- Page 1 VERSION:D 20200514 TBB2 User Manual...
-
Page 2: Table Of Contents
7. Packages, Transportations, and Storage ......................8 8. Manufacture information ............................9 9. Performance Data ..............................9 Charging and discharging characteristics .......................... 9 Constant life tests of charging/discharging on the 12V lead-acid battery in TBB2 ..........10 9.2.1 Testing temperature ............................... 10 9.2.2 Testing sample ................................ -
Page 3: Safety Instructions
TBB2 must be used with rated input voltage only. Don’t discard TBB2 randomly or expose them to heat sources, such as radiators or space heaters to avoid any fire or explosions. To reduce environmental impacts, please bring your battery to a certified recycling depot at the end of its life. -
Page 4: Capacity Status And Led Indications
Note 2: When TBB2 is under protection mode (refer to section D): The LED indication is continuously off. Note 3: If the orange light shines continually, it means disconnection of TBB2 or electrical circuit failure. If any related condition occurs, please contact our authorized sales agent or TiMOTION. -
Page 5: Operation
3. Operation The operation of TBB2 with ON/OFF switches: Switch ON: Please connect TBB2 to the control box, and then press the switch constantly for 1~2 seconds until the indication light is on. (As the below picture) Switch OFF: Please press the switch constantly for 3 seconds until indication light is off. -
Page 6: Maintenance
TBB2 User Manual 4. Maintenance It is highly recommended that TBB2 should be charged continuously at least 24hrs+ in the following situations:: First operation Before long time storage (long period of time when disconnected to AC power) ... -
Page 7: Appearance And Wiring Definitions
TBB2 User Manual 6. Appearance and Wiring Definitions TBB2 Version D．May 2020... -
Page 8: Packages, Transportations, And Storage
TBB2 User Manual 7. Packages, Transportations, and Storage Standard package as picture below: TBB2 is packed into small box and 4*2 layers small boxes for an outer carton. Transportations: By sea or land only. Storage conditions: Temperature: 5~45°C ... -
Page 9: Manufacture Information
The following chart shows the correspondence between the controlled constant current and the charging period through discharging continuously from the Full Capacity State (100% electricity capacity) to the Low Capacity State (<20% electricity capacity). Figure D: TBB2 (1.2AH) battery discharging test Version D．May 2020... -
Page 10: Constant Life Tests Of Charging/Discharging On The 12V Lead-Acid Battery In Tbb2
Constant life tests of charging/discharging on the 12V lead-acid battery in TBB2 300 times test cycles on charging/discharging of the 12V lead-acid batteries in TBB2. Its aim is to check the maximum electricity capacity of the battery, observing how it may decay as we increase the charging/discharging cycles.
