Cisco Memory Card MEMCUE-256D= Installation Manual page 3

Figure 1
3
1 Daughter card screws
2 Daughter card
Step 2 Locate the existing 256-MB SDRAM DIMM memory card socket on the NM-CUE. (See
Make sure that both latches on the SDRAM DIMM connector are in the open position.
Step 3
Orient the SDRAM DIMM so that the polarization notch lines up with the polarization key on the
Step 4
connector. (See
78-16927-01
NM-CUE System Board with Daughter Card
1
2
4
Figure 2.)
3 NM-CUE module screws
4 256-MB SDRAM DIMM
Installing the NM-CUE 256-MB SDRAM DIMM Memory Card
Figure 1.)
3
