ENGINE SPEED IN RPM
OUTPUT IN HORSEPOWER
ENGINE INLET WATER TEMP.
THERMOSTAT RATING
THERMOSTAT FULL OPEN
ENGINE OUTLET WATER TEMP.MAX.
HIGH TEMP. SHUTDOWN SWITCH
HEAT REJECTION – BTU / MIN.
HEAT REJECTION – BTU / HR.
AIR FLOW – CU. FT. / MIN.
ENGINE OIL TEMP. MAX.
COMBUSTION AIR TEMP. *
* Combustion Air Temperature: The output of the engine will decrease about 1% for
every 10°F of air temperature above 77°F or 25°C.
IMPORTANT: Insulation and Sound Absorbing Material used inside of the generator compartment
Must Not reduce the specified airspace clearances or restrict the airflow around the generator. Such
reduction in airspace may lead to an overheating situation and reduced generator performance. Also be
sure the air inlet and outlet openings meet the specified requirements. Allow clearance inside the
generator compartment for easy access when routine maintenance is required.
WARNING: The generator compartment Must Be sealed to prevent hazardous fumes and vapors from
entering the vehicles other compartments and interior spaces. Plugging holes and sealing all seams will
greatly reduce this hazard.
WARNING: Drip Proofing! When installing a generator, the area directly beneath the generator end of
the unit must incorporate a non-flammable barrier. This barrier needs to be made of sufficient material
able to withstand and prevent molten metal, burning insulation, flaming or sparking particles from
contacting any flammable materials at the bottom of the compartment.
AIR REQUIREMENTS CONT'D
8KW
1800
13.6
N/A
160°F
185°F
230°F
230°F
702
42120
1700
268°F
N/A
6
10KW
12KW
1800
1800
17.9
17.9
N/A
N/A
160°F
160°F
185°F
185°F
230°F
230°F
230°F
230°F
979
1053
58770
60812
1700
1700
268°F
268°F
N/A
N/A
