5.1 Analog

Pin Function
1 +3V3
2 A0
3 A1
4 A2
5 A3
6 A4
7 A5
8 A6
9 A7
10 +5V
11 Reset
12 GND
12 VIN

5.2 Digital

Pin Function
1 D1/TX1
2 D0/RX0
3 D2
4 D3
5 D4
6 D5
7 D6
8 D7
9 D8
10 D9
11 D10
12 D11
13 D12
14 D13
15 Reset
16 GND
9 / 13
Type Description
Power 5V USB Power
Analog Analog input 0 /GPIO
Analog Analog input 1 /GPIO
Analog Analog input 2 /GPIO
Analog Analog input 3 /GPIO
Analog Analog input 4 /GPIO
Analog Analog input 5 /GPIO
Analog Analog input 6 /GPIO
Analog Analog input 7 /GPIO
Power +5V Power Rail
Reset Reset
Power Ground
Power Voltage Input
Type Description
Digital Digital Input 1 /GPIO
Digital Digital Input 0 /GPIO
Digital Digital Input 2 /GPIO
Digital Digital Input 3 /GPIO
Digital Digital Input 4 /GPIO
Digital Digital Input 5 /GPIO
Digital Digital Input 6 /GPIO
Digital Digital Input 7 /GPIO
Digital Digital Input 8 /GPIO
Digital Digital Input 9 /GPIO
Digital Digital Input 10 /GPIO
Digital Digital Input 11 /GPIO
Digital Digital Input 12 /GPIO
Digital Digital Input 13 /GPIO
Reset Reset
Power Ground
