Steering
1
10/07/2016
1. Sector Shaft Grease Fitting
Fig. 2, Steering Gear Lubrication
chassis grease, apply clean grease at the grease
fittings until old grease is forced out of the
socket.
1
10/07/2016
1. Grease Fitting at Pitman Arm
2. Grease Fitting at Axle Steering Arm
Fig. 3, Drag Link
46–06 Power Steering Filter
Changing
1. Apply the parking brakes and chock the rear
tires.
2. Raise the front of the vehicle and support it with
jack stands.
3. Remove the retaining ring from the reservoir.
See Fig. 1.
Business Class M2 Maintenance Manual, August 2015
4. Remove the filter, filter cover, and gasket from
the reservoir.
5. Disconnect the filter from the filter cover, and dis-
card the filter.
6. Apply a thin film of power steering fluid on the
gasket of the new filter. Then attach the filter to
the filter cover.
7. Check for damage to the gasket that was re-
moved from the reservoir. If the gasket is dam-
aged, replace it. Install the gasket on the reser-
voir.
8. Install the filter and filter cover in the reservoir.
Attach the retaining ring to the reservoir to se-
cure the filter and filter cover.
9. Check the fluid level in the reservoir. If neces-
sary, add fluid to the reservoir to maintain the
fluid level between the MIN COLD and MAX
f461071
HOT lines. See
steering fluids.
10. Raise the vehicle and remove the jack stands,
then lower the vehicle.
11. Remove the chocks from the tires.
2
f461072
Table 1 for approved power
