- Page 1 OLIMPO Data Collection Unit User’s Manual (ver. 5.12) SIAP+MICROS S.r.l. Via del Lavoro,1 tel +39 0438 491411 – fax +39 0438 401573 I – 31010 – Castello Roganzuolo email info@siapmicros.com di San Fior (TV) www.siapmicros.com...
-
Page 2: Table Of Contents
OLIMPO ver. 00 SUMMARY Precautions and safety measures......................1 1.1 The aim of use ............................1 1.2 Warnings ............................... 2 1.3 Moving the unit............................2 1.4 Unpacking ............................. 2 1.5 During the functioning ........................... 2 1.6 Storage..............................3 1.7 Maintenance............................3 1.7.1... -
Page 3: Precautions And Safety Measures
OLIMPO ver. 00 1 Precautions and safety measures Olimpo is a measuring instrument which allows you to acquire electrical measures , elaborate and memorize them. This unit complies with the requirements set out by the Low Tension 73/23 CEE Directive, modified according to the 93/68/CEE and the EMC 89/336/CEE Directives. -
Page 4: Warnings
OLIMPO ver. 00 1.2 Warnings The producer declines all responsibility if a fault is due to a disobedience of the instructions, tampering, any use not stated in this manual, improper use of the unit, the use of the unit by untrained staff. Only authorized and specially trained, qualified staff may have access to the working area for the standard maintenance and operative purposes. -
Page 5: Storage
OLIMPO ver. 00 1.6 Storage If the unit is not used for long periods (at least one year) all cables of the unit should be disconnected, kept in a transparent plastic bag and tied with adhesive tape. Label the bag suitably to indicate the contents and weight (15kg) of the unit , indicate that this bag should be "HANDLED WITH CARE". -
Page 6: The Panel Description
OLIMPO ver. 00 1.8 The panel description Display PWR Switch Membrane keyboard COM1 - RS232 Connection to PC COM2 - RS232 Connection to GSM Memory card User’s manual pag. 4 di 29 Printed in e005-di OLIMPO (eng).doc Siap+Micros S.r.l. -
Page 7: The Use Of The Olimpo Main Unit
OLIMPO ver. 00 2 The use of the Olimpo main unit 1.9 Switching on the Olimpo main unit The Olimpo Main unit is switched on by pressing the switch situated at the front of the Main unit next to the LCD display. -
Page 8: Resetting The Memory To Zero
OLIMPO ver. 00 To set the clock it is necessary to follow the structure indicated on the display with two numbers for each field, where : HH = hour MM = minutes SS = seconds GG = day MM = month... -
Page 9: The Registration
OLIMPO ver. 00 1.12 The registration The Olimpo Main Unit deals with two different types of solid state memories to register the acquired data: • internal memory of a RAM type situated in the mother circuit board. • (optional) memory of a memory card type (ATA Flash) which is extractable, inserted into the PCMCIA connector placed at the front of the Olimpo Main Unit. -
Page 10: The Registration Autonomy
OLIMPO ver. 00 The data held in the memory card may be downloaded onto a Personal Computer equipped with a RS232 by using the suitable LMEMC driver (see relative paragraph) When the memory card is read by the driver, it will be automatically predisposed to be reset at zero when it is installed in any other OLIMPO station. - Page 11 OLIMPO ver. 00 Each part of this Record Format is subdivided within itself into separate fields of the characters "," (ASCII 44). All of the data (instant data, statistical data, data in alert, Calibration data, etc) managed by the system are all recorded in the internal memory (RAM) of the Main Unit and, if present, in the external memory (memory card).
-
Page 12: Record Format For Statiscal Data
OLIMPO ver. 00 1.15 Record format for Statiscal Data The Statistical Data is available with this format in File n° 6 (internal memory) or in the File n° 10 (memory card). 1.15.1 HAED The Head of the Record Format contains the information which allows for the identification of the record based on the event of a storm and of the station of origin. - Page 13 OLIMPO ver. 00 Where the various fields assume the following meaning: Numerical code which identifies in an univocal way the parameter (analogical input or digital input ON/OFF) to which the following refer to. constant ASCII characters ( From ASCII 65 to ASCII 90) which expresses the meaning of the following "value"...
-
Page 14: An Example Of The Statistical Data Record Format
OLIMPO ver. 00 1.15.3 TERMINATOR Finally, the Terminator is a field which indicates the end of the record format. The Terminator is made up of character “#” (ASC11 35) + a number which indicates the total number of record (fields) between the starting header ST and the terminator # inclusive. - Page 15 OLIMPO ver. 00 the meaning of the various fields is summarized in the following table STid_station A header which identifies the start of the Head of the record. It is composed of Letter ST plus a number indicating the ID code of the station.
- Page 16 OLIMPO ver. 00 The two fields undertake the following meaning: constant The characters ASCII (from ASCII 65 to ASCII 90 ) which express the meaning of the following field "VALUE". value A numerical value which represents the characteristics of the parameter being examined.
-
Page 17: An Example Of The Instant Data In The Record Format
OLIMPO ver. 00 constant value Instant data of the parameter acquired correctly An error of electric acquisition A parameter in the out of monitor condition Instant data in the over-range condition Instant data invalid due to a variation of the associated digitial input Instant data invalid due to an invalidation of the associated anologic input. -
Page 18: The Record Format Of Data In Alert
OLIMPO ver. 00 where: Station n°2 STid_station ST02 The constant code of the record format with a dynamic structure Hour, minute and seconds of the event hh.nn.ss 13.45.15 The day of the event The month of the event The year of the event... - Page 19 OLIMPO ver. 00 the meaning of the various fields are shown in the following table: STid_station A header which identifies the start of the Header of the record. It is composed of characters "ST" plus a number indicating the code (id) of the station.
- Page 20 OLIMPO ver. 00 Each time every section is broken down into two fields which together compete to provide the single information regarding the parameter in alarm. Each section would be structured in detail like this: SECTION_N = constant + “,” + value...
-
Page 21: An Example Of The Record Format Of Data In Alert
OLIMPO ver. 00 constant value Any numerical value (instant data in alarm of the parameter mentioned). If the value is acquired wrongly from an electrical angle, would be replaced by the characters "*". constant value If the threshold of alarm or prealarm identified by the Id is that it has overcome the instant value. - Page 22 OLIMPO ver. 00 where: Station n°2 STid_station ST02 Constant code of the record format with a dynamic structure The hour and minute of the event hh.nn 13.45 The day of the event The month of the event The year of the event...
-
Page 23: Technical Features
OLIMPO ver. 00 3 Technical features Input/output ....- Analogic inputs : n. 8 a 12 bit + n. 4 analogic input/Pt100 a 18 bit with differential input - Analogic input range: +/- 2V each input 18 bit 0-2V each input a 12 bit - Analogic output: n. -
Page 24: Safety Regulations
OLIMPO ver. 00 4 Safety regulations In this dossier you are provided with complete technical documents which assures you that this product is in full accordance with the safety regulations existing now. Careful examining and testing has allowed us to fully appreciate all risks which might occur while using the product, when used correctly , to be able to set out clear instructions for a proper use. -
Page 25: Emc
OLIMPO ver. 00 e) plugs and sockets for domestic power use; power devices for electric fencing; g) material which respects radio electric disturbance; h) special electric material, to be used on ships, airplanes and trains, in conformance with the safety regulations laid out by the International Organizations, which the State Members of the European Economic Community are part of;... -
Page 26: Environmental Conditions Of Use
OLIMPO ver. 00 1.1 Environmental conditions of use This apparatus has been made to be used in accordance with the specifications indicated in the following table: USE FORESEEN AND DATA/INFORMATION AVAILABLE THE LIMITS OF THE APPARATUS The use foreseen includes exclusively the measuring of the... -
Page 27: Conformity Declaration
OLIMPO ver. 00 5 Conformity Declaration Conformity Declaration MICROS Srl Via del Lavoro, 1 – 31010 Castello Roganzuolo di S. Fior (TV) – Italia Declares herein that the product described is in compliance with the following Community Directives set out ( including all of the modifications applicable):... -
Page 28: The Schematic Of The Main Unit's
OLIMPO ver. 00 6 The schematic of the Main Unit’s INGRESSO 220V MAGNETOTERMICO SCARICATORE PRESENZA RETE RELAY 40.52 su zoccolo finder MORSETTO TERRA RELE PRESENZA ALIMENTAZIONE BARRA EQUIPOTENZIALE SULLA GRIGLIA POSTERIORE DEL PANNELLO MONITOR ALIMENTATORE 14 V BATTERIA KAT 600... -
Page 29: Memory Card Drive (Olm-Lmc)
OLIMPO ver. 00 7 Memory card drive (OLM-LMC) The memory card driver has been made with the same electronic aspects which run the OLIMPO Main Unit and allows you to read the memory card coming from the peripherical station.
