8. ORDERING

Table 1 below shows the codes to be used for product ordering. Only the first three code groups
need to be specified for the standard versions of the product. The standard versions ships without
the items from groups 4, 5 and 6, and with a standard size current transformer (CT100 with 3m
lead).
Please review the examples shown overleaf.
TABLE 1: ORDERING CODES
Group 1 Product Range
Group 2 Symbol 1: Power source
Symbol 2: Indicator type
Symbol 3: Glands
Group 3 Nominal trip current in amps
Group 4 Symbol 1: Mains cable fitted
Symbol 2: Mains cable length in meters
Group 5 Symbol 1: Remote indicator fitted
Symbol 2: Remote cable length in meters
Group 6 Symbol 1: Auxiliary relay fitted
Symbol 2: Auxiliary cable length in meters
Group 7 Symbol 1-5: Current transformer diameter
Group 8 Symbol 1: CT fitted
Symbol 2: CT cable length in meters
EFI
M
B
C
L
F
Z
50
M
3
R
3
A
2
CT100
CT150
CT300
C
3
Version 4.1
User's Manual
Earth Fault Indicator
Mains powered
Battery powered
CT powered
LED
Flag
Cable glands fitted
50 amps trip level
Mains cable
3 meters
Remote indicator
3 meters
Auxiliary relay
2 meters
100mm diameter
150mm diameter
300mm by 100mm
Current Sensor
3 meters
