Page 1: Operation Manual
CASSETTE TYPE AIR CONDITIONER OPERATION MANUAL AB182ACBHA AU182AFBIA (HBU-18HA03/R1(B)) No.0010571312... -
Page 2: Table Of Contents
CONTENTS CAUTIONS THE NAME OF EACH PART AND ITS FUNCTION INTRODUCTION TO SPARE PARTS REMOTE CONTROLLER OPERATION GUIDE TO OPERATION AIR FLOW DIRECTION ADJUSTMENT PROCEDURE FOR COMFORTABLE USE CARE AND MAINTENANCE WARNING OPERATION 8-12 13-15 17-19 20-24... -
Page 3: Cautions
Before disposing an old air conditioner that goes out of use, please make sure it's inoperative and safe. Unplug the air conditioner in order to avoid the risk of child entrapment. It must be noticed that air conditioner system contains refrigerants, which require specialized waste disposal. - Page 4 CAUTIONS Use of the air conditioner is to be carried out in strict compliance with the relative instructions set forth in the User's Guide. Installation shall be done by professional people, don't install unit by yourself. For the purpose of safety, the air conditioner must be properly grounded in accordance with specifications.
-
Page 5: The Name Of Each Part And Its Function
THE NAME OF EACH PART AND ITS FUNCTION Indoor unit Operating Control Panel Outdoor unit Air inlet Air outlet Swing louver (Air flow direction can be adjusted by using the SWING button on the remote controller) Operating Control Panel Air Inlet Grille Air Filter (Inside of the Inlet Grille) COMP TIMER OPER POWER... -
Page 6: Air Flow Direction Adjustment Procedure
AIR FLOW DIRECTION ADJUSTMENT PROCEDURE Up/down direction can be adjusted by using the SWING button on the remote controller. Each time pressing this button, the mode changes in the following sequence. Change to the AIRFLOW mode. SWING Louver moves in upward and downward directions continuously. - Page 7 Press SLEEP button once to make the air conditioner have the previous-set sleep time (first power-on is "1h"), the sleep symbol will appear.
- Page 8 Notes: When a power failure suddenly occurs during the air conditioner is working after the power after the power failure compensation is set, if the air conditioner will not be used for a long time, please cut off the power supply to prevent its operation from being resumed after the power is supplied again, or press the "Switch On/Off"...
-
Page 9: For Comfortable Use
FOR COMFORTABLE USE Clean the air filter periodically. When cooling season is over,clean the air filter. If air filter is colgged: Efficiency of air-conditioning is reduced, and it will result in excessive consumption of elec- tric power. It will result in malfunction. Water drop will drip in cooling mode Operation. -
Page 10: Care And Maintenance
2. After drying the air filter, set it up on the air conditioner. Filter Do not dry the air filter with fire. Do not run the air conditioner without the air filter. Do not use hot water or volatileliquid. Do not... - Page 11 Operate the unit with FAN mode on a fair day for about half a day to dry the inside of the unit well. Stop operation and turn off the power supply switch. Electric power is consumed even the air conditioner is in stop.
- Page 12 The smell results from residents of tobacco smoke or cosmetics stuck inside of unit. When the air conditioner is used at restaurant etc. where dense edible oil fume is always exists, white fog sometimes blows out of air outlet during operation.
-
Page 13: Warning Operation
Defrosting operation when a room is warmed with a heat pump type air conditioner, frost accumulates on the heat exchanger of outdoor unit along with the drop of indoor temperature. Since the accu- mulated frost reduces the effect of warming, it is necessary to automatically switch the op- eration to the defrosting mode. -
Page 14: Safety Precautions
The electric work must be burden on the authorized engineer with qualification for electric work and grounding work, and the work must be conducted in accordance with electric equip- ment technical standard. The power source for the unit is to be of exclusive use. An earth leakage breaker should be installed. -
Page 15: Cautions For Operation
Do not install nearby the place where may have leakage of flammable gas. If the gas leakes and gathers around, it may cause the fire. Where strong winds may pre- vail, the system should be fixed securely to prevent a collapse. Bodily injury could result by a col- lapse. - Page 16 It could cause deterioration of foods or other problems. SAFETY PRECAUTIONS Do not wash the air conditioner with water. It could cause electric shocks. Neither stand on the air condi- tioner nor place something on it.
- Page 17 If the structure is not repaired imm- ediately, the unit could topple down to cause a personal injury. WARNING When the air conditioner is relocated, contact you dealer or a professional installer. Improper practice of installation could cause water leakage, electric shock or fire.
