- Page 1 iReceptal Digital Surgical Suction System Site Preparation, Installation, and Maintenance Guide 100～240 VAC Docking Station REF iRD301-01 ONLY Instructions For Use SL 5107 Rev. A.
-
Page 2: Table Of Contents
Contents Introduction ............................3 Conventions ..........................3 Contact Information ........................3 Indications For Use ........................... 3 Contraindications For Use........................ 3 For Use With ............................3 Accessories ............................4 Description ............................4 User/Patient Safety ........................... 4 General ............................5 Electrical Safety ........................5 Environmental/Biological ...................... -
Page 3: Introduction
NOTE: A note supplements and/or clarifies procedural information. Contact Information For additional information, including safety information, or in-service training, contact your AMSINO sales representative or call AMSINO iReceptal Customer Service at XXXXXX. Indications For Use The iReceptal Digital Surgical Suction System is intended to be used in the operating room, pathology, surgical centers, and doctor’s offices to collect and dispose of surgical fluid waste as well as collect smoke generated... -
Page 4: Accessories
Power Cord (EU) iRA107-01 NOTE: For a complete list of accessory information, contact your AMSINO sales representative or call AMSINO iReceptal Digital Surgical Suction System Customer Service. Description The iReceptal Docking Station (docker) is a component of the iReceptal Digital Surgical Suction System. The Stryker Rover (rover), another component of the system, is a mobile unit used to suction and collect fluid waste and surgical smoke from a surgical site in an operating room. -
Page 5: General
• Healthcare professionals should be thoroughly familiar with the instructions for use, handling characteristics, and the indicated and intended uses of this equipment. Contact your AMSINO sales representative or AMSINO iReceptal Digital Surgical Suction System Customer Service for in-service training. -
Page 6: Environmental/Biological
following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. • Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radioexempts de licence. -
Page 7: Features
environmental contamination and result in injury. Features Figure 3 Docking Station Front view Figure 4 Docking Station Back view Magnet– Provide for the automatic connection of the rover to the docker. Infrared Communication Port – Allow infrared data transfer between the docker and rover. Data transfer is necessary during the docking procedure. -
Page 8: Symbols
Specification Label – Symbols The following symbols appear on the device and/or its labeling. For more information, see “Technical specifications” Symbol Description ON (POWER) OFF (POWER) ALTERNATING CURRENT (AC) General warning Consult instructions for use Follow instructions for use This symbol is located near the protective ground locations on this device DETERGENTADD PORT WASTE OUTLET PORT... -
Page 9: Instructions
Instructions To Install the Docker � � � WARNING HEAVY EQUIPMENT – ALWAYS have more than one person unpack and move this ： equipment from the shipping pallet. See the Specifications section for rover weight. Failure to comply may result in personal injury. -
Page 10: To Install The Docker And Connect Utilities
required. • Make sure the plumbing configuration is NOT susceptible to water hammer conditions. • Make sure the waste outlet hose is connected properly to minimize the escape of noxious fumes and odors. Figure 6 Minimum Floor Space Requirements Left-Side Clearance No minimum requirement 15 cm Right-Side Clearance... -
Page 11: To Apply Power, Water, And Detergent
Figure 7 To Connect the Waste Outlet Hose e. Connect the power cord between the electrical receptacle of the docker and the facility electrical power source. To Apply Power, Water, and Detergent a. Press the power switch ON. Make sure the power switch illuminates. b. -
Page 12: To Prepare The Rover
CAUTIONS: • DO NOT put any objects, including hoses, tubes, towels or detergent bottles, on or over the docker enclosure. Failure to comply may cause corrosion. • DO NOT allow fluid of any kind to spill directly onto the exterior surface of the electrically-powered docker. Failure to comply may cause corrosion or product failure. -
Page 13: To Prepare The Dock
2. To Prepare the Docker a. Make sure the power switch is in the ON position and illuminated. b. Make sure the canister of Detergent has enough detergent to perform a wash cycle. Figure 10 To Prepare the Docker 3. To Perform a Wash Cycle a．... -
Page 14: To Shut Down The Docker
• If a specific wash cycle is not selected within ten seconds, the “Wash” cycle will be performed automatically. See the Wash Cycle Options table. • To exit the current wash cycle, push the “Suction Off/Stop Docking” button to terminate the current a wash cycle and the rover detaches from the docker automatically. -
Page 15: Add The Detergent
Only individuals trained and experienced in the maintenance of reusable medical devices should install, • inspect, and test this equipment. For service, contact your AMSINO sales representative or call AMSINO iReceptal Customer Service. • Outside the US, contact your nearest AMSINO subsidiary. -
Page 16: Cleaning
DO NOT reuse the empty container. CAUTION: Use only AMSINO iReceptal Detergent REF iRC003 with the docker. Failure to comply will result in damage to rover and docker internal components. 1. Remove the detergent canister lid tube from the docker. -
Page 17: Storage And Handling
Contact local distributor for disposal information. Ensure infected equipment is decontaminated prior to recycling. Troubleshooting NOTE: For service, contact your AMSINO sales representative or call AMSINO iReceptal Customer Service. Outside the US, contact your nearest Stryker subsidiary. PROBLEM CAUSE... -
Page 18: Error Messages
Water inlet hose is leaking. Water inlet hose connection is not Make sure the water inlet hose secure. connection is secure. Water inlet hose is damaged. Replace the water inlet hose. Waste outlet hose is leaking. Waste outlet hose connection is Make sure the waste outlet hose not secure. - Page 19 Ingress Protection (IP): IPX0 Light Emitting Diode (LED) WARNING: INVISIBLE LED RADIATION Classification (infrared DO NOT VIEW DIRECTLY WITH OPTICAL INSTRUMENTS CLASS communication windows): 1M LED PRODUCT — Viewing the laser output with certain optical instruments (for example, eye loupes, magnifiers and microscopes) within a distance of 100 mm may pose an eye hazard.
- Page 20 Guidance and manufacturer's declaration - electromagnetic emissions The iReceptal 3 Dockers, REF iRD301-01 and REF iRD302-01, is intended for use in the electromagnetic environment specified below. The customer or the user of the iReceptal 3 Dockers, REF iRD301-01 and REF iRD302-01, should assure that it is used in such an environment.
- Page 21 IEC 61000-4-11 for 5 cycles for 5 cycles during power mains interruptions, it is 70% U 70% U recommended that the iReceptal 3 (30% dip in U (30% dip in U Dockers, REF iRD301-01 and REF for 25 cycles for 25 cycles iRD302-01, be powered from an <5% U <5% U...
- Page 22 considered. If the measured field strength in the location in which the iReceptal 3 Dockers, REF iRD301-01 and REF iRD302-01, are used exceeds the applicable RF compliance level above, the iReceptal 3 Dockers, REF iRD301-01 and REF iRD302-01, should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating the iReceptal 3 Dockers, REF iRD301-01 and REF iRD302-01.
