Card MEMCUE-256D= Installation Manual page 4

Figure 2
Step 5 Carefully and firmly press the 256-MB SDRAM DIMM into the connector until the latches close onto
the SDRAM DIMM. Make sure that both latches rotate to the closed position against the SDRAM
DIMM. (See
1 Additional 256 memory card
Figure 3
2
1
256-MB SDRAM DIMM memory card
Reinstall the NM-CUE daughter board on the NM-CUE firmly seating the daughter card on the system
Step 6
board connector pins. (See
Installing the NM-CUE 256-MB SDRAM DIMM Memory Card
4
SDRAM DIMM Showing Polarization Notch
Figure 3.)
SDRAM DIMM Latches
Figure 4.)
Polarization notch
2 Existing 256 memory card
1
2
256-MB SDRAM DIMM latches
2
