Summary of Contents for PCB Piezotronics IMI SENSORS 691C42T
Page 1
Model 691C42T Vibration Switch Box Installation and Operating Manual For assistance with the operation of this product, contact the PCB Piezotronics, Inc. Toll-free: 800-959-4464 24-hour SensorLine: 716-684-0001 Fax: 716-684-3823 E-mail: imi@pcb.com Web: www.imi-sensors.com...
Page 2
Assistance is needed to safely operate equipment PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
Page 3
CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
INDUSTRIAL MONITORING INSTRUMENTATION DIVISION Introduction Models 691C41 and 691C42 are rotary switch boxes that provide terminal strip inputs for sensor cable termination with the convenience of BNC & military connectors for switched outputs and terminal strips for continuous outputs. They are typically used in conjunction with third-party data collectors and analyzers. The boxes provide simultaneous vibration and temperature inputs on every channel so that they can be used in conjunction to temperature output (TO) sensors (accelerometers with a built-in temperature sensor that provide simultaneous vibration and temperature signals).
INDUSTRIAL MONITORING INSTRUMENTATION DIVISION Installation Establish an easily accessible location for installation. Fiberglass rotary switch boxes include four polyester mounting brackets and four stainless steel attachment screws that are shipped loose to facilitate enclosure mounting. There are positioning indents on the back of the box in each corner.
INDUSTRIAL MONITORING INSTRUMENTATION DIVISION If the box did not ship from factory with factory-installed connections ports, drill/punch the necessary holes in the bottom of box for the input and output cabling. Be very careful when drilling/punching holes in the box as to not damage the internal metal, terminal strips and printed circuit boards.
INDUSTRIAL MONITORING INSTRUMENTATION DIVISION Output Wiring Using the Enclosure When collecting data from the enclosure using the BNC and/or MIL connectors and a data collector, connect the data’s collector connector to its appropriate connector mate in the box and modulate the switch to the appropriate channel.
Warning 2 – ESD Sensitivity This equipment is designed with user safety in mind; however, the protection provided by the equipment may be impaired if the equipment is used in a manner not specified by PCB Piezotronics, Inc. Caution 1 – ESD Sensitivity Cables can kill your equipment.
INDUSTRIAL MONITORING INSTRUMENTATION DIVISION Warranty IMI instrumentation is warranted against defective material and workmanship for 1 year unless otherwise expressly specified. Damage to instruments caused by incorrect power or misapplication, is not covered by warranty. If there are any questions regarding power, intended application, or general usage, please consult with your local sales contact or distributor.
Customer Service IMI, a division of PCB Piezotronics, guarantees Total Customer Satisfaction. If, at any time, for any reason, you are not completely satisfied with any IMI product, IMI will repair, replace, or exchange it at no charge. You may also choose, within the warranty period, to have your purchase price refunded.
Page 15
Model Number Revision: A VIBRATION SWITCH BOX 691C42T ECN #: 48403 Performance ENGLISH OPTIONAL VERSIONS Channels Optional versions have identical specifications and accessories as listed for the standard model Environmental except where noted below. More than one option may be used. Enclosure Rating Nema 4X IP66...
Page 16
PCB Piezotronics Inc. claims proprietary rights in REVISIONS the information disclosed hereon. Neither it nor any reproduction thereof will be disclosed to others DESCRIPTION 8.50 [215.9] without the written consent of PCB Piezotronics Inc. UPDATE SCREEN PRINT 47778 12 CHANNEL SWITCH 3 PIN MIL BNC JACKS 10.50 [266.7]...
