Coopers Wheelbarrow Planter 11022 Instructions For Use

Table of Contents

Download this manual

Wheelbarrow Planter

Please read and retain these instructions for future reference

Parts

Part no. 2 the parts are NOT identical. The part with

pre-drilled holes underneath is the front piece which

attaches to part no. 3.

Using bolts part B x4 on each side where shown,

connect parts 2 and 3.

Rear

11022

Front

Turn upside down

and connect part 1

to the assembly

using 2x screws A.

Instructions for Use

v001: 13/11/17

Table of Contents

Do you have a question about the Wheelbarrow Planter 11022 and is the answer not in the manual?

Page 1 Wheelbarrow Planter Instructions for Use 11022 Please read and retain these instructions for future reference v001: 13/11/17 Parts IMPORTANT Part no. 2 the parts are NOT identical. The part with pre-drilled holes underneath is the front piece which attaches to part no. 3. ASSEMBLY INSTRUCTIONS Step 1 Using bolts part B x4 on each side where shown,...
Page 2 Wheelbarrow Planter Instructions for Use 11022 Please read and retain these instructions for future reference v001: 13/11/17 Step 3 Assemble wheel Fit parts 5 using 2x bolts C. Attach 2x parts 6 to the wheel (part 4) using 2x pins D . Step 4 Step 5 Slot in assembled wheel as shown.
