Sentinel™ EFI-MLZ

7. SPECIFICATIONS

Network voltage range:
Rated mains voltage:
Frequency:
Overvoltage withstand:
Impulse voltage withstand:
Trip current:
Minimum fault duration:
Fault current withstand:
Primary indication:
Flashing duration:
Voltage reset:
Manual test:
Supply charging time:
Operating temperature:
Enclosure
-dimensions
-material
-mounting
-degree of protection
-cable gland size:
-mass:
Current sensor
-CT100 (standard size):
-CT150 (optional):
-CT300 (optional):
-material:
-mounting:
-lead length:
-lead type:
-mass:
Auxiliary relay
-type:
-rating:
Remote indicator
-dimensions:
-material:
1-36kV
110V-230V ±20%
50Hz / 60Hz ±20%
600V for 48 hours
10kV, 1.2/50us waveform
50A ±10A (factory programmable)
2.5 cycles (50ms @ 50Hz / 40ms @ 60Hz)
25kA for 1s
LED, flash rate 1Hz nominal
12 hours nominal (6 hours with remote indicator)
Healthy mains for 10s
Pushbutton alternately initiates trip and reset
5 minutes nominal
-20ºC to 70ºC
115mm × 65mm × 40m
ABS, grey
Flush-mounting, two M4 holes
IP65
PG7; cable diameter range 3-6.5mm
250g
100mm diameter
150mm diameter
300mm × 100mm rectangular oval
Insulated silicon steel
releasable cable-ties
3m
2-core, 0.5mm 2 , doubly insulated
250g
Latching, N/O on reset
220Vdc, 250Vac, 2A
M10 Hex Bolt 20mm long (100g)
Stainless steel
Version 4.1
User's Manual
Page 11 of 15
