• Devices may be compound (have multiple

functions) or contain hubs.

• Devices are high-speed (12 Mbps) or low-

speed (1.5 Mbps) only. Hubs are high only.

• Differential Data Signalling (3.3V NRZI)

• +Vcc is 500mA @ 5 Vdc

• Devices may supply own power.

• Vcc and Ground make contact before Data lines.

• Maximum length of any single Hub-Device segment:

Hub

3m for low-speed devices

• Maximum length to any (high speed) device (5 external hub tiers):

Root Hub

• Connectors are friction/detent capture only, and may not be suitable for moderate or

high shock/vibration environments (without user-designed capture).

A Closer Look

Hub

Device

30m

Hub

+Vcc

-Data

+Data

Ground

Hub

Device
