160L Wheeled Collection Bag with Rake
Please read and retain these instructions for future reference
PARTS
Max. weight: 15kg
ASSEMBLY:
1. Attach part b (the top handle) to part c (the lower poles) using the screws and
nuts, parts u and v.
2. Slide part e (the handle clip) down over the screws that have just been
inserted.
Instructions for Use
10546
v002:05/12/16/2016
Advertisement
Related Manuals for Coopers 10546
Summary of Contents for Coopers 10546
- Page 1 Instructions for Use 160L Wheeled Collection Bag with Rake 10546 Please read and retain these instructions for future reference v002:05/12/16/2016 PARTS Max. weight: 15kg ASSEMBLY: 1. Attach part b (the top handle) to part c (the lower poles) using the screws and nuts, parts u and v.
- Page 2 Instructions for Use 160L Wheeled Collection Bag with Rake 10546 Please read and retain these instructions for future reference v002:05/12/16/2016 3. Insert the handle poles into the frame 4. Place the wheel part f onto the axle on base attached to part h and secure using the part h.
- Page 3 Instructions for Use 160L Wheeled Collection Bag with Rake 10546 Please read and retain these instructions for future reference v002:05/12/16/2016 7. Expand the collection bag by unclipping the toggle on each side of the bag; be careful as this can expand quickly.
- Page 4 Instructions for Use 160L Wheeled Collection Bag with Rake 10546 Please read and retain these instructions for future reference v002:05/12/16/2016 HOW TO USE HOW TO STORE 1. To collapse the collection bag, undo the hook and loop and the push down on the bag and secure back into place by using the toggles on each side.
