Package Content; Charging The Circulator (Nerve And Muscle Stimulator); Charging Related Warnings; Technical Specification - Weightworld CIRCULATOR User Manual

5. Package Content

The device packaging consists of the following inclusive content:
Circulator (Nerve & Muscle Stimulator) Device
Electrode Patches
Electrode Patches Cable
DC USB Cable
User Manual
Circulator (Nerve & Muscle Stimulator) Bag
6. Charging the Circulator
Place charger output pin in Circulator (Nerve & Muscle Stimulator) charging slot.
Plug the charger into any working 110V 50/60Hz or 220/240v 50/60Hz mains electrical outlet.
Both the Glowing Green and Red Light indicates that the charging is on.
When the device is fully charged, it indicates the 'Solid Green' light.
Your device will be fully charged in 4 1/2 hours.
When the battery is low, it is indicated by short beep sound and when the battery is
completely discharged it is indicated by a long beep sound.

7. Charging related warnings

Charging with any other types of DC USB Cable may damage the device.
Usage of any other attachment that is not with your charger may result in electric
shock or injury to people.
Shortening the terminal of the charging socket or plug may cause permanent
damage to the device,
To ensure the optimum battery performance, always store the device in a fully charged state.
Document No.: CWL-URM-04A
11
(Nerve and muscle stimulator)
| Revision No.: 00. | Revision Date: 20.06.2022
8. Technical Specification
Name of product
Model
Dimensions
Weight
No. of Programs
Input Voltage
Input Power
Chargeable
Working Time
Mode of Machine
Operational Frequency
Delay Frequency
Batteries
Accessories
Operating conditions:
Transportation and storage environment:
Applied parts
Applied parts Applied parts
Electrode patches Electrode patches
Foot pads Foot pads
Document No.: CWL-URM-04A | Revision No.: 00.
Circulator
(Nerve and Muscle Stimulator)
Circulator
458 mm x 343 mm x 72 mm
2 kg with Box Pack
2 (PI-EMS, P2-TENS)
5VDC
10 Watt
Yes
30 min
1
0-99Hz
300ms
Lithium ion batteries
Electrode Patches Cable,
DC USB Cable and Electrode Patches
41°F - 104°F (5°C - 40°C), 30% — 75% RH,
700 hPa - 1060 hPa atmospheric pressure
14°F - 122°F (-10°C - 50°C), 10% - 90% RH,
700 hPa - 1060 hPa atmospheric pressure
Applicable type verification Applicable type verification
BF BF
BF BF
| Revision Date: 20.06.2022
12
