Haier HSU-24HEA03 Operation Manual
Split type room air conditioner
Hide thumbs
Also See for HSU-24HEA03:
- Operation manual (26 pages) ,
- Service manual (61 pages) ,
- Operating manual (19 pages)
Subscribe to Our Youtube Channel
Related Manuals for Haier HSU-24HEA03
Summary of Contents for Haier HSU-24HEA03
-
Page 1: Operation Manual
SPLIT TYPE ROOM AIR CONDITIONER OPERATION MANUAL HSU-24HEA03(T3) HSU-24LEA03(T3) HSU-24HEA13(T3) HSU-24LEA13(T3) HSU-30HEA13(T3) HSU-30HEA03(T3) Please read this operation manual before using the air conditioner. 0010518784... - Page 2 Damaged air conditioners are not to be put into operation. In case of doubt, consult your supplier. Use of the air conditioner is to be carried out in strict compliance with the relative instructions set forth in the User's Guide.
-
Page 3: Specifications
Cautions Do not obstruct or cover the ventilation grille of the air conditoner.Do not put fingers or any other things into the inlet/outlet and swing louver. Do not allow children to play with the air conditioner.In no case should children be allowed to sit on the outdoor unit. -
Page 4: Safety Instruction
Installation Please call Sales/Service Shop for the Installation. Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. lnstallation in a inadequate place may cause accidents. Do not install in the following place. - Page 5 Cautions When abnormality such as burnt-small found, immediately stop the operation button and contact sales shop. Connect power supply cord to the outlet completely STRICT ENFORCEMENT Do not use power supply cord in a bundle. PROHIBITION Do not start or stop the operation by disconnecting the power supply cord and so on.
-
Page 6: Parts And Functions
Anion generator (inside) Vertical blade(inside) (adjust left and right air flow) Note:The inlet grill will not be risen automatically,when the unit is placed with the inlet grill upward. Outdoor Unit HSU-24HEA03(T3) HSU-24LEA03(T3) HSU-24HEA13(T3) HSU-24LEA13(T3) OUTLET INLET Air filter(inside) display board(inside) - Page 7 Parts and Functions POWER/SOFT 1.CODE Used to select CODE A or B with a press,A or B will be displayed on LCD. Please select A without special explanation. 2.RESET When the remote controller appears abnormal, use a sharp pointed article to press this button to reset the remote controller normal.
- Page 8 Parts and Functions Clock Set When unit is started for the first time and after replacing batteries in remote controller, clock should be adjusted as follows: 1. Press CLOCK button,"AM" or "PM" flashes. 2. Press to set correct time. Each press will increase or decrease 1 min.
-
Page 9: Operation
BRIEF INTRODUCTION TO HEALTH ANION FUCTION The anion generator in the air conditioner can generate a lot of anion effectively balance the quantity of position and anion in the air and also to kill bacteria and speed up the dust sediment in the room and finally clean the air in the room. -
Page 10: Auto Operation
Press FAN button. For each press, fan speed changes as follows: Remote controller: Air conditioner is running under displayed fan speed. When FAN is set to AUTO, the air conditioner automatically adjusts the fan speed according to room temperature. 4.Unit stop Press ON/OFF button, the unit stops. -
Page 11: Cool Operation
Press FAN button. For each press, fan speed changes as follows: Remote controller: Air conditioner is running under displayed fan speed. When FAN is set to AUTO, the air conditioner automatically adjusts the fan speed according to room temperature. 5.Unit stop Press ON/OFF button, the unit stops. -
Page 12: Dry Operation
4.Fan speed selection Press FAN button. For each press, fan speed changes as follows: Remote controller: Air conditioner is running under displayed fan speed. In DRY mode, when room temperature becomes lower than temp.setting+2 at LOW speed regardless of FAN setting. -
Page 13: Fan Operation
Operation Fan Operation Remote controller POWER/SOFT 1. Unit start Press ON/OFF on the remote controller, unit starts. 2.Select operation mode Press MODE button. For each press, operation mode changes as follows: Remote controller: AUTO COOL Then Select FAN operation 3.Fan speed selection Press FAN button. -
Page 14: Heat Operation
Air conditioner is running under displayed fan speed IN HEAT mode, warm air will blow out after a short period of the time due to cold-draft prevention function. When FAN is set to AUTO, the air conditioner automatically adjusts the fan speed according to room temperature. -
Page 15: Air Flow Direction Adjustment
Operation Air Flow Direction Adjustment 1.Status display of air sending POWER/SOFT 2.Up and down air flow direction For each press of SWING button, air flow direction on remote controller displays as follows according to different operation modes: COOL/DRY/FAN remote controller: Pos.1 HEAT: remote controller:... -
Page 16: Sleep Operation
Operation Sleep Operation Before going to bed, you can simply press the SLEEP button and unit will operate in SLEEP mode and bring you a sound sleep. Use of SLEEP function After the unit starts, set the operation status, then press SLEEP button before which the clock must be adjusted and time being set. -
Page 17: Timer On/Off Operation
Operation Timer On/Off Operation Remote Controller POWER/SOFT Hints: After replacing batteries or a power failure happens, time setting should be reset. Remote controller possesses memory function, when use TIMER mode next time, just press SET button after mode selecting if time setting is the same as previous one. Set clock correctly before starting TIMER operation. - Page 18 Operation Timer On-Off Operation Remote Controller POWER/SOFT Set clock correctly before starting TIMER operation. 1. After unit starts, select your desired operation mode 2. Timer mode selection Press TIMER button to change TIMER mode. Every time the button is pressed, display changes as follows: Remote controller: TIMER ON TIMER OFF...
-
Page 19: Power Operation
Operation POWER/SOFT Operation POWER Operation When you need rapid heating or cooling, you can use this function. Remote controller Selecting of POWER operation Press POWER/SOFT button. Every time the button is pressed,display changes as follows: Stop the display at In POWER operation status: In COOL mode, fan speed automatically takes high speed of AUTO fan mode. -
Page 20: Health Airflow Operation
3.In cooling, it is better to select the mode. 4.In cooling and dry, using the air conditioner for a long time under the high air humidity, a phenomenon falling drips of water occurs at the outlet grille . 5.Select the appropriate fan direction according to the actual... -
Page 21: Emergency Operation
Operation Emergency and Test Operation Emergency operation Use this operation only when the remote controller is defective or lost. When the emergency operation switch is pressed,the" Pi "sound is heard once, which means the start of this operation. In this operation, the system automatically selects the operation modes,cooling or fan or heat,according to the room temperature. -
Page 22: Maintenance
Maintenance For Smart Use of The Air Conditioner Setting of proper room temperature Close doors and windows during operation During cooling operation prevent the penetration of direct sunlight with curtain or blind If the unit is not to be used for a long time, turn off the power supply main switch. - Page 23 Gasoline,benzine, thinner or cleanser may damage the coating of the unit. Indoor Body Wipe the air conditioner by using a soft and dry cloth.For serious stains,use a neutral detergent diluted with water.Wring the water out of the cloth before wiping.then wipe off the detergent completely.
-
Page 24: Replacement Of Air Purifying Filter
Maintenance Replacement of Air Purifying Filter 1.Open the lnlet Grille Prop up the inlet grille by using a small device named grille-support which located in the right side of the ind- oor unit. 2.Detach the standard air filter Slide the knob slightly upward to release the filter, then withdraw it. -
Page 25: Troubleshooting
When the electric plug is pulled out and reinserted, the protection circuit will work for 3 minutes to protect the air conditioner. During unit operation or at stop, a swishing or gurgling noise may be heard. At first 2-3 minutes after unit start, this noise is more noticeable.
