Allied MDPED Assembly Instructions

Mobile admin/teacher desk
Hide thumbs
1
2
3
4

Advertisement

Table of Contents

Tools Required for Assembly:
• Cordless Screwdriver with #2 Phillips bit
MDPED
DESK FRONT
- OR -
DRAWERS
ON RIGHT
Step 2.
Unpack the MDPED drawer unit and remove
the top two drawers. Pull the drawer out, lift the
release latches and pull the drawer free. Set the
drawers aside.
For Customer Service Call 1-800-999-0386
®
MD-LEG
M-PANEL
DRAWERS
ON LEFT
DESK FRONT
Mobile Admin/Teacher Desk

Assembly Instructions - Single Pedestal

Included Hardware:
10 x 10/32
4 x
M6 Truss-head screws
Your desk base arrives in multiple cartons,
labeled as:
MDPED - One fully assembled drawer pedestal
MD-LEG - One leg assembly
M-PANEL - One modesty panel
The Desk Top will be its own carton. Please
flatten and retain this carton for assembly.
Step 1.
Carefully lay the desk top face-down on the
carton.
Determine if you want the drawers on the left
or right-hand side, using the pattern of thread-
ed inserts in the underside of the desktop as a
guide.
Rotate the top accordingly.
1/2" Pan-head screws
RELEASE
LATCH
alliedusa.com
R041922

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MDPED and is the answer not in the manual?

Questions and answers

Related Manuals for Allied MDPED

Summary of Contents for Allied MDPED

  • Page 1 M6 Truss-head screws MDPED MD-LEG Your desk base arrives in multiple cartons, labeled as: MDPED - One fully assembled drawer pedestal MD-LEG - One leg assembly M-PANEL - One modesty panel M-PANEL The Desk Top will be its own carton. Please flatten and retain this carton for assembly.
  • Page 2 Mobile Admin/Teacher Desk Single Pedestal - Continued ® Step 3. Position the MDPED unit on the desk top, top-side down, with the front facing toward the front of the desk. DESK TOP Attach the M-Panel to the drawer unit using two (2) M6 truss head screws.
  • Page 3 MDPED MDPED Your desk base arrives in multiple cartons, labeled as: 2) MDPED - Fully assembled drawer units 1) M-PANEL - One modesty panel M-PANEL The Desk Top will be its own carton. Please flatten and retain this carton for assembly.
  • Page 4 Mobile Admin/Teacher Desk Dual Pedestal - Continued ® Step 3. Position the two MDPED units on the desk top, top-side down with the fronts facing toward the front of the desk. Attach the Modesty Panel to the Drawer Units using two (2) M6 truss head screws for each side.
