Johnson Controls PENN ACT2 Technical Bulletin

Johnson Controls PENN ACT2 Technical Bulletin

Hide thumbs Also See for PENN ACT2:
Table of Contents

Advertisement

Quick Links

Download this manual
Setting Up External Communications
Setting Up External Communications ................................................3
Introduction......................................................................................................... 3
Key Concepts...................................................................................................... 4
Installation Options..........................................................................................................4
Alarm Dial-Out Options....................................................................................................4
Introduction......................................................................................................... 5
Key Concepts...................................................................................................... 6
Definitions .......................................................................................................................6
ACT2 Controller Requirements........................................................................................6
Computer Requirements .................................................................................................6
Hardware Requirements..................................................................................................7
Procedure Overview........................................................................................... 8
Detailed Procedures........................................................................................... 9
Performing a Typical Installation without a ProLink Converter .........................................9
Performing an Alternate Installation with a ProLink Converter .......................................10
Introduction....................................................................................................... 15
Key Concepts.................................................................................................... 16
Definitions .....................................................................................................................16
ACT2 Controller Requirements......................................................................................16
Computer Requirements ...............................................................................................16
Hardware Requirements................................................................................................16
© 1999 Johnson Controls, Inc.
Code No. LIT-804250
Refrigeration Systems Technical Manual
T
B
ECHNICAL
ULLETIN
Communications Section
Issue Date
www.johnsoncontrols.com
804
0699

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PENN ACT2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Johnson Controls PENN ACT2

Summary of Contents for Johnson Controls PENN ACT2

  • Page 1: Table Of Contents

    Performing an Alternate Installation with a ProLink Converter ........10 Connecting Multiple ACT2 Controllers Directly to a Computer ..15 Introduction....................... 15 Key Concepts....................16 Definitions ........................16 ACT2 Controller Requirements..................16 Computer Requirements ....................16 Hardware Requirements....................16 © 1999 Johnson Controls, Inc. Code No. LIT-804250 www.johnsoncontrols.com...
  • Page 2 Communications Procedure Overview..................17 Detailed Procedures..................18 Connecting a Computer to Multiple ACT2 Controllers............18 Connecting to Single or Multiple ACT2 Controllers via Modem ..23 Introduction....................... 23 Key Concepts....................24 Definitions ........................24 ACT2 Controller Requirements..................24 Computer Requirements ....................24 Hardware Requirements....................24 Procedure Overview..................25 Detailed Procedures..................

  • Page 3: Setting Up External Communications

    Setting Up External Communications Setting Up External Communications Introduction This document covers the hardware needed to set up the remote configuration, monitoring, and alarm dial out capabilities of the ACT2 controller. For remote configuration and monitoring of the ACT2 controller installation, as well as for computer monitoring of alarms, additional Maestro software setup may be needed.

  • Page 4: Key Concepts

    Communications Key Concepts Installation Options ACT2 controllers can be set up and the installation can be remotely monitored by setting up communication between the controller and a computer running Maestro software. ACT2 controller communication can be configured several ways: • A single ACT2 controller can communicate directly with a computer (Version 2.01 and later).

  • Page 5: Connecting A Single Act2 Controller Directly To A Computer

    Setting Up External Communications Connecting a Single ACT2 Controller Directly to a Computer Introduction Connecting an ACT2 controller to a computer that has the Maestro software installed allows remote programming and monitoring of an ACT2 controller installation. A computer can be directly connected to a single ACT2 controller in two ways: •...

  • Page 6: Key Concepts

    ProLink RS-232 to RS-485 Converter: The ProLink converter is available through Johnson Controls/Encore. It converts the ACT2 controller communication signal into a signal that the computer can interpret. ACT2 controllers older than Version 2.01 must use this converter.

  • Page 7: Hardware Requirements

    Setting Up External Communications Hardware Requirements For direct connection between a PC and a single ACT2 controller (without a ProLink converter), the following hardware is needed: • Cable: Depending on the type of serial port on the computer, female 9-pin to female 9-pin null modem cable, or female 25-pin to female 9-pin null modem cable For direct connection with a ProLink converter between your PC and a single ACT2 controller, the following hardware is needed:...

  • Page 8: Procedure Overview

    Communications Procedure Overview Table 1: Connecting a Single ACT2 Controller to a Computer To Do This Follow These Steps: Directly Connect a Computer Turn off the computer. to an ACT2 Controller Depending on the computer’s serial port, do one of the following: Plug the female 9-pin connector into the serial communication port on the computer.

  • Page 9: Detailed Procedures

    Setting Up External Communications Detailed Procedures Performing a Typical Installation without a ProLink Converter Serial Null Modem Cable 9-Pin Female Connector Power Alarm 9-Pin or 25-Pin Female Connector Figure 1: Direct Connection Between the ACT2 Controller and a Computer 1. Turn off the computer. 2.

  • Page 10: Performing An Alternate Installation With A Prolink Converter

    Communications Performing an Alternate Installation with a ProLink Converter Straight Through Cable 25-Pin (not Null Modem Cable) Male Connector 9-Pin or 25-Pin P r o L i n k Female Power Alarm Connector ProLink Converter 22 AWG Shielded Twisted Pair Cable (Belden 9451 or equivalent) Figure 2: Alternate Method for Direct Connection Between the ACT2 Controller and a Computer...
  • Page 11 Setting Up External Communications 3. Plug the 25-pin male connector into the ProLink converter port. (See Figure 3 below.) 9-pin or 25-pin Female 25-pin Male P r o L i n k Straight Through Cable Plug together. Figure 3: Connecting the Straight Through Cable 4.
  • Page 12 Communications 7. Connect the communications wire to the ProLink converter (black wire to the “-” terminal and white wire to the “+” terminal). IMPORTANT: Polarity must be maintained between the ProLink converter and ACT2 controllers. Reversing polarity may result in damaged or incorrect communication. P r o L i n k - Black Wire + White Wire...
  • Page 13 Setting Up External Communications ACT2 Circuit Board USE COPPER CONDUCTORS ONLY TB16 TB15 Communications shield drain wire should be grounded to Earth Ground only at one end of the cable. The - Black Wire other end should be left unterminated. + White Wire TB14 RS-485...
  • Page 14 Communications...

  • Page 15: Connecting Multiple Act2 Controllers Directly To A Computer

    Setting Up External Communications Connecting Multiple ACT2 Controllers Directly to a Computer Introduction Connecting a network of ACT2 controllers to a computer with the Maestro software installed allows remote programming and viewing of that network. This section covers the steps needed to directly connect a computer to a network of ACT2 controllers.

  • Page 16: Key Concepts

    ProLink RS-232 to RS-485 Converter: The ProLink converter is available through Johnson Controls/Encore. It converts the ACT2 controller communication signal into a signal that the computer can interpret. The ProLink converter is packaged complete with power supply and a 9-pin to 25-pin cable.

  • Page 17: Procedure Overview

    Setting Up External Communications Procedure Overview Table 2: Connecting Multiple ACT2 Controllers to a Computer To Do This Follow These Steps: Connect a Computer to Turn off the computer and disconnect Multiple ACT2 Controllers power from the ACT2 controllers. Depending on the computer’s serial port, do one of the following: Plug the female 9-pin connector into the serial communication port on the...

  • Page 18: Detailed Procedures

    Communications Detailed Procedures Connecting a Computer to Multiple ACT2 Controllers 9-Pin or 25-Pin 25-Pin Female Male Connector Connector ProLink Converter ProLink Power Alarm Power Alarm Straight Through Cable 22 AWG Shielded (not Null Modem Cable) Next Twisted Pair Cable ACT2 (Belden 9451 or equivalent) Controller Figure 8: Direct Connection Between Multiple ACT2 Controllers...
  • Page 19 Setting Up External Communications 9-pin or 25-pin Female 25-pin Male P r o L i n k Straight Through Cable Plug together. Figure 9: Connecting the Cable 4. Unscrew the four screws on the cover of the ProLink converter. 5. Set jumpers J3 and J4 to the DTE position, as illustrated on the inside cover of the ProLink converter.
  • Page 20 Communications 7. Connect the communications wire to the ProLink converter (black wire to the “-” terminal and white wire to the “+” terminal). IMPORTANT: Polarity must be maintained between the ProLink converter and ACT2 controllers. Reversing polarity may result in damaged or incorrect communication. P r o L i n k - Black Wire + White Wire...
  • Page 21 Setting Up External Communications 9. Connect the RS-485 wire to the Remote Communication Terminals inside of the ACT2 controller; black wire to the “-” terminal and white wire to the “+” terminal. ACT2 Circuit Board USE COPPER CONDUCTORS ONLY TB16 TB15 Communications shield drain wire should be grounded to Earth Ground...
  • Page 22 Communications 11. Plug in the power for the ProLink converter. P r o L i n k 120 VAC Outlet ProLink Power Cord Figure 13: ProLink Converter Power Connection 12. Turn the computer back on and restore power to the ACT2 controller.

  • Page 23: Connecting To Single Or Multiple Act2 Controllers Via Modem

    Setting Up External Communications Connecting to Single or Multiple ACT2 Controllers via Modem Introduction This section describes the connections needed to remotely communicate with a single or multiple ACT2 controllers via modem.

  • Page 24: Key Concepts

    ProLink RS-232 to RS-485 Converter: The ProLink converter is available through Johnson Controls/Encore. It converts the ACT2 controller communication signal into a signal that the modem can relay. The ProLink converter is packaged complete with power supply and a 9-pin to 25-pin cable.

  • Page 25: Procedure Overview

    Setting Up External Communications Procedure Overview Table 3: Connecting to ACT2 Controllers via Modem To Do This Follow These Steps: Connect a Computer and 1. Turn off the computer and disconnect Single or Multiple ACT2 power from the ACT2 controllers. Controllers via Modem Note: The modem attached to the ACT2 controller network must be set at factory...

  • Page 26: Detailed Procedures

    Communications Detailed Procedures Connecting a Computer and Single or Multiple ACT2 Controllers via Modem Modem Power Alarm Power Alarm Modem ProLink Converter ProLink To Next ACT2 Controller in Network 22 AWG Shielded Twisted Pair Cable (Belden 9451 or equivalent) Figure 14: Modem Connection Between a Computer and Single or Multiple ACT2 Controllers 1.
  • Page 27 Setting Up External Communications 2. Using the female 25-pin to male 25-pin straight through cable, plug the female 25-pin connector into the male 25-pin port on the modem. This connector type depends on the modem used. 25-pin Male P r o L i n k Straight Through Cable Plug Plug...
  • Page 28 Communications 7. Connect the 22 AWG shielded twisted pair cable to the T1 terminal on the ProLink converter; black wire to the “-” terminal, and white wire to the “+” terminal. IMPORTANT: Polarity must be maintained between the ProLink converter and ACT2 controllers. Reversing polarity may result in damaged or incorrect communication.
  • Page 29 Setting Up External Communications 9. Make connections to the ACT2 controller remote communication terminals as shown below; black wire to “-” terminal, white wire to “+” terminal. ACT2 Circuit Board USE COPP ER CONDUCTO RS O NLY TB16 TB15 Communications shield drain wire should be grounded to Earth Ground only at one end of the cable.

  • Page 30: Resetting A Modem To Factory Defaults

    Communications 12. Connect the power cord to the ProLink converter and plug it into a 120 VAC outlet. Modem This connector is dependent on the modem type. 25-pin Male P r o L i n k 120 VAC Straight Through Cable - Black Wire + White Wire 22 AWG Shielded...

  • Page 31: Alarm Dial-Out Options

    Setting Up External Communications Alarm Dial-Out Options Introduction This section covers hardware setup for dialing out alarms to: • printer • answering service • audible alarm or strobe light • pager To set up hardware for dial-out to the Maestro software, follow the steps in the section titled Connecting to Single or Multiple ACT2 Controllers via Modem.

  • Page 32: Key Concepts

    ProLink RS-232 to RS-485 Converter: The ProLink converter is available through Johnson Controls/Encore. It converts the ACT2 controller communication signal into a signal that the printer or modem can interpret. ACT2 controllers older than version 2.01 must use this converter.

  • Page 33: Act2 Controller Requirements

    Setting Up External Communications ACT2 Controller Requirements The ACT2 controller must be set up for “modem” connection and a unique communication ID must be assigned to each controller before communication will be successful. See the Programming ACT2 System Parameters Technical Bulletin for information on how to set these parameters.

  • Page 34: Procedure Overview

    Communications Procedure Overview Table 4: Alarm Dial-Out Options To Do This Follow These Steps: Connect a Remote Printer to Disconnect power from the ACT2 Single or Multiple ACT2 controllers. Controllers for Alarm Dial-Out Note: The modem attached to the ACT2 controller network must be set at factory defaults.
  • Page 35 Setting Up External Communications To Do This (Cont.) Follow These Steps: Connect an Audible or Visible Wire the alarm relay on the ACT2 controller Alarm to an ACT2 Controller board to the alarm device. See the Wiring the ACT2-CS Controller and Add-On Input and Output Boards Technical Bulletin for more information on wiring alarms.

  • Page 36: Detailed Procedures

    Communications Detailed Procedures Connecting a Remote Printer to Single or Multiple ACT2 Controllers for Alarm Dial-Out 1. Disconnect power from the ACT2 controllers. Note: The modem attached to the ACT2 controller network must be set at factory defaults. To reset a previously used modem, see the section titled Resetting a Modem to Factory Defaults.
  • Page 37 Setting Up External Communications 7. Connect the 22 AWG shielded twisted pair cable to the T1 terminal on the ProLink converter; black wire to the “-” terminal, and white wire to the “+” terminal. IMPORTANT: Polarity must be maintained between the ProLink converter and ACT2 controllers.
  • Page 38 Communications ACT2 Circuit Board USE CO PPER CO NDUCTORS ONLY TB16 TB15 Communications shield drain wire should be grounded to Earth Ground only at one end of the cable. The other end should be left unterminated. - Black Wire ProLink + White Wire TB14 RS-485...
  • Page 39 Setting Up External Communications Modem This connector is dependent on the modem type. 25-pin Male P r o L i n k 120 VAC Straight Through Cable - Black Wire + White Wire 22 AWG Shielded Twisted Pair Cable (Belden 9451 or equivalent) To Act2 Controller Figure 24: ProLink Converter Power Connection...

  • Page 40: Connecting An Audible Or Visible Alarm To An Act2 Controller

    Communications Connecting an Audible or Visible Alarm to an ACT2 Controller The last output terminal on the ACT2 controller internal circuit board is a dedicated alarm relay. Wire the alarm relay on the ACT2 controller board to the alarm device. See the Wiring the ACT2-CS Controller and Add-On Input and Output Boards Technical Bulletin for more information on wiring alarms.

  • Page 41: Troubleshooting

    Setting Up External Communications Troubleshooting Problem Cannot establish communication between ACT2 controller and Maestro software. Possible Causes and Solutions • Observe the TX and RX LEDs on each ACT2 controller board (see Figure 26). If no flickering is seen, the modem is not communicating with the ACT2 controller.
  • Page 42 Communications • If flickering of the TX and RX LEDs on the ACT2 controller are observed, check the modem for similar flickering TX and RX LEDs. If the modem LEDs are not flickering, check the modem for proper connections. • Ensure that all ACT2 controllers have been assigned a unique communication ID (see the Programming ACT2 System Parameters Technical Bulletin for more information).
  • Page 43 Setting Up External Communications Notes...
