Page 1: Operation Manual
SPLIT TYPE ROOM AIR CONDITIONER OPERATION MANUAL HSU-24CG13-B Please read this operation manual before using the air conditioner. 0010518***... - Page 2 Damaged air conditioners are not to be put into operation. In case of doubt, consult your supplier. Use of the air conditioner is to be carried out in strict compliance with the relative instructions set forth in the User's Guide.
-
Page 3: Specifications
Always remember to unplug the air conditioner before openning inlet grill. Never unplug your air conditioner by pulling on the power cord. Always grip plug firmly and pull straight out from the outlet. All electrical repairs must be carried out by qualified electricians. - Page 4 Cautions The machine is adaptive in following situation I. Applicable ambient temperature range: Indoor Cooling Outdoor 2. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similar qualified person. The type of connecting wire is H05/07 RN-F or 245IEC57(YZW). 3.
-
Page 5: Parts And Functions
Outdoor Unit OUTLET INLET Timer mode indicator Lights up when Timer operation is selected. HSU-24CG13-B CONNECTING PIPING AND ELECTRICAL WIRING DRAIN HOSE Test running switch(manual) Used only for test running in cooling when room temp. is below 16 Don't use it in normal operation. -
Page 6: Clock Set
NOTE:(1)The following functions and related displays are not available: AUXILIARY HEAT display, POWER/SOFT display, LOCK display. (2)If the Air conditioner don't have the function of the code ,press code B can cause it not available. (3)Cooling only unit do not have functions and displays related with heating. -
Page 7: Operation
When sudden power failure happens during unit operation in power failure resume mode, if the air conditioner is not desired for use in a long period, please shut off the power supply in case that the unit automatically resume operation when power is re-supplied, or press... - Page 8 Operation Auto run, Fan operation (1) Unit start Press ON/OFF button, unit starts. Previous operation status appears on display. (Not Timer setting) Power indicator on indoor unit lights up. (2) Select operation mode Press MODE button. For each press, operation mode changes as follows: AUTO COOL...
-
Page 9: Cool And Dry Operation
Operation COOL and DRY operation Recommendations: (1) Unit start Press ON/OFF button, unit starts. Previous operation status appears on display. (Not Timer setting) Power indicator on indoor unit lights up. (2) Select operation mode Press MODE button. For each press, operation mode changes as follows: AUTO COOL... - Page 10 Operation (5) Air flow direction adjustment After operation mode is selected, vertical flap will open automatically according to the mode. Referring to the Fig. COOL About 10 Up and down (Use remote controller) Press SWING button, vertical flap will move within the range shown in the Fig.
-
Page 11: Timer Operation
Operation TIMER Operation Set Clock correctly before starting Timer operation You can let unit start or stop automatically at following times: Before you wake up in the morning, or get back from outside or after you fall asleep at night. TIMER ON/OFF (1)After unit start, select your desired operation mode. - Page 12 Operation TIMER ON-OFF TIMER ON-OFF (1)After unit start, select your desired operation mode. Operation mode will be displayed on LCD. Power indicator on indoor unit lights up. (2) Press TIMER button to change TIMER mode. Every time the button is pressed, display changes as follows: TIMER ON T IMER OFF TIMER ON-OFF Select TIMER ON-OFF.
-
Page 13: Health Mode Operation
BRIEF INTRODUCTION TO HEALTH OPERATION The anion generator in the air conditioner can generate a lot of anion to effectively balance the quantity of position and anion in the air and also to kill bacteria and speed up the dust sediment in the room and finally clean the air in the room. -
Page 14: Emergency Operation
Operation Emergency operation and test operation Emergency Operation: Use this operation only when the remote controller is defective or lost. When the emergency operation switch is pressed, the " Pi "sound is heard once, which means the start of this operation. In this operation, the system automatically selects the operation modes, cooling according to the room temperature: Room... - Page 15 Operation Comfortable SLEEP Before going to bed at night, you can simply press the SLEEP button and unit will bring you a sound sleep in selected mode. In COOL mode One hour after SLEEP mode starts, temp. will become 1 C higher than temp.
-
Page 16: Maintenance
Maintenance Different models have different appearance Cleaning of unit casing Cleaning of remote controller Cleaning of air filter 1.Open inlet grille by pulling it upward. 3.Clean the filter Use a vacuum cleaner to remove dust,or wash the filter with water. After washing, dry the filter completely in the shade. - Page 17 Maintenance Better use of air conditioner Proper room temperature. Closing of doors and windows during operation Never fail to observe the followings Do not sprinkle water over the unit. Do not pull power plug. Cleaning of the air filter. Proper temperature Effective use of the timer.
-
Page 18: Troubleshooting
When the electric plug is pulled out and reinserted, the protection circuit will work for 3 minutes to protect the air conditioner. During unit operation or at stop, a swishing or gurgling noise may be heard. At first 2-3 minutes after unit start, this noise is more noticeable.
