- Page 1 Translated from French to English - www.onlinedoctranslator.com INSTRUCTIONS FOR INSTALLATION, USE & MAINTENANCE REVERSIBLE MOBILE AIR CONDITIONER Air conditioning / heating Ref. : 409612 – Type: A001-07KR2H/B1 Ref. : 409613 – Type: A001-09KR2H/B1 HOTLINE...
-
Page 3: Table Of Contents
Contents SPECIFIC WARNINGS FOR R290 GAS ................4 WARNING ! SAFETY INSTRUCTIONS................6 Special warning for use ................. 7 1. PRODUCT PRESENTATION ..................8 2. INSTALLING........................ 9 3. CONTROL PANEL AND REMOTE CONTROL - USE........11 4. -
Page 4: Specific Warnings For R290 Gas
Its effect on global warming is very low (see product sheet at the end of this manual). The device contains approximately: - 165 g for model A001-07KR2H/B1 - 200g for model A001-09KR2H/B1 Conditions of installation, use and storage: •... - Page 5 Page 5 / 24 Servicing, maintenance and repair: Please carefully read the safety instructions to be implemented in the case of maintenance and repair of the device described at the end of this manual. Authorization of stakeholders: • Anyone involved in work on or in a refrigerant circuit should hold a valid certificate issued by an industry-accredited rating authority authorizing them to handle refrigerants safely in accordance with the specifications of the refrigerant.
-
Page 6: Warning ! Safety Instructions
Page 6 / 24 WARNING ! SAFETY INSTRUCTIONS Please read this manual carefully before using the device. • This air conditioner is designed exclusively for domestic use. • It is suitable for indoor use only. • Please only use the accessories provided by the manufacturer of the air conditioner. -
Page 7: Special Warning For Use
Page 7 / 24 Special warning for use Before using the air conditioner, please follow these recommendations: Positioning and environment: • To avoid damage, place the device in an upright position for at least 24 hours before starting it for the first use. •... -
Page 8: Product Presentation
Page 8 / 24 1. PRODUCT PRESENTATION 1. Carry handle 2. Control screen + LCD display 3. Air outlet 4. Air outlet flaps 5. Casters 6. Upper filter frame 7. Exhaust connector 8. Power cord location 9. Lower filter frame 10. -
Page 9: Installing
Page 9 / 24 2. INSTALLATION WARNING : before using the mobile air conditioner, keep it upright for at least two hours. Always and imperatively move the air conditioner in a vertical position and place the air conditioner on a flat surface. Do not install the air conditioner in bathrooms and damp rooms. - Page 10 Page 10 / 24 WARNING Improper installation may affect the proper operation of the air conditioner The length of the exhaust duct is 280~1500mm, and this length is based on the specification of the air conditioner. Do not use other exhaust duct models other than the one supplied with your air conditioner, and do not add any extension exhaust ducts.
-
Page 11: Control Panel And Remote Control - Use
Page 11 / 24 3. CONTROL PANEL AND REMOTE CONTROL - USE CONTROL BY REMOTE CONTROL OR BY THE AIR CONDITIONER PANEL A) CONTROL PANEL 9 10 11 12 15 16 17 18 19 1.power button 11.High fan speed indicator 2.mode button 12.Low fan speed indicator 3.Sleep button... - Page 12 Page 12 / 24 B) REMOTE CONTROL 1. FOOD: Press key to turn on/off the air conditioner. After power on, the default is cooling mode with low fan speed. 2. FASHION: After turning on the air conditioner, press the button to select the cooling, heating, dehumidification or ventilation mode.
- Page 13 Page 13 / 24 · To push on to set the timer duration (from 1 to 24 hours). · The timer indicator lights up. The air conditioner will start after the selected number of hours. Setting the stop time: · With the air conditioner on, set the desired functions (mode/temperature/speed). Press TIMER to configure the timer off time.
-
Page 14: Drainage
Continuous drainage (recommended in dehumidification mode): In dehumidification mode, the device can recover up to: - model A001-07KR2H/B1: 17 liters of water per day - model A001-09KR2H/B1: 24 liters of water per day 1) Unscrew the plastic cap then remove the rubber stopper from the outlet of the drainage pipe. -
Page 15: Maintenance
Page 15 / 24 5. MAINTENANCE Cleaning: Before cleaning and maintenance, turn off the air conditioner and turn off the power. 1. Clean the surface Clean the surface of the air conditioner with a damp soft cloth. Do not use detergents, chemical products, such as benzene, alcohol, petrol, etc., as there is a risk of deterioration. -
Page 16: Troubleshooting
Page 16 / 24 6. TROUBLESHOOTING Do not repair or disassemble the air conditioning by yourself. A repair carried out by an unqualified person will lead to the loss of the guarantee and could cause damage to users or their property. Problems Possible causes Solution... -
Page 17: Appendices
Page 17 / 24 7. APPENDICES Fuse specification : Diameter 5×20mm Current: 3.15A Voltage: 250 Vac Block diagram for air conditioning : Regulator Condenser Evaporator Compressor DISPOSAL OF WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT FROM END USERS IN THE EUROPEAN UNION This symbol on the product or on the container indicates that this product may not be disposed of with general waste. -
Page 18: Product Information Sheet
Page 18 / 24 Product information sheet Maker :STARLIGHT – 255 Boulevard de la Madeleine – FR-06000 NICE A001-07KR2H/B1 A001-09KR2H/B1 Model : (ref. 409612) (ref. 409613) Cooling method: Energy efficiency class: Energy Efficiency Coefficient (EER): Rated cooling capacity: 2.0kW 2.6kW Hourly energy consumption: 0.8kWh/60min... -
Page 19: Safety Information For Maintenance And Repair
Page 19 / 24 SAFETY INFORMATION FOR MAINTENANCE AND REPAIR 1. Checking the working environment Before starting to work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimal. To repair the refrigeration system, the following instructions must be observed before carrying out any work on the system. - Page 20 Page 20 / 24 containing the refrigerant are installed; • ventilation machines and outlets work properly and are not obstructed; • If an indirect refrigeration circuit is used, the secondary circuit must be checked for the presence of refrigerant; • Marking on equipment continues to be visible and legible. Illegible marks and signs must be corrected;...
- Page 21 Page 21 / 24 7. Wiring Check that the wiring will not be subject to wear, corrosion, excessive pressure, vibration, sharp edges or any other adverse environmental effects. The check should also take into account the effects of aging or continual vibration from sources such as compressors or fans.
- Page 22 Page 22 / 24 11. Charging Procedures In addition to conventional charging procedures, the following requirements must be followed: • Ensure that different refrigerants are not contaminated when using charging equipment. Hoses or lines should be as short as possible to minimize the amount of refrigerant they contain.
- Page 23 Page 23 / 24 14. Recovery When removing refrigerant from a system, whether for maintenance or decommissioning, it is recommended that all refrigerants be safely removed. When transferring refrigerant into cylinders, be sure to use only appropriate refrigerant recovery cylinders. Make sure the correct number of cylinders to hold the total system charge are available.
